Zebra ZD420
Brand | Zebra 2017 |
Model | Network, AC Adapter, ZD420d, ZD42042-D01W01EZ, Wireless |
Released Year | 2017 |
Type | Printers |
Series | Zd |
Printing Technology | Thermal Transfer and Direct Thermal |
Status | Active |
Quick view
Overview
The Zebra ZD420 printer is engineered for high-quality label printing with precision thermal transfer and direct thermal technologies. It supports multiple connectivity options including USB, wired Ethernet, and wireless, enhancing network integration flexibility. The device features an easy-to-load ribbon cartridge system which simplifies media replacement and minimizes downtime. Its 4-inch print width capability and print speed up to 6 inches per second allow consistent output performance in various office environments. The ZD420 series also includes advanced security protocols to protect network communication and device access. Compact and designed with a contemporary aesthetic, it suits diverse applications from retail to healthcare.
Specifications
Input Type | Monochrome |
Output Type | Black & White |
Memory | 256 MB SDRAM, 512 MB Flash |
MPN | Network, AC Adapter, ZD420d, ZD42042-D01W01EZ, Wireless |
Supported Paper Size | Max Label Width: 4.65" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | ZD420 |
Connectivity | USB, Wired Ethernet, Wireless (Wi-Fi 802.11ac/b/g/n), Bluetooth (optional) |
Features | Networkable, Portable |
Black Print Speed | 6 ips |
Product Line | Zebra ZD |
UPC | 654538545955 |
Printing Technology | Thermal Transfer and Direct Thermal |
Print Width | 4 inches (104 mm) |
Print Speed | Up to 6 inches per second (152 mm/s) |
Media Types Supported | Continuous, die-cut, black mark, fanfold labels and tags |
Resolution | 203 dpi (8 dots/mm), optional 300 dpi |
Power Supply | External AC adapter 100-240V, 50-60 Hz |
Physical Dimensions | 8.7" W x 7.5" H x 10.4" D (221 mm x 191 mm x 264 mm) |
Weight | Approx. 4.1 lbs (1.86 kg) |
Operating Temperature | 40°F to 105°F (4.4°C to 41°C) |
Operating Humidity | 10% to 90% non-condensing |
User Interface | 3 LED status indicators, single feed button |
Software Compatibility | ZebraDesigner, Zebra Setup Utilities, Zebra Link-OS printer management |
Security | Secure boot, network security protocols including WPA/WPA2 for wireless |
Images
Key Advantages
The ZD420 offers remarkable ease of use with its innovative media handling system. Its broad connectivity options, including wireless capability, provide networking versatility. The printer’s fast print speeds optimize productivity in busy office settings. It is compatible with a wide range of label materials and sizes, ensuring flexible application. Zebra’s printer diagnostics and management tools facilitate remote monitoring and troubleshooting. The compact design reduces the device footprint while maintaining robust build quality for long-term reliability.
Limitations
The ZD420’s print speed, while sufficient for most office tasks, might be lower compared to industrial-grade printers for high-volume labeling. Its thermal print technology limits the device to monochrome printing, unsuitable for color label requirements. The cost of specialized Zebra media and ribbons can increase operational expenses. Wireless network setup may require some technical knowledge for optimal configuration and security. It lacks certain advanced features found in larger, higher-end models like automatic cutter options. Replacement parts and accessories are primarily proprietary, potentially limiting third-party options.
FAQ
What printing technologies does the Zebra ZD420 support?
The Zebra ZD420 supports both thermal transfer and direct thermal printing technologies.
Does the ZD420 support wireless connectivity?
Yes, the ZD420 model includes wireless connectivity options for network flexibility.
What is the maximum print width of the ZD420 printer?
The maximum print width supported by the ZD420 is 4 inches.
Can the ZD420 printer handle various label sizes and materials?
Yes, it is compatible with a wide range of label sizes and materials suitable for diverse office labeling needs.
Is the Zebra ZD420 still in production?
As of now, the Zebra ZD420 is not discontinued and continues to be supported.
What are the power supply options for the ZD420?
The ZD420 uses an AC adapter power supply for reliable operation.
Are there any software tools available for managing the ZD420 printer?
Yes, Zebra provides printer diagnostics and management software for remote monitoring and maintenance.
