Zebra S4M image

Zebra S4M

Quick information
Brand Zebra 2005
Model S4M00-3001-0100T
Released Year 2005
Type Printers
Series S4m
Status Discontinued
Quick view
Full specs Images FAQ

Overview

The Zebra S4M is an industrial direct thermal and thermal transfer barcode printer designed for medium volume labeling applications. It features a robust metal frame construction ensuring durability in harsh environments. The printer supports print speeds up to 5 inches per second and offers a maximum print width of 4.09 inches (104 mm). It uses a 32-bit RISC processor for efficient label data processing and has 8 MB SDRAM and 4 MB flash memory storage for label formats. The S4M supports Ethernet, parallel, and serial connectivity options, allowing compatibility with various host systems. It also includes advanced calibration algorithms for precise media handling and print quality.

Specifications

Non-Domestic Product No
Output Type Black & White
Custom Bundle No
MPN S4M00-3001-0100T
Modified Item No
Type Label Printer
Printer Type Industrial Thermal Transfer and Direct Thermal
Technology Thermal Transfer/Direct Thermal
Maximum Resolution 300dpi
Model S4M
Connectivity Ethernet, Serial RS-232, Parallel, USB (optional)
Black Print Speed 6ips
Product Line Zebra S4M
UPC Does not apply
Print Speed Up to 5 inches per second (127 mm/s)
Print Resolution 203 dpi (8 dots/mm), optional 300 dpi (12 dots/mm)
Maximum Print Width 4.09 inches (104 mm)
Media Types Continuous, die-cut, black mark, notch
Media Width Range 0.79 inches to 4.45 inches (20 mm to 113 mm)
Processor 32-bit RISC processor
Memory 8 MB SDRAM, 4 MB Flash
Label Sensor Adjustable reflective, transmissive sensors
Dimensions 10.45" W x 17.4" D x 12.59" H (265 mm x 442 mm x 320 mm)
Weight Approximately 22 lbs (10 kg)
Power Supply Auto-switching power supply 100-240V, 50-60Hz
Operating Temperature 40°F to 104°F (5°C to 40°C)
Programming Language Zebra Programming Language (ZPL)
Discontinued Yes

Key Advantages

  • Durable industrial design suitable for factory and warehouse environments.
  • High print speed of up to 5 inches per second for efficient label production.
  • Multiple connectivity options including Ethernet, parallel, and serial ports for flexibility.
  • Supports a wide variety of media types and sizes with easy calibration features.
  • Robust memory capacity allowing storage of complex label formats and graphics.
  • Compatibility with Zebra’s ZPL programming language for ease of integration with existing systems.

Limitations

  • Relatively limited color printing capability, primarily supporting monochrome labels.
  • The printer is heavier and less compact compared to smaller desktop models.
  • Media ribbons require manual replacement which may slow workflow in high volume environments.
  • Limited to print widths up to 4.09 inches, which may not suit large label requirements.
  • The firmware update process can be technical, requiring specialized knowledge.
  • End of standard support may lead to challenges sourcing replacement parts.
