Zebra Tlp 2844-z
Brand | Zebra 2008 |
Model | 284Z-10400-0001 |
Released Year | 2008 |
Type | Printers |
Printing Technology | Thermal transfer |
Status | Discontinued |
Quick view
Overview
The Zebra TLP 2844-Z is a compact thermal transfer printer designed for high-quality label printing with a print resolution of 203 dpi. It supports a maximum print width of 2.83 inches and a maximum print speed of up to 4 inches per second. The printer uses a flat, two-button user interface with LED indicators for easy operation. It includes EPL and ZPL programming language compatibility for flexible integration into various systems. Connectivity options include parallel and serial ports, ensuring adaptability in older office setups. The device supports roll-fed media with a maximum roll diameter of 5 inches, making it suitable for small to medium volume label printing tasks.
Specifications
MPN | 284Z-10400-0001 |
UPC | 0000004462279 |
Model | Zebra TLP 2844-Z |
Technology | Thermal |
Connectivity | Serial (RS-232), Ethernet (RJ-45), USB 2.0 |
Output Type | Black & White |
Type | Label Printer |
Black Print Speed | 102mm/Sec |
Extend Printer Technology | Direct Thermal / Thermal Transfer |
Installed RAM | 8MB |
Data Link Protocol | Ethernet |
Computer Operating System | Microsoft Windows 2000, Microsoft Windows Millennium Edition, Microsoft Windows 95 |
Form Factor | Desktop, Point of Sale |
MAX Media Size | Roll (10.4cm) |
Networking Type | Print Server |
Media Type | Roll-fed labels and tags |
MAX Resolution (Bw) | 203x203DPI |
Media Capacity | 1 Roll(s) |
Printing Technology | Thermal transfer |
Print Resolution | 203 dpi |
Maximum Print Width | 2.83 inches (72 mm) |
Maximum Print Speed | Up to 4 inches per second |
Maximum Media Roll Diameter | 5 inches (127 mm) |
Interface | Parallel, Serial |
Programming Languages Supported | EPL, ZPL |
User Interface | Two-button with LED indicators |
Dimensions (W x D x H) | 6.9 x 8.1 x 5.0 inches (175 x 205 x 128 mm) |
Weight | Approx. 3 kg |
Power Supply | External power supply, 24V DC |
Operating Temperature | 5°C to 40°C (41°F to 104°F) |
Storage Temperature | -40°C to 60°C (-40°F to 140°F) |
Images
Key Advantages
The TLP 2844-Z features a compact footprint, making it ideal for limited desk space environments. Its thermal transfer printing method ensures durable and long-lasting labels resistant to smudging and fading. The printer offers fast print speeds up to 4 inches per second, improving productivity for high-volume tasks. It maintains compatibility with standard label design languages (EPL & ZPL), enhancing flexibility in label design and system integration. Easy media loading design reduces downtime during operations. The rugged build quality provides reliable performance under continuous office use.
Limitations
The TLP 2844-Z's maximum print resolution (203 dpi) is lower compared to newer models, which may not be suitable for printing very detailed images or small barcodes. It lacks modern connectivity options such as USB or Ethernet, limiting integration in contemporary network environments. The printer's maximum print width (2.83 inches) restricts it to smaller label sizes only. The build is more oriented toward desktop use and is not recommended for industrial-scale printing. It does not natively support wireless printing capabilities. Firmware and driver support have become limited due to its age and discontinuation.
FAQ
What type of printing technology does the Zebra TLP 2844-Z use?
The Zebra TLP 2844-Z uses thermal transfer printing technology, which transfers ink from a ribbon onto a label to produce durable prints.
What is the maximum print resolution of the TLP 2844-Z?
The maximum print resolution is 203 dots per inch (dpi).
Which connectivity options are available on the Zebra TLP 2844-Z?
It includes parallel and serial interface ports for connectivity.
Can the ZPL and EPL programming languages be used with the TLP 2844-Z?
Yes, the printer supports both ZPL and EPL label programming languages.
What maximum label width can the TLP 2844-Z handle?
The printer can handle labels up to 2.83 inches wide.
Is the Zebra TLP 2844-Z still in production?
No, the TLP 2844-Z has been discontinued and is no longer in production.
What types of media can be used with the TLP 2844-Z?
It supports roll-fed labels and tags compatible with thermal transfer printing, with a maximum roll diameter of 5 inches.
