Zebra LP2824 image

Zebra LP2824

Quick information
Brand Zebra 2008
Model 2824-21400-0001, LAN Network, AC Adapter
Released Year 2008
Type Printers
Series Lp
Status Discontinued
Quick view

Overview

The Zebra LP2824 is a compact thermal label printer designed for efficient barcode and label printing in office environments. This model operates with a direct thermal printing method, which eliminates the need for ink or toner, reducing maintenance costs. It supports a maximum print width of 4.09 inches (104 mm) and a resolution of 203 dpi, suitable for clear labels and barcodes. The printer features a maximum print speed of up to 4 inches per second, optimizing throughput in medium volume printing tasks. Connectivity options include LAN networking capability and an external AC adapter for reliable power supply. The device is built with an easy-to-load media system compatible with labels, tags, and receipt paper rolls, ensuring user convenience and versatility.

Specifications

Input Type Monochrome
Output Type Black & White
Memory 8 MB SDRAM, 4 MB Flash
MPN 2824-21400-0001, LAN Network, AC Adapter
Supported Paper Size Maximum Label Width: 2.36"
California Prop 65 Warning This item does NOT contain any chemicals or materials specified in the California Prop 65 list.
Type Label Printer
Technology Thermal
Maximum Resolution 203 x 203 DPI
Model LP2824
Connectivity LAN Network (Ethernet), RS-232 Serial (optional), USB (optional)
Features Portable
Black Print Speed 4 ips
Country/Region of Manufacture United States
Product Line Zebra LP
Printer type Direct Thermal
Print resolution 203 dpi (8 dots/mm)
Maximum print width 4.09 inches (104 mm)
Maximum print speed 4 inches per second (102 mm/sec)
Power supply External AC Adapter
Media types supported Direct thermal labels, tags, receipts
Media width 0.75 in to 2.36 in (19 mm to 60 mm)
Dimensions (W x D x H) 7.1 x 8.0 x 5.8 inches (180 x 203 x 148 mm)
Weight Approximately 3.4 lbs (1.54 kg)
Operating system support Windows, Mac OS, Linux with appropriate drivers
Label sensor Reflective and transmissive sensors
Discontinued Yes

Key Advantages

The Zebra LP2824 provides high print quality at 203 dpi making it ideal for barcode and label clarity. Its compact and lightweight design allows for easy placement in limited office spaces. The direct thermal printing technology reduces consumable costs by eliminating ink or toner. The LAN network connectivity enables multiple users to share the printer efficiently in office environments. Its quick label loading mechanism reduces downtime and streamlines operations. Additionally, the printer is energy efficient with an external AC power adapter that ensures stable and consistent printing performance.

Limitations

The LP2824 supports only direct thermal printing, which limits label durability when exposed to heat or sunlight over time. Its print speed, while adequate for moderate volume, may not be sufficient for high-demand industrial labeling environments. The maximum print width of 4.09 inches restricts the size of labels compared to larger industrial printers. The device has a relatively basic control panel and lacks touchscreen interfaces found in newer models. It has limited internal memory, which can restrict the complexity of stored label templates. The printer also does not support wireless connectivity options like Wi-Fi or Bluetooth natively, requiring physical LAN connections.
