Zebra GX430T
| Brand | Zebra 2010 |
| Model | GX43-102410-000, Ethernet Network, AC Adapter., Tag, Shipping |
| Released Year | 2010 |
| Type | Printers |
| Series | Gx |
| Status | Discontinued |
Quick view
Overview
The Zebra GX430t is a high-resolution thermal transfer desktop printer designed for office and industrial use.
It supports print resolutions up to 300 dpi, enabling high-quality barcode and text output.
The printer features a maximum print speed of 4 inches per second and a print width up to 4.09 inches.
Equipped with a 32-bit processor and 8MB SDRAM plus 4MB Flash memory, it ensures efficient processing and print performance.
Connectivity options include USB 2.0, serial port, and an optional Ethernet network interface for flexible integration.
It supports multiple barcode symbologies and scalable fonts, compatible with Zebra programming languages EPL and ZPL.
Specifications
| Input Type | Monochrome |
| Output Type | Black & White |
| Memory | 8 MB SDRAM, 4 MB Flash |
| MPN | GX43-102410-000, Ethernet Network, AC Adapter., Tag, Shipping |
| Supported Paper Size | Max Label Width: 4.25" |
| California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
| Type | Label Printer |
| Technology | Thermal |
| Maximum Resolution | 300 x 300 DPI |
| Model | GX430T |
| Connectivity | Ethernet (RJ-45), Serial (RS-232), USB 2.0 |
| Features | Networkable, Portable |
| Black Print Speed | 4 ips |
| Product Line | Zebra GX |
| Release Year | 2010 |
| Printer Type | Thermal Transfer / Direct Thermal Desktop Printer |
| Print Resolution | 300 dpi (12 dots/mm) |
| Maximum Print Width | 4.09 inches (104 mm) |
| Maximum Print Speed | 4 inches per second (102 mm/sec) |
| Processor | 32-bit |
| Interface | USB 2.0, Serial RS232, Optional Ethernet 10/100 |
| Media Types Supported | Labels, Tags, Receipt Paper, Wristbands |
| Media Sensors | Moveable black mark sensor, gap sensor, ribbon near end sensor |
| Ribbon | Thermal transfer ribbons, 1 inch core |
| Dimensions (WxDxH) | 7.9 x 9.8 x 7.5 inches (200 x 249 x 191 mm) |
| Weight | Approx. 5.9 lbs (2.7 kg) |
| Operating System Compatibility | Windows, Mac OS, Linux |
| Power Supply | AC Adapter included |
| Supported Printer Languages | ZPL, EPL |
| Accessories | Ethernet network card, AC Adapter, media/tag supplies |
Images
Key Advantages
The GX430t delivers superior print resolution at 300 dpi, ideal for detailed labels and barcodes.
Its thermal transfer technology provides durable and long-lasting prints suitable for harsh environments.
Compact desktop design saves space without compromising performance.
Wide connectivity options including optional Ethernet allow versatile deployment.
Supports a broad range of media types and widths, which enhances printing flexibility.
Reliable and fast printing at up to 4 inches per second meets high-volume labeling needs efficiently.
Limitations
The printer's 4-inch maximum print width limits applications that require wider labels.
Memory size is modest by modern standards, potentially limiting complex label designs.
The device does not inherently support wireless connectivity; users must rely on wired interfaces.
Limited to thermal transfer and direct thermal printing methods, restricting some print media options.
Lack of touchscreen interface may reduce ease of direct configuration and status monitoring.
Discontinued status means replacement parts and support may be harder to source over time.
FAQ
What print resolutions does the Zebra GX430t support?
The Zebra GX430t supports print resolutions of 203 dpi and 300 dpi, with 300 dpi providing high-quality detailed prints.
What connectivity options are available for the GX430t printer?
The printer includes USB 2.0 and serial ports by default and offers an optional Ethernet network interface for versatile connectivity.
Is the GX430t suitable for printing wide labels?
The maximum print width is 4.09 inches, making it suitable for standard-sized labels but not for very wide formats.
What printing technologies does the GX430t support?
The printer supports thermal transfer and direct thermal printing methods.
Does the GX430t support wireless networking?
No, the GX430t does not have built-in wireless capabilities; it relies on wired USB, serial, or Ethernet connections.
Are replacement parts and support still available for the GX430t?
As the model is discontinued, replacement parts and official support may be limited and harder to procure.
Which printer programming languages are compatible with the GX430t?
The printer supports Zebra's EPL and ZPL programming languages for label formatting and control.
