Zebra ZD410
Brand | Zebra 2015 |
Model | ZD41022D01000EZ, 1079903-021, ZD410 |
Released Year | 2015 |
Type | Printers |
Series | Z |
Status | Active |
Quick view
Overview
The Zebra ZD410 is a compact direct thermal and thermal transfer printer that excels in printing labels, receipts, and tags with precision. It features a print resolution of 203 dpi, which enables sharp and clear print output suitable for various industrial applications. The device supports printing speeds up to 6 inches per second, ensuring efficient handling of medium-volume printing demands. Connectivity options include USB, Serial, Ethernet, and optional Bluetooth or Wi-Fi, allowing flexible integration into existing office environments. The ZD410 supports a wide variety of media widths up to 2.2 inches, making it versatile for diverse printing tasks. It also incorporates Link-OS environment support for ease of management and device connectivity.
Specifications
Input Type | Monochrome |
Output Type | Black & White |
MPN | ZD41022D01000EZ, 1079903-021, ZD410 |
Item Length | 4in. |
Supported Paper Size | Max size 2.36 in./60 mm |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Manufacturer Warranty | 3 Months |
Item Height | 2in. |
Model | ZD410 |
Features | Portable |
Item Width | 4.5in. |
Product Line | Zebra Z |
Print Method | Direct Thermal and Thermal Transfer |
Print Resolution | 203 dpi (8 dots/mm) |
Max Print Speed | 6 inches per second (152 mm/s) |
Max Print Width | 2.2 inches (56 mm) |
Media Types | Die-cut labels, continuous labels, receipt paper, tags |
Media Width | 0.625 inches to 2.36 inches (16 mm to 60 mm) |
Media Thickness | 0.003 inches to 0.0075 inches (0.08 mm to 0.19 mm) |
Roll Diameter | Maximum 2.6 inches (67 mm) |
Processor | 32-bit ARM Cortex R4 |
Memory | 256 MB Flash, 128 MB SDRAM |
Connectivity | USB 2.0, Serial, Ethernet; optional Bluetooth 4.1 and Wi-Fi 802.11ac |
Operating System Support | Windows, Mac OS, Linux |
Dimensions | 4.6 in (W) x 7 in (H) x 6.9 in (D) / 117 mm x 178 mm x 175 mm |
Weight | 2.1 lbs (0.95 kg) |
Power Supply | External Universal Power Supply |
Link-OS Environment | Supported for centralized device management |
Images
Key Advantages
The Zebra ZD410 offers a compact form factor, ideal for limited space environments. It provides exceptional print quality with 203 dpi resolution at high speed. Connectivity versatility with multiple interfaces caters to broad deployment scenarios. The easy media loading mechanism reduces downtime and user errors. It supports robust printer management features via Link-OS for enhanced operational efficiency. Energy-efficient design minimizes power consumption during operation and standby modes.
Limitations
The ZD410’s maximum print width is limited to 2.2 inches, which may restrict some wide label applications. It is designed primarily for moderate volume printing and may not meet very high throughput industrial needs. The 203 dpi resolution, while adequate for most labels, is not suitable for ultra-fine detailed printing requirements. The printer’s media roll capacity is smaller compared to larger models, requiring more frequent media changes. Some connectivity options such as Bluetooth and Wi-Fi are optional add-ons rather than standard. Its direct thermal printing mode is sensitive to environmental factors like heat and light, potentially affecting label longevity.
FAQ
What types of printing technology does the Zebra ZD410 use?
The Zebra ZD410 uses direct thermal and optional thermal transfer printing technologies.
What is the maximum printing speed of the ZD410?
It can print up to 6 inches per second, suitable for moderate volume tasks.
Which connectivity options are available for the ZD410 printer?
The printer offers USB, Serial, Ethernet, with optional Bluetooth and Wi-Fi modules.
What is the maximum print width supported by this model?
It supports printing widths up to 2.2 inches (56 mm).
Can I use the ZD410 printer for high-resolution printing?
It provides 203 dpi resolution; for finer print detail, a higher dpi model would be necessary.
Is the ZD410 printer still supported and available for purchase?
Yes, as of now, it has not been discontinued and remains supported.
What types of media can the Zebra ZD410 handle?
It supports a variety of label media including die-cut labels, continuous labels, receipt paper, and tags.
