Zebra Zd420c
Brand | Zebra 2017 |
Model | ZD42042-C01E00EZ |
Released Year | 2017 |
Type | Printers |
Series | Z |
Printing Technology | Direct Thermal / Thermal Transfer |
Status | Active |
Quick view
Overview
The Zebra ZD420c is a desktop thermal printer designed for label printing in office electronics applications, primarily in the printing category. It utilizes direct thermal and thermal transfer printing technology, ideal for high-quality label creation. Featuring a compact design, the ZD420c supports print widths up to 4.09 inches (104 mm) and resolutions up to 203 dpi for crisp, clear printing. Connectivity options include USB, USB Host, Serial, Ethernet, and Bluetooth, making it suitable for diverse office environments. The printer supports a variety of media types including continuous, die-cut, black mark, and tag stock labels. Its user-friendly interface incorporates a color LCD and supports easy ribbon and media loading to optimize user experience and efficiency.
Specifications
MPN | ZD42042-C01E00EZ |
UPC | 0779184180562 |
Model | Zebra ZD420C |
Memory | 512 MB Flash, 256 MB SDRAM |
Technology | Thermal |
Connectivity | USB 2.0, USB Host, Serial, Ethernet (optional), Bluetooth (optional) |
Output Type | Black & White |
Features | Portable, Networkable |
Input Type | Monochrome |
Type | Label Printer |
Maximum Resolution | 203 x 203 DPI |
Black Print Speed | 6 ppm |
Product Line | Zebra Z |
Printing Technology | Direct Thermal / Thermal Transfer |
Print Resolution | 203 dpi (8 dots/mm) |
Maximum Print Width | 4.09 inches (104 mm) |
Maximum Print Speed | 6 inches per second (152 mm/s) |
Media Types | Continuous, Die-cut, Black Mark, Tag Stock |
Media Width Range | 0.79 inches to 4.25 inches (20 mm to 108 mm) |
Display | Color LCD interface |
Dimensions | 7.4 in H x 7.6 in W x 9.25 in D (188 mm x 193 mm x 235 mm) |
Weight | 4.9 lbs (2.2 kg) |
Operating Temperature | 40°F to 105°F (5°C to 40°C) |
Power | Universal power supply (100-240V AC) |
Software | Supports Zebra Link-OS, ZPL, EPL programming languages |
Images
Key Advantages
The Zebra ZD420c offers fast print speeds up to 6 inches per second enhancing productivity. Its versatility in connectivity options allows seamless integration with existing networks and devices. The printer's compact footprint saves valuable workspace without compromising functionality. Energy-efficient thermal printing technology reduces power consumption and maintenance requirements. The ZD420c supports a wide range of media to accommodate different labeling needs. User-centric features, such as easy media loading and intuitive controls, minimize downtime and enhance operational efficiency.
Limitations
The ZD420c's maximum print resolution of 203 dpi may not suffice for ultra-high-resolution label requirements. It is primarily designed for desktop use and may not meet the needs of large-scale industrial printing operations. The printer does not support color label printing since it is limited to monochrome thermal printing technology. Ribbon and media options are somewhat limited compared to larger industrial printers. While compact, its print speed may not be optimal for extremely high-volume printing demands. Additionally, some connectivity options are optional and may require separate purchase or configuration.
FAQ
What printing technology does the Zebra ZD420c use?
The Zebra ZD420c uses direct thermal and thermal transfer printing technologies.
What is the maximum print resolution of the ZD420c printer?
The maximum print resolution is 203 dpi.
What connectivity options are available with the Zebra ZD420c?
Available connectivity options include USB, USB Host, Serial, Ethernet, and Bluetooth.
Can the ZD420c print in color?
No, the ZD420c supports only monochrome thermal printing.
Is the Zebra ZD420c still in production?
As of now, the Zebra ZD420c has not been officially discontinued.
What are the typical applications of the ZD420c printer?
It is typically used for label printing in office, retail, healthcare, and light industrial environments.
What types of media does the ZD420c support?
It supports continuous, die-cut, black mark, and tag stock labels.
