Zebra Zd420
Brand | Zebra 2019 |
Model | ZD42H42-D01E00EZ |
Released Year | 2019 |
Type | Printers |
Status | Active |
Quick view
Overview
The Zebra ZD420 is a desktop label printer designed for high-quality, on-demand printing solutions in office environments. It supports direct thermal and thermal transfer printing technologies with a maximum print resolution of 203 dpi, producing clear and precise labels. The printer boasts a print speed of up to 6 inches per second, facilitating efficient workflow in various labeling applications. Connectivity options include USB, USB Host, and optional wireless capabilities such as Wi-Fi and Bluetooth for flexible integration. The device uses an intuitive LCD interface for easy configuration and monitoring. Its compact size and durable design optimize workspace usage while ensuring reliable operation under continuous use.
Specifications
Input Type | Monochrome |
Grayscale Depth | 16 Bit |
Color Depth | 8 Bit |
Memory | 256 MB SDRAM, 512 MB Flash |
Output Type | Black & White |
MPN | ZD42H42-D01E00EZ |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | Zebra ZD420 |
Connectivity | USB 2.0, USB Host, optional Wi-Fi and Bluetooth |
Features | Networkable |
Scanning Resolution | 200x200 DPI |
Country/Region of Manufacture | China |
Printer type | Thermal Transfer and Direct Thermal |
Print resolution | 203 dpi (8 dots/mm) |
Maximum print width | 4.09 inches (104 mm) |
Print speed | Up to 6 inches per second (152 mm/s) |
Display | User-friendly LCD display |
Media handling | Roll-fed or fan-fold media, label length up to 39 inches |
Ribbon types | Wax, Wax/Resin, Resin |
Dimensions (WxDxH) | 7.5 x 8 x 6.75 inches |
Weight | 3.6 lbs (1.63 kg) |
Operating Temperature | 40°F to 105°F (4.4°C to 40.5°C) |
Power supply | External universal power supply, 100-240V |
Compatible operating systems | Windows, macOS, Linux |
Images
Key Advantages
The ZD420 offers user-friendly features like quick media loading and ribbon cartridge compatibility, reducing downtime significantly. Its versatile connectivity options enhance adaptability in diverse office setups, from wired to wireless networks. The printer's robust build quality supports long-term reliable performance, minimizing maintenance needs. Energy-efficient operation helps reduce power consumption without compromising print quality. A wide range of media compatibility supports various label types and sizes, enhancing application versatility. The ZD420's clear LCD display simplifies status monitoring and printer settings for users of all experience levels.
Limitations
The print resolution is limited to 203 dpi, which may not suit applications requiring ultra-high-definition labels. Unlike some competitors, the ZD420 does not support color printing, restricting output to monochrome labels. The maximum print width is 4.09 inches, which may be insufficient for certain large-format labeling requirements. Media roll capacity is moderate, potentially requiring frequent replacements in high-volume operations. While wireless options are available, they come as optional extras rather than standard features. Pricewise, it might be higher than basic thermal printers, which could be a consideration for budget-conscious buyers.
FAQ
What printing technologies does the Zebra ZD420 support?
The Zebra ZD420 supports both direct thermal and thermal transfer printing technologies.
What is the maximum print speed of the ZD420?
The ZD420 can print at speeds up to 6 inches per second.
Does the ZD420 have wireless connectivity options?
Yes, wireless options such as Wi-Fi and Bluetooth are available but must be added as optional modules.
What is the maximum print resolution of the Zebra ZD420?
The printer offers a maximum print resolution of 203 dpi.
Is the ZD420 suitable for color label printing?
No, the Zebra ZD420 only supports monochrome (black and white) printing.
Can the ZD420 use ribbon cartridges for thermal transfer printing?
Yes, it supports ribbon cartridge use for thermal transfer printing, making ribbon loading easier.
What types of media can the Zebra ZD420 handle?
The printer supports a wide range of media types, including labels, tags, and receipts suitable for office and industrial applications.
