Zebra ZD411
Brand | Zebra 2017 |
Model | ZD411 ZD4a022-d0em00ez, ZD411 ZD4A022 DOEM00EZ |
Released Year | 2017 |
Type | Printers |
Status | Active |
Quick view
Overview
The Zebra ZD411 is a thermal transfer and direct thermal desktop label printer designed for office and light industrial environments. It supports resolutions up to 300 dpi, ensuring high-quality, crisp label prints with fine detail. This printer integrates multiple connectivity options including USB, serial, Bluetooth, and optional Wi-Fi, offering flexible installation for diverse workflows. The device utilizes Zebra’s Link-OS operating system, providing streamlined device management and seamless integration with Zebra's software tools. It supports various media types including labels, tags, receipts, and wristbands with widths up to 4 inches. Equipped with fast print speeds up to 6 inches per second, the ZD411 optimizes label production efficiency while maintaining compact size for desktop use.
Specifications
Input Type | Monochrome |
Print Technology | Thermal Transfer |
Output Type | Black & White |
MPN | ZD411 ZD4a022-d0em00ez, ZD411 ZD4A022 DOEM00EZ |
Depth | 9.6" |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 300dpi |
Item Height | 6.7" |
Core Size | 1.00 inch |
Model | ZD411 |
Connectivity | USB 2.0, Serial, Bluetooth (optional), Wi-Fi (optional) |
Features | Desktop |
Scanning Resolution | 300dpi |
Package Quantity | 1Pc |
Max Media Width | 2.0-2.9 inch |
Country/Region of Manufacture | China |
Item Width | 5.5" |
Product Line | ZEBRA |
Printer Type | Thermal Transfer and Direct Thermal |
Print Resolution | 300 dpi (12 dots/mm) |
Print Width | 4.09 inches (104 mm) |
Print Speed | Up to 6 inches per second (152 mm/s) |
Processor | 32-bit RISC processor |
Memory | 256 MB Flash; 128 MB SDRAM |
Operating System | Zebra Link-OS |
Media Type | Labels, Tags, Receipts, Wristbands |
Media Sensing | Gap, Black Mark, Notches |
Media Width | 0.585 to 4.25 inches (15 mm to 108 mm) |
Media Thickness | 0.003 inches to 0.0075 inches (0.08 mm to 0.19 mm) |
Media Roll Diameter | Up to 5 inches (127 mm) |
Power Supply | External power supply 100-240 VAC, 50-60Hz |
Dimensions (WxHxD) | 7.5 x 6.7 x 8 inches (191 x 170 x 203 mm) |
Weight | 3.6 lbs (1.63 kg) |
Images
Key Advantages
The printer offers high-resolution 300 dpi printing, ideal for detailed barcode labels and small fonts. Its compact footprint allows placement in limited office spaces. Flexible connectivity options such as USB, option for wireless, and Bluetooth enhance versatility. The Link-OS ecosystem simplifies device management and troubleshooting remotely. Quick media loading with its clamshell design reduces downtime and eases maintenance. Reliable thermal printing technology ensures consistent output quality and durability.
Limitations
The ZD411 is primarily designed for low-to-medium volume label printing, which might be limiting in high-volume industrial applications. It has a maximum media width of 4.09 inches, unsuitable for larger label requirements. The printer lacks some advanced industrial durability features present in heavy-duty Zebra models. The initial investment for optional wireless modules can increase the total cost. It does not natively support color printing options, being a monochrome thermal device. Print speed, although adequate, is slower compared to some newer models focusing on high throughput.
FAQ
What printing technologies does the Zebra ZD411 support?
The Zebra ZD411 supports both direct thermal and thermal transfer printing technologies.
What is the maximum print resolution of the ZD411?
The printer offers a maximum print resolution of 300 dots per inch (dpi).
Which connectivity options are available for the ZD411?
Standard connectivity includes USB and serial ports; optional Bluetooth and Wi-Fi modules are available.
Can the ZD411 handle different label types?
Yes, it supports labels, tags, receipts, and wristbands of varying sizes up to 4.09 inches wide.
Is the ZD411 suitable for high volume industrial printing?
No, it is intended for low-to-medium volume office or light industrial printing environments.
Does the ZD411 support remote device management?
Yes, it uses Zebra’s Link-OS operating system, enabling advanced remote management and integration.
Is the ZD411 printer still currently manufactured?
Yes, as of the latest information, the Zebra ZD411 is still in production.
