BIXOLON SRP-350 Plus III
Brand | BIXOLON 2012 |
Model | SRP-350PlusIII, 497-0508382 |
Released Year | 2012 |
Type | Printers |
Series | Srp |
Status | Active |
Quick view
Overview
The BIXOLON SRP-350 Plus III is a high-speed 3-inch thermal receipt printer designed primarily for office and retail environments. It supports ESC/POS command system compatibility, making it suitable for various POS applications. The printer features a print speed of up to 220mm per second and a resolution of 203 dpi (8 dots/mm) ensuring clear, sharp output. Connectivity options include USB, Serial, and Parallel interfaces, with optional Ethernet and Bluetooth modules for flexible integration. It uses 80mm wide thermal paper rolls with easy drop-in loading to streamline maintenance. The device is built for durability with an MCBF (Mean Cycles Between Failure) rating of 60 million lines, assuring long-term reliability.
Printing mechanism involves direct thermal printing technology which eliminates the need for ink or ribbons, reducing running costs. The compact design meets the needs of restricted counter space while maintaining performance. Standard features also include sensor-based detection for paper end and cover open status to prevent printing errors. It supports multiple code page encoding to accommodate global languages and characters, enhancing usability in diverse regions. The SRP-350 Plus III operates with low noise and low power consumption, making it an efficient choice for busy retail and office environments.
Specifications
Printer type | Direct Thermal Printer |
Print speed | Up to 220 mm/s |
Print resolution | 203 dpi (8 dots/mm) |
Paper width | 80 mm |
Connectivity options | USB, Serial, Parallel; Optional Ethernet, Bluetooth |
Command system | ESC/POS compatible |
Print method | Line Thermal Printhead |
Paper loading method | Drop-in |
Mean Cycles Between Failures (MCBF) | 60 million lines |
Dimensions (W x D x H) | 142 x 204 x 148 mm |
Weight | 1.7 kg |
Power Supply | AC 100-240V, 50-60Hz |
Memory | NA |
Character support | Font A: 12x24, Font B: 9x17 |
Emulation | ESC/POS |
Sensors | Paper end sensor, Cover open sensor |
Operating temperature | 5 ~ 45°C |
Humidity | 10 ~ 80% RH |
Input Type | Monochrome |
Output Type | Black & White |
MPN | SRP-350PlusIII, 497-0508382 |
Supported Paper Size | Max. Label Width: 3.15" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Point of Sale Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | SRP-350 Plus III |
Connectivity | Ethernet (RJ-45), Serial (RS-232C), USB 2.0 |
Features | Networkable, Portable |
Black Print Speed | 11.8 ips |
Product Line | Bixolon SRP |
Images
Key Advantages
The SRP-350 Plus III offers rapid printing speeds up to 220mm/s, ideal for high-volume printing tasks. Its compact footprint saves valuable desk space without compromising durability. Multiple connectivity options ensure flexible integration with existing POS systems. The thermal printing technology reduces consumable costs due to no ribbon or ink requirement. Easy paper loading minimizes downtime and improves operator productivity. It supports diverse paper widths and has multiple sensors for reliable operation.
Limitations
The printer is limited to 203 dpi print resolution, which may be insufficient for high-detail graphics or logos. It requires heat-sensitive paper, which is prone to fading over time compared to other printing technologies. The absence of built-in wireless connectivity in base models may require additional modules for network integration. It's primarily designed for receipt printing and lacks features for other document types. Replacement of mechanical parts may be required after extended heavy usage. The device does not support color printing as it is monochrome thermal technology.
FAQ
What types of connectivity does the BIXOLON SRP-350 Plus III support?
The SRP-350 Plus III supports USB, Serial, and Parallel interfaces by default, with optional modules for Ethernet and Bluetooth connectivity.
What is the maximum print speed of the SRP-350 Plus III?
It can print at speeds of up to 220 millimeters per second.
Does the printer support color printing?
No, the SRP-350 Plus III uses thermal printing technology which only supports monochrome printing.
What is the paper width supported by this printer?
The printer supports 80mm wide thermal paper rolls.
Is the SRP-350 Plus III compatible with ESC/POS commands?
Yes, it is compatible with ESC/POS command systems, making it widely usable in POS environments.
How easy is it to load paper in the SRP-350 Plus III?
Paper loading is designed to be simple with a drop-in mechanism that reduces downtime.
Is the SRP-350 Plus III still in production?
As of now, it is not discontinued and remains available in the market.
