Zebra QN3-AUNA0M00-00
Brand | Zebra 2018 |
Model | QN3-AUNA0M00-00 |
Released Year | 2018 |
Type | Printers |
Series | Qln320 |
Printing Technology | Direct Thermal |
Status | Active |
Quick view
Overview
The Zebra QN3-AUNA0M00-00 is a mobile printer from the QLn320 series designed for efficient on-the-go label printing. It uses direct thermal printing technology to produce high-quality, durable labels without requiring ink or toner. The device supports resolutions of 203 dpi, allowing for clear text and barcode printing essential for logistics and retail applications. Connectivity options include Bluetooth, Wi-Fi, and USB, enabling versatile integration with various mobile devices and computer systems. It features a compact and rugged design with IP43 rating and drop resistance up to 5 feet, suitable for harsh environments. The printer also boasts a battery capacity that supports extended printing periods, ensuring minimal downtime in field operations.
Specifications
Print Technology | Thermal |
Max Label and Liner Width | 3.125”/79 mm |
Output Type | Black & White |
Memory | 256 MB Flash, 128 MB SDRAM |
Max Print Width | 3.125”/79 mm |
MPN | QN3-AUNA0M00-00 |
Max Media Roll Size | 2.6”/66 mm O.D. on a 0.75”/19 mm or 1.375”/34.9 mm I.D. core |
Supported Paper Size | 3" |
Type | Mobile Printer |
Technology | Thermal |
Maximum Resolution | 203 dpi/8 dots per mm |
Media Types | Labels and Receipt Paper |
Model | QN3-AUNA0M00-00 |
Connectivity | Bluetooth 3.0, 802.11 a/b/g/n Wi-Fi, USB 2.0 |
Black Print Speed | 4" / 102 mm per second |
Product Line | Zebra QLN320 |
Printer Type | Mobile Thermal Printer |
Printing Technology | Direct Thermal |
Print Resolution | 203 dpi (8 dots/mm) |
Print Width | Up to 104 mm (4.09 inches) |
Print Speed | Up to 4 inches per second (102 mm/s) |
Display | Monochrome LCD |
Battery | Rechargeable Lithium-ion, approx. 8 hours life |
Dimensions | 125 mm x 79 mm x 178 mm |
Weight | Approx. 420 grams |
Durability | Drop resistance up to 5 feet, IP43 rated |
Media Type | Direct thermal labels and receipts |
Media Width | 25.4 mm to 114 mm |
Operating Temperature | -20°C to 50°C |
Supported Languages | ZPL, EPL, CPCL |
Images
Key Advantages
The QLN320 model offers robust wireless connectivity with simultaneous Wi-Fi and Bluetooth support, increasing flexibility in different usage scenarios. Its compact and lightweight design enhances portability, making it ideal for mobile workers. High-resolution 203 dpi printing improves label clarity and scannability. The rugged build of the printer ensures durability under challenging industrial environments, reducing maintenance costs. The easy-to-load media mechanism speeds up the process of paper replacement, boosting productivity. Additionally, the device offers good battery life to handle prolonged work shifts without frequent recharging.
Limitations
One limitation of the QN3-AUNA0M00-00 is the exclusive use of direct thermal printing technology, which can be less durable than thermal transfer under exposure to heat and sunlight. It has a print speed capped at 4 inches per second, which may be slower than some competitors for high-volume needs. The printer primarily supports smaller label sizes, limiting its use for larger format printing. Connectivity setups, although flexible, might require technical expertise for optimal configuration in complex network environments. The device does not come with NFC connectivity, a feature increasingly common in newer mobile printers. Finally, the battery replacement requires attention, as it may need proprietary parts which could be less accessible over time.
FAQ
What type of printing technology does the Zebra QN3-AUNA0M00-00 use?
It uses direct thermal printing technology, which prints by heating thermochromic paper without requiring ink or toner.
What are the connectivity options available on the QLn320 series printer?
The printer supports Bluetooth, Wi-Fi, and USB connections for flexible device integration.
Is the Zebra QN3-AUNA0M00-00 suitable for outdoor usage?
Yes, it has a rugged design with an IP43 rating and drop resistance up to 5 feet, suitable for harsh and outdoor environments.
What is the print resolution and speed of this Zebra printer?
It offers 203 dpi print resolution with a maximum print speed of up to 4 inches per second.
Can this model print large labels?
The QLn320 primarily supports label widths up to 4 inches, making it unsuitable for larger format printing.
Does the QN3-AUNA0M00-00 support NFC connectivity?
No, this model does not have NFC connectivity options.
Is the printer still supported and not discontinued?
The printer is currently not discontinued and supported in the market.
