Zebra TLP 2884-Z

Quick information
Brand Zebra 2005
Model TLP 2884-Z
Released Year 2005
Type Printers
Status Discontinued
Quick view
Full specs Images

Overview

The Zebra TLP 2884-Z is a thermal transfer printer designed primarily for printing high-quality barcode labels and tags in office and industrial environments.

It utilizes thermal transfer technology, using a ribbon coated with ink to produce sharp and durable prints on various media types.

The printer supports a maximum print resolution of 203 dpi (8 dots/mm), enabling clear and reliable barcode readability.

It features a print width of up to 4 inches (104 mm) and a maximum print speed of approximately 6 inches per second, suitable for moderate volume label printing.

The TLP 2884-Z is equipped with serial, parallel, and USB interfaces for flexible connectivity with host computers.

Its rugged design makes it suitable for office, retail, and light industrial applications where consistent label printing is necessary.

Specifications

Printer Type Label Printer
Model TLP 2844-Z (284Z-10401-0001)
Type Label Printer
Technology Thermal
Output Type Black & White
Connectivity Serial (RS-232), Parallel (IEEE 1284), USB 1.0/1.1, DB9
MPN 284Z-10401-0001
Form Factor Desktop, Point of Sale
Max Resolution (Bw) 203DPI
Black Print Speed 102mm/Sec
Print method Thermal Transfer
Print resolution 203 dpi (8 dots/mm)
Maximum print width 4.09 inches (104 mm)
Maximum print speed 6 inches per second (152 mm/sec)
Interfaces Serial, Parallel, USB
Media types Continuous, die-cut, black mark, fan-fold
Media width 0.79 to 4.65 inches (20 to 118 mm)
Media thickness 0.00236 to 0.01 inches (0.06 to 0.25 mm)
Ribbon type Wax, wax/resin
Ribbon width 1.6 to 4.33 inches (40 to 110 mm)
Ribbon length Up to 450 meters
Memory 4 MB Flash, 8 MB DRAM
Dimensions 11.3 x 8.9 x 7.1 inches (287 x 226 x 181 mm)
Weight About 10 lbs (4.5 kg)
Operating temperature 40°F to 104°F (5°C to 40°C)
Power supply External, 100-240V, 50/60 Hz
Emulations ZPL, EPL

Key Advantages

The Zebra TLP 2884-Z offers durable thermal transfer printing which ensures long-lasting labels resistant to smudging and fading.

Its compact build saves valuable workspace without sacrificing printing capacity.

The printer supports multiple connectivity options, increasing compatibility with various systems.

With its 203 dpi resolution, barcode quality and label clarity are maintained at a high technical standard.

User-friendly design and easy ribbon/media loading minimize downtime and simplify maintenance.

It is cost-effective for small to medium printing volumes while providing reliable performance.

Limitations

The print speed of up to 6 inches per second may not suffice for very high-volume industrial environments.

It only supports a maximum print resolution of 203 dpi, limiting suitability for applications requiring higher detail.

The printer lacks modern network connectivity options such as Ethernet or Wi-Fi, restricting integration in networked office ecosystems.

Its design is somewhat dated, with fewer advanced software features compared to newer models.

The model does not support direct thermal printing, limiting media options.

Spare parts and consumables may be less readily available due to the device’s age.

FAQ

The Zebra TLP 2884-Z uses thermal transfer technology, which requires a ribbon to print durable images on label media.

It has a maximum print resolution of 203 dpi (dots per inch).

No, it primarily supports serial, parallel, and USB connections but does not include built-in Ethernet or Wi-Fi.

No, this model has been discontinued.

It is typically used for office, retail, and light industrial barcode label printing needs.

No, the TLP 2884-Z only supports thermal transfer printing using ribbon media.

It includes serial, parallel, and USB interfaces for connectivity.
