Zebra TLP2824 Plus
Brand | Zebra 2005 |
Model | AC Adapter, 282P-101511-000, Barcode, Ethernet, Network, Peeler |
Released Year | 2005 |
Type | Printers |
Series | Tlp |
Printing technology | Direct thermal |
Status | Discontinued |
Quick view
Overview
The Zebra TLP2824 Plus is a compact, thermal label printer designed for low to medium volume applications offering reliable performance.
This printer uses direct thermal technology eliminating the need for ink or toner and supporting a wide range of label materials.
Equipped with a 203 dpi print resolution, it ensures clear and sharp barcode and text printing essential for office and retail applications.
The device supports various connectivity options including USB, serial, and optional Ethernet for network integration.
It also offers an optional peel-off feature to automate label dispensing and improve operational efficiency.
The robust design includes easy media loading and an AC adapter for stable power supply.
Specifications
Input Type | Monochrome |
Output Type | Black & White |
Memory | Standard 2 MB SDRAM, 8 MB Flash |
MPN | AC Adapter, 282P-101511-000, Barcode, Ethernet, Network, Peeler |
Supported Paper Size | Maximum Label Width: 2.36" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | TLP2824 Plus |
Connectivity | USB 1.1, Serial RS-232, Optional Ethernet |
Features | Networkable, Portable |
Black Print Speed | 4 ips |
Product Line | Zebra TLP |
UPC | 783555102039 |
Printer type | Desktop thermal label printer |
Printing technology | Direct thermal |
Print resolution | 203 dpi (8 dots/mm) |
Maximum print width | 2.2 inches (56 mm) |
Maximum print length | Up to 39 inches (991 mm) |
Print speed | Up to 4 inches per second |
Media type | Labels, tags, continuous paper, wristbands |
Media width | 0.75 to 2.36 inches (19 to 60 mm) |
Media thickness | 0.0025 to 0.010 inches (0.0635 to 0.254 mm) |
Power supply | External AC adapter 24V, 2.5A |
Dimensions | 7.8 in W x 5.9 in H x 8.5 in D (198 mm x 150 mm x 216 mm) |
Weight | Approx. 3.8 lbs (1.7 kg) |
Optional features | Peeler module, Ethernet network interface |
Supported barcodes | Code 39, Code 128, UPC, EAN, Interleaved 2 of 5, and more |
Images
Key Advantages
The TLP2824 Plus offers high-quality 203 dpi printing producing crisp text and barcodes, crucial for scanning and readability.
Compact size makes it ideal for space-conscious environments while maintaining strong print performance.
Versatile connectivity options simplify network integration and allow flexible deployment.
Direct thermal printing technology reduces maintenance by removing the need for ribbons or ink cartridges.
Optional peeling feature speeds up label application, saving time in repetitive tasks.
Durable construction ensures reliable operation even in demanding office scenarios.
Limitations
Print speed may be slower than some industrial printers, limiting high-volume output.
Limited to 203 dpi resolution, which may not be sufficient for very fine detail or small barcodes.
Direct thermal printing is sensitive to heat and light, which can cause label fading over time.
Optional features like Ethernet connectivity and peeler increase cost and may require additional setup.
It has a moderate maximum print width (2.2 inches) which may not suit larger label requirements.
The power adapter's specifications and compatibilities must be verified to avoid operational issues.
FAQ
What types of labels can the Zebra TLP2824 Plus print?
The printer supports direct thermal labels including paper and synthetic materials, typically used for barcode, shipping, and identification labels.
Does the TLP2824 Plus support network connectivity?
Yes, it supports USB and serial by default, with optional Ethernet adapters available for network integration.
Can the printer use a peeler for labels?
Yes, an optional peel-off feature is available allowing automatic label peeling for efficient application.
What is the print resolution of the TLP2824 Plus?
It prints at 203 dpi, providing clear and legible text and barcodes.
Is the TLP2824 Plus still supported by Zebra?
This model has been officially discontinued, but Zebra may provide limited support and documentation.
What accessories come with the TLP2824 Plus?
Common accessories include an AC adapter, power cord, USB or serial cable, and optional Ethernet modules or peelers.
What are the power requirements for this printer?
It requires an AC adapter typically rated around 24V DC; ensuring compatibility with the power source is essential.
