Zebra ZD620
| Brand | Zebra 2016 |
| Model | AC Adapter, Barcode, ZD620t, Ethernet, ZD62142-T01L01EZ, Wireless Network |
| Released Year | 2016 |
| Type | Printers |
| Series | Zd |
| Status | Active |
Quick view
Overview
The Zebra ZD620 series represents advanced desktop barcode printers designed for office and industrial environments. It employs a direct thermal and thermal transfer printing mechanism, supporting high-resolution print speeds up to 8 inches per second. Connectivity options include USB, Ethernet, and wireless (Wi-Fi) interfaces, ensuring versatile integration into existing networks. The printer features a color LCD interface with a user-friendly design for status monitoring and configuration. It supports a wide variety of label materials and sizes, with a maximum print width of 4.09 inches. The device utilizes an ARM Cortex-A9 processor with significant memory for efficient data processing and label printing.
Specifications
| Input Type | Monochrome |
| Output Type | Black & White |
| Memory | 512 MB Flash; 256 MB SDRAM |
| MPN | AC Adapter, Barcode, ZD620t, Ethernet, ZD62142-T01L01EZ, Wireless Network |
| Supported Paper Size | Max Label Width: 4.65" |
| California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
| Type | Label Printer |
| Technology | Thermal |
| Maximum Resolution | 203 x 203 DPI |
| Model | ZD620 |
| Connectivity | USB 2.0, USB Host, Ethernet 10/100, Optional Wi-Fi 802.11ac, Bluetooth 4.1 |
| Features | Networkable, Portable, Peeler, LCD |
| Black Print Speed | 8 ips |
| Product Line | Zebra ZD |
| UPC | 751492929996 |
| Printer Type | Direct Thermal and Thermal Transfer |
| Print Resolution | 203 dpi (8 dots/mm) or 300 dpi (12 dots/mm) |
| Max Print Width | 4.09 inches (104 mm) |
| Max Print Speed | 8 inches per second (203 dpi model) |
| Processor | 32-bit ARM Cortex-A9 |
| Display | Color LCD (Configurable) |
| Label Roll Capacity | 127 mm (5 inches) outer diameter |
| Media Types Supported | Continuous, die-cut, black-mark, tag, receipt, wristband |
| Ribbon Width | 1.57 inches to 4.33 inches (40 mm to 110 mm) |
| Dimensions (W x D x H) | 7.0 x 8.0 x 6.0 inches |
| Weight | Approx. 2.3 kg (5.1 lbs) |
| Power Supply | External AC adapter, input 100-240V AC, output 24V DC |
| Operating Temperature | 5°C to 40°C (41°F to 104°F) |
| Storage Temperature | -40°C to 60°C (-40°F to 140°F) |
| Languages Supported | ZPL, EPL, XML, CPCL |
| SDK and Software | ZebraDesigner, ZebraNet Bridge, Link-OS environment |
Images
Key Advantages
Zebra ZD620 offers high print speed and superior print quality, suitable for complex barcode labeling. It includes multiple connectivity options such as USB, Ethernet, and Wi-Fi for flexible networking. The built-in color LCD screen improves user interaction and printer status monitoring. Its compact design fits easily on desks while maintaining durability for industrial use. The printer supports a broad material range, including synthetic and paper labels for enhanced application versatility. Furthermore, it allows cloud-based remote management, enabling IT administrators to monitor and update devices effortlessly.
Limitations
The ZD620 series may have a higher purchase price compared to basic desktop printers, making it a larger investment. Some users report that the device firmware updates require specific software tools and may not always be seamless. The wireless module depends heavily on network infrastructure quality; in weak signal areas, connectivity could be interrupted. Its thermal transfer ribbon capacities might demand frequent replacements in high-volume environments. Compatibility with older Zebra labels or software might be limited without firmware updates. Additionally, spare parts and specialized accessories could have limited availability in certain regions.
FAQ
What types of connectivity does the Zebra ZD620 support?
The Zebra ZD620 supports USB, Ethernet, and optional Wi-Fi wireless connectivity, allowing versatile integration into various network environments.
Can the ZD620 print in both direct thermal and thermal transfer modes?
Yes, the ZD620 offers both direct thermal and thermal transfer printing, supporting a wide range of label types and materials.
Is there a display screen to monitor printer status on the ZD620?
Yes, it features a color LCD display that provides status updates, error notifications, and configuration options for ease of use.
What is the maximum printing resolution of the Zebra ZD620?
The ZD620 supports a maximum print resolution of 300 dpi (dots per inch), enabling high-quality barcode and label printing.
Are there wireless networking options available on the ZD620?
Yes, select models of the ZD620 are equipped with optional Wi-Fi and Bluetooth modules for wireless operation.
What operating systems are compatible with Zebra ZD620 drivers?
Drivers for the ZD620 support Windows, macOS, and Linux operating systems, ensuring broad compatibility across platforms.
Is the Zebra ZD620 still supported by the manufacturer?
Yes, as of the latest information, Zebra continues to provide support and updates for the ZD620 series.
