Zebra ZD420
| Brand | Zebra 2017 |
| Model | Ethernet, Network, AC Adapter, ZD420d, ZD42043-D01E00EZ |
| Released Year | 2017 |
| Type | Printers |
| Series | Zd |
| Status | Active |
Quick view
Overview
The Zebra ZD420 is a high-performance desktop barcode printer designed for office and retail environments requiring fast, reliable label printing.
Equipped with Ethernet and network connectivity, it supports seamless integration within existing IT infrastructures for efficient data communication.
It features a thermal transfer and direct thermal printing mechanism delivering high-quality labels with resolutions up to 203 dpi.
The device accommodates a wide range of media types and sizes enabling flexible labeling solutions across various applications.
Its compact design is complemented by an intuitive user interface and easy media loading, reducing downtime and operational complexity.
The included AC adapter ensures stable and consistent power supply to maintain optimal performance during prolonged use.
Specifications
| Printer Type | Desktop thermal transfer and direct thermal barcode printer |
| Print Resolution | 203 dpi (8 dots/mm) |
| Print Speed | Up to 6 inches per second |
| Connectivity | Bluetooth, Ethernet (RJ-45), USB 2.0, USB Host |
| Media Types | Continuous, die-cut, black mark, tag, and receipt |
| Media Width | 1.00 inches to 4.25 inches (25.4 mm to 108 mm) |
| Media Thickness | 0.0023 in to 0.0100 in (0.058 mm to 0.25 mm) |
| Memory | 128 MB |
| Dimensions | 7.6 in (W) x 7.5 in (H) x 9 in (D) (193 mm x 191 mm x 229 mm) |
| Weight | 6.5 lbs (2.95 kg) |
| Power Supply | External AC adapter 100-240V, 50-60Hz |
| Operating Temperature | 40°F to 105°F (5°C to 41°C) |
| Interface Supported | ZPL, EPL, XML, and other printer languages |
| Display | LCD with buttons for status and configuration |
| Input Type | Monochrome |
| Output Type | Black & White |
| MPN | Ethernet, Network, AC Adapter, ZD420d, ZD42043-D01E00EZ |
| Supported Paper Size | Max Label Width: 4.65" |
| California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
| Type | Label Printer |
| Technology | Thermal |
| Maximum Resolution | 300 x 300 DPI |
| Model | ZD420 |
| Features | Networkable, Portable |
| Black Print Speed | 4 ips |
| Product Line | Zebra ZD |
Images
Key Advantages
The ZD420 provides reliable Ethernet and network connectivity, enabling centralized printer management.
Its fast print speeds improve operational efficiency in busy environments requiring rapid label generation.
The compact footprint conserves workspace in office settings without sacrificing performance.
User-friendly media loading reduces setup times and operator errors.
Support for multiple media types and sizes allows versatile application without the need for specialized devices.
The integrated AC adapter ensures consistent power delivery, enhancing device stability and longevity.
Limitations
Print resolution is limited to 203 dpi, which may not suffice for applications needing high-definition labels.
While it supports Ethernet networking, it lacks built-in wireless connectivity, requiring additional accessories for Wi-Fi functionality.
The printer is optimized for moderate print volumes and may not meet demands of heavy industrial environments.
Some advanced label design features require compatible software, adding to overall setup cost.
Replacement parts and proprietary media may have higher costs compared to generic alternatives.
Firmware updates might require manual intervention or technical support for end users.
FAQ
Does the Zebra ZD420 support Ethernet connectivity?
Yes, the Zebra ZD420 printer includes built-in Ethernet connectivity for easy network integration.
What printing technology is used in the ZD420?
The printer uses thermal transfer and direct thermal printing technologies to produce durable barcodes and labels.
Is the ZD420 suitable for high-volume printing environments?
The ZD420 is designed for moderate print volumes typically found in office or retail settings, but might not be ideal for heavy industrial use.
Can the printer handle different label sizes and types?
Yes, the ZD420 supports a wide range of media types and label sizes providing flexibility for various labeling needs.
Does it come with wireless connectivity built-in?
No, the ZD420 does not have built-in wireless capabilities; however, wireless modules can be added as accessories.
What is the maximum print resolution of the ZD420 printer?
The printer offers a maximum resolution of 203 dpi for clear barcode and text printing.
Is the AC adapter included with the Zebra ZD420?
Yes, the standard package includes an AC adapter to provide stable and reliable power.
