Zebra Zd411 image

Zebra Zd411

Quick information
Brand Zebra 2017
Model ZD4AH22-D01E00EZ
Released Year 2017
Type Printers
Status Active
Quick view
Full specs Images

Overview

The Zebra ZD411 is a compact thermal label printer designed for office environments requiring fast and reliable printing solutions. It utilizes direct thermal technology, eliminating the need for ink or toner, which enhances cost efficiency and maintenance simplicity. Equipped with a 203 dpi print resolution, it ensures clear and crisp barcode and text printing for various label sizes. The device offers USB, Serial, and Ethernet connectivity options, providing versatile interfacing with multiple host systems. Its compact footprint and light weight make it ideal for limited workspace situations. Additionally, the ZD411 supports easy media loading and features Zebra’s Link-OS environment for integration with enterprise systems.

Specifications

Input Type Monochrome
Output Type Black & White
Memory 128 MB Flash, 128 MB SDRAM
MPN ZD4AH22-D01E00EZ
Item Length 8.6 inch
Type Label Printer
Technology Thermal
Maximum Resolution 203 x 203 DPI
Item Height 6 Inch
Model Zebra ZD411
Connectivity USB 2.0, Serial RS-232, Ethernet 10/100 Mbps
Features Networkable, Portable
Country/Region of Manufacture China
Item Width 4.5 inch
Product Line Zebra Z
Printer Technology Direct Thermal
Print Resolution 203 dpi (8 dots/mm)
Max Print Width 4.09 inches (104 mm)
Print Speed Up to 6 inches per second (152 mm/s)
Media Type Die-cut labels, Continuous media, Tags, Receipt paper
Media Width 0.75 inch to 4.5 inches (19 mm to 114 mm)
Dimensions (WxHxD) 7.6 x 6.5 x 7.1 inches (193 x 165 x 180 mm)
Weight 4.0 lbs (1.8 kg)
Operating Temperature 40°F to 105°F (5°C to 40°C)
Power Supply External power supply 100-240VAC, 50-60 Hz
Supported Barcodes 1D and 2D barcodes including Code 39, Code 128, QR Code, Data Matrix
Printer Languages ZPL, EPL

Key Advantages

1. Compact and lightweight design enables easy placement in constrained office spaces.

2. Direct thermal printing technology reduces consumable costs by eliminating the need for ribbons or ink.

3. Multiple connectivity options including USB, Serial, and Ethernet ensure versatile deployment.

4. Supports a print resolution of 203 dpi for high-quality barcode and label output.

5. Zebra’s Link-OS platform allows enhanced device management and integration capabilities.

6. User-friendly media loading process reduces downtime during label roll changes.

Limitations

1. Only supports direct thermal printing, so labels are susceptible to fading over time or with heat exposure.

2. Print resolution limited to 203 dpi, which may not be suitable for extremely small or high-density barcode requirements.

3. Limited to monochrome printing; no capability for color labels.

4. The maximum label width is constrained, limiting larger format applications.

5. Lacks wireless connectivity options such as Wi-Fi or Bluetooth, which may restrict flexible installation.

6. The device series is less known, potentially affecting parts availability in the long term.

FAQ

The Zebra ZD411 uses direct thermal printing technology that prints images on heat-sensitive media without requiring ink or ribbons.

The printer supports USB, Serial, and Ethernet connections for versatile use with different host devices.

No, the Zebra ZD411 only supports monochrome printing using direct thermal labels.

The printer has a 203 dpi resolution which is sufficient for most barcode and text labels but may not meet very high-density print requirements.

Media loading is designed to be user-friendly and quick, minimizing downtime during label roll replacement.

No, this model does not have built-in wireless connectivity such as Wi-Fi or Bluetooth.

As of now, the Zebra ZD411 is not discontinued and is available for purchase.
