Zebra Zd220 image

Zebra Zd220

Quick information
Brand Zebra 2012
Model Zd220
Released Year 2012
Type Printers
Series Z
Status Active
Quick view

Overview

The Zebra ZD220 is a compact desktop thermal printer designed primarily for label and barcode printing in office and industrial settings. It supports direct thermal printing technology, eliminating the need for ink or toner cartridges, which reduces maintenance effort and cost. The printer offers a print resolution of 203 dpi, suitable for crisp text and barcode production on various materials such as paper and synthetic labels. It has a standard print speed up to 6 inches per second, optimizing productivity in medium volume printing environments. Connectivity options include USB and optional Ethernet, providing flexibility for different network configurations. The device supports multiple label formats and is compatible with Zebra’s Link-OS environment for easier management.

Specifications

Supported Scanning Sizes A0 (841 x 1189 mm)
Input Type Monochrome
Memory 64 MB SDRAM, 128 MB Flash
Features Portable
Country/Region of Manufacture China
Product Line Zebra Z
UPC 0751492929040
Type Label Printer
Technology Thermal
Output Type Black & White
Maximum Resolution 203 x 203 DPI
Model Zebra ZD220
Connectivity USB 2.0, Optional Ethernet
MPN ZD22042-T01G00EZ
Printer type Direct Thermal
Print resolution 203 dpi (8 dots/mm)
Print speed Up to 6 inches (152 mm) per second
Media type Roll-fed labels, tags, receipts, continuous media
Media width 0.75 inch to 4.25 inches (19 mm to 108 mm)
Dimensions 7.6 in x 5.9 in x 5.9 in (193 mm x 151 mm x 151 mm)
Weight 3.4 lbs (1.54 kg)
Operating temperature 40°F to 105°F (5°C to 40°C)
Power supply External power supply 100-240V AC
Supported barcode symbologies Code 39, Code 128, QR Code, UPC, EAN, and more
Operating system compatibility Windows, Mac OS, Linux via ZPL and EPL emulation

Key Advantages

The ZD220's direct thermal printing technology makes it cost-effective and low-maintenance as no ribbons or toners are required. Its compact design allows it to fit conveniently on crowded desktops or workstations. Fast print speeds enhance operational workflow efficiency for offices and light industrial uses. The printer is straightforward to set up and operate, making it ideal for users with minimal technical expertise. Compatibility with Zebra's Link-OS simplifies device management and remote access. Additionally, it supports multiple media types and sizes, enhancing versatility in label printing tasks.

Limitations

Being a direct thermal printer, the Zebra ZD220 labels are sensitive to heat and light, which may cause fading over time, limiting use for long-term durability needs. The print resolution of 203 dpi may not be sufficient for very high-detail printing requirements. It lacks support for wireless connectivity natively, potentially restricting placement options compared to modern printers with Wi-Fi. The printer is designed for medium volume printing, so it may not be suitable for very high-demand industrial environments. There is limited support for color printing as this model prints only in monochrome. The printer’s maximum media roll size is relatively small, which could require frequent media replacements.
