Zebra LP 2824
Brand | Zebra 2005 |
Model | 282P-201112-000, 2824211000001 |
Released Year | 2005 |
Type | Printers |
Series | Lp |
Status | Discontinued |
Quick view
Overview
The Zebra LP 2824 is a compact, thermal label printer designed primarily for office and retail environments. Featuring direct thermal printing technology, it operates without the need for ink or toner, reducing ongoing supplies and maintenance costs. The printer supports a maximum print resolution of 203 dpi and a maximum print width of up to 2.2 inches, suitable for small label printing needs. Connectivity options typically include serial, parallel, and USB interfaces, allowing flexible integration with various systems. The device is optimized for low- to medium-volume printing tasks and offers easy media loading with a clamshell design for user convenience. Compatible with popular label design software, it facilitates efficient label creation for shipping, inventory, and asset tracking applications.
Specifications
Input Type | Monochrome |
Memory | Dependent on firmware - typical configurations include 8 MB Flash, 8 MB SDRAM |
Output Type | Black & White |
MPN | 282P-201112-000, 2824211000001 |
California Prop 65 Warning | non |
Supported Paper Size | A8 (52 x 74 mm), A0 (841 x 1189 mm), A9 (37 x 52 mm) |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | LP 2824 |
Connectivity | Serial, Parallel, USB |
Features | Scanner, Portable, Networkable |
Black Print Speed | 4 ppm |
Country/Region of Manufacture | China |
Product Line | Zebra LP |
UPC | 0132017738529 |
Print Technology | Direct Thermal |
Print Width | Maximum 2.2 inches (56 mm) |
Print Resolution | 203 dpi (8 dots/mm) |
Print Speed | Up to 4 inches per second (102 mm/s) |
Media Types | Roll or fanfold labels, tags, receipt paper |
Media Width | 0.75 inches to 2.36 inches (19 mm to 60 mm) |
Dimensions | 7.0 inches W x 5.9 inches D x 5.5 inches H (177 mm x 150 mm x 140 mm) |
Weight | Approx. 3.6 lbs (1.63 kg) |
Power Supply | External 100-240 VAC, 50/60 Hz |
Operating Temperature | 40°F to 105°F (5°C to 40°C) |
Operating Humidity | 20-85% non-condensing |
Driver Support | Windows, Mac, Linux |
Emulations | Zebra CPCL, ZPL, EPL |
Images
Key Advantages
The LP 2824's compact and lightweight design saves workspace and promotes easy portability. Its direct thermal technology eliminates the need for ink cartridges or ribbons, lowering operational costs and maintenance. The printer provides fast print speeds up to 4 inches per second for efficient output. Compatibility with multiple connectivity options (serial, parallel, USB) enhances installation flexibility. It features user-friendly media loading with drop-in mechanism, minimizing downtime during roll changes. Additionally, broad software and driver support ensures seamless integration across different applications and platforms.
Limitations
The LP 2824 prints only in monochrome due to its direct thermal technology, limiting use in applications requiring color labels. Its maximum print width of 2.2 inches restricts it to smaller labels and tags. The print resolution of 203 dpi may not be suitable for highly detailed graphics or small fonts. It is designed for low- to medium-volume printing; thus, it might not meet high-demand industrial printing needs. Lack of wireless connectivity reduces flexibility compared to modern printers. Since it uses thermal printing, labels can fade over time when exposed to heat and sunlight.
FAQ
What type of printing technology does the Zebra LP 2824 use?
The Zebra LP 2824 employs direct thermal printing technology, which does not require ink or toner.
What is the maximum print resolution of the LP 2824?
The printer offers a maximum print resolution of 203 dots per inch (dpi).
Can the LP 2824 connect via USB?
Yes, the Zebra LP 2824 typically includes USB connectivity along with serial and parallel interfaces.
Is the LP 2824 suitable for large label printing?
No, the printer supports a maximum print width of approximately 2.2 inches, suitable mainly for small labels.
Does the LP 2824 support color printing?
No, it prints only in monochrome because it uses direct thermal printing technology.
Is the Zebra LP 2824 still in production?
No, the Zebra LP 2824 has been discontinued.
What are common use cases for the Zebra LP 2824 printer?
Common applications include shipping labels, asset tags, inventory labels, and retail price tags.
