Zebra 105SL
Brand | Zebra 2000 |
Model | Barcode, 10500-2001-0000 |
Released Year | 2000 |
Type | Printers |
Series | 105 |
Status | Discontinued |
Quick view
Overview
The Zebra 105SL is a robust industrial barcode label printer designed for high-volume printing applications. It utilizes direct thermal and thermal transfer printing technologies, allowing for flexible media compatibility. The printer supports resolutions of 203 dpi, offering clear and precise barcode printing essential for inventory and shipping labels. It features a metal frame construction which ensures durability in demanding environments. Connectivity options include parallel and serial interfaces, catering to integration with various legacy systems. The thermal printhead is engineered for long lifecycle and easy replacement, minimizing downtime in operational settings.
Specifications
Input Type | Monochrome |
Output Type | Black & White |
Memory | 2 MB DRAM, 2 MB Flash ROM |
MPN | Barcode, 10500-2001-0000 |
Supported Paper Size | Maximum Label Width: 4.52" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | 105SL |
Connectivity | Parallel (Centronics), serial RS-232 |
Black Print Speed | 8 ips |
Product Line | Zebra 105 |
UPC | 033587451514 |
Printing Method | Direct Thermal and Thermal Transfer |
Print Resolution | 203 dpi (8 dots/mm) |
Maximum Print Width | 4.09 inches (104 mm) |
Maximum Print Speed | 4 inches per second (102 mm/s) |
Media Types | Continuous, die-cut, black mark, fan-fold, tags, tickets |
Media Width | 0.79 to 4.6 inches (20 to 117 mm) |
Media Thickness | 0.003 to 0.010 inches (0.08 to 0.25 mm) |
Ribbon Type | Wax, wax/resin, resin |
Ribbon Width | 1.57 to 4.33 inches (40 to 110 mm) |
Dimensions (W x D x H) | 11.6 x 15.25 x 13.25 inches (295 x 388 x 337 mm) |
Weight | 26 lbs (11.8 kg) |
Construction | Metal frame with plastic covers |
Operating Temperature | 40° to 104° F (5° to 40° C) |
Storage Temperature | -40° to 140° F (-40° to 60° C) |
Power Supply | 100-240 VAC, 47-63 Hz |
Images
Key Advantages
The Zebra 105SL provides high-speed printing, facilitating efficient high-volume label production. Its durable metal chassis enhances reliability and withstands industrial wear and tear. Compatible with a wide range of label materials and ribbons, it offers versatility for different labeling needs. The printer supports programmable fonts and graphics, enabling customizable labels. Easy to maintain printhead and platen rollers reduce service time and operational costs. Its legacy interface options ensure compatibility with older systems without requiring additional adapters.
Limitations
The Zebra 105SL offers limited connectivity options compared to modern printers, lacking USB and Ethernet standard ports. The printing resolution is fixed at 203 dpi, which may not be sufficient for ultra-high definition labels. It does not support advanced wireless networking technologies, limiting deployment flexibility. The printer is relatively heavy and bulky, reducing portability and space efficiency. Firmware updates and support are limited due to its age, potentially causing compatibility issues with newer software. Replacement parts may be harder to source as the model is considered legacy, potentially increasing maintenance time.
FAQ
What printing technologies does the Zebra 105SL support?
The Zebra 105SL supports both direct thermal and thermal transfer printing technologies.
What is the print resolution of the Zebra 105SL printer?
It offers a print resolution of 203 dpi for clear barcode and text printing.
Is the Zebra 105SL still available in the market?
No, the Zebra 105SL has been discontinued and is considered a legacy model.
What connectivity options does the Zebra 105SL provide?
The printer includes parallel and serial interfaces for data communication.
Can the Zebra 105SL print custom fonts and graphics?
Yes, it supports programmable fonts and graphics to customize label output.
Is the Zebra 105SL suitable for high-volume industrial use?
Yes, its design and durability make it well-suited for high-volume industrial labeling applications.
Are replacement parts available for the Zebra 105SL?
Because the model is discontinued, replacement parts may be limited but can still occasionally be sourced through specialized vendors.
