Zebra ZD41022-D01000EZ
Brand | Zebra 2017 |
Model | ZD41022-D01000EZ |
Released Year | 2017 |
Type | Printers |
Series | Z |
Status | Active |
Quick view
Overview
The Zebra ZD41022-D01000EZ is a compact thermal label printer designed for office and industrial applications that require fast, reliable label printing.
It features direct thermal printing technology with a print resolution of 203 dpi, delivering sharp and clear barcode and text output suitable for a variety of labeling needs.
This model supports a maximum print width of 2.2 inches, making it ideal for small label sizes frequently used in retail and healthcare.
The printer is equipped with a fast print speed of up to 6 inches per second, improving productivity in fast-paced environments.
With flexible connectivity options including USB, Ethernet, and optional Wi-Fi, it integrates seamlessly into existing office networks and systems.
The device supports various media types including continuous, die-cut, black mark, and tag stock, enhancing its versatility for different labeling applications.
Specifications
Input Type | Monochrome |
Output Type | Black & White |
MPN | ZD41022-D01000EZ |
California Prop 65 Warning | : |
Type | Label Printer |
Printer Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | ZD41022-D01000EZ |
Connectivity | USB 2.0, 10/100 Ethernet, optional Wi-Fi (802.11ac) |
Features | Portable |
Product Line | Zebra Z |
UPC | Does not apply |
Print Technology | Direct Thermal |
Print Resolution | 203 dpi (8 dots/mm) |
Maximum Print Width | 2.2 inches (56 mm) |
Print Speed | Up to 6 inches per second (152 mm/s) |
Processor | 32-bit ARM Cortex-A7 |
Memory | 256 MB Flash, 128 MB SDRAM |
Media Types | Continuous, die-cut, black mark, tag stock |
Media Width | 1.0 inch to 2.28 inches (25 mm to 58 mm) |
Media Roll Diameter | Up to 2.6 inches (66 mm) |
Cutter | Optional auto-cutter |
Dimensions | 7.0 in (W) x 5.0 in (H) x 7.25 in (D) |
Weight | 2.4 lbs (1.1 kg) |
Operating Systems Supported | Windows, Mac OS, Linux |
Power Supply | External 100-240 V AC, 50-60 Hz |
Certifications | FCC Class A, CE, UL, cUL, RoHS |
Images
Key Advantages
The Zebra ZD41022-D01000EZ offers compact design, ideal for environments with limited space.
Its high-speed printing capability increases throughput and operational efficiency.
The printer supports multiple connectivity options including wireless, ensuring easy integration.
It provides excellent print quality at 203 dpi resolution for clear and precise labels.
Compatibility with a wide range of media types provides flexibility for diverse labeling needs.
Easy-to-use operation with intuitive interface reduces training time and increases productivity.
Limitations
The ZD41022-D01000EZ's maximum print width is limited to 2.2 inches, which may not suit larger label requirements.
It uses direct thermal printing, which is less durable and more susceptible to fading compared to thermal transfer printing.
The print resolution is 203 dpi, which may be insufficient for applications needing very fine print details.
Some advanced connectivity options are optional, potentially increasing overall cost.
Media roll capacity is limited due to its compact size, requiring more frequent media replacements.
It may lack some advanced software features found in higher-end Zebra printer models.
FAQ
What is the print technology used in the Zebra ZD41022-D01000EZ?
The printer uses direct thermal printing technology.
What are the connectivity options available in this model?
It comes with USB and Ethernet connectivity by default, with optional Wi-Fi support.
What is the maximum print width supported by the printer?
The maximum print width supported is 2.2 inches.
Is this printer suitable for high volume printing?
The printer supports a decent print speed up to 6 inches per second, suitable for low to medium volume printing tasks.
What types of media can the Zebra ZD41022-D01000EZ handle?
It supports continuous, die-cut, black mark, and tag stock media types.
Does the printer support thermal transfer ribbons?
No, the ZD41022-D01000EZ is a direct thermal only printer and does not support thermal transfer ribbons.
Is the printer still in production?
Yes, the Zebra ZD41022-D01000EZ is currently in production.
