Zebra QL220
Brand | Zebra 2007 |
Model | QL220 |
Released Year | 2007 |
Type | Printers |
Printing Technology | Direct Thermal |
Status | Discontinued |
Quick view
Overview
The Zebra QL220 is a portable direct thermal label printer designed for mobile printing needs in office and field environments. It supports a maximum print width of 2 inches and delivers fast print speeds up to 2 inches per second, optimizing efficiency in label printing tasks. The device employs direct thermal technology, which eliminates the need for ink or toner, relying instead on heat-sensitive label materials. Connectivity options include IrDA infrared for wireless communication, allowing mobile device pairing, and a proprietary serial interface. The printer is powered by rechargeable batteries enabling extended use in remote scenarios. Its compact size and lightweight design facilitate easy portability without sacrificing print performance.
Specifications
Model | QL220 |
Modified Item | No |
Custom Bundle | No |
Type | Label Printer |
Non-Domestic Product | No |
Connectivity | Infrared (IrDA), Serial interface |
Output Type | Black & White |
Technology | Thermal |
MPN | Q2B-LUBB0000-00 |
UPC | Does not apply |
Release Year | 2007 |
Printing Technology | Direct Thermal |
Max Print Width | 2 inches (54 mm) |
Print Resolution | 203 dpi |
Print Speed | Up to 2 inches per second |
Power Source | Rechargeable Battery |
Weight | Approximately 1.5 lbs (0.68 kg) |
Dimensions | 5.6 x 3.2 x 2.4 inches (142 x 81 x 61 mm) |
Media Type | Thermal Labels and Tags |
Discontinued | Yes |
Images
Key Advantages
The Zebra QL220 offers exceptional portability with a sleek, lightweight structure suitable for mobile workforces. Its direct thermal printing technology reduces maintenance costs as it requires no ink or toner cartridges. Fast printing speeds enhance operational efficiency in fast-paced environments. The rechargeable battery provides sufficient runtime for daily printing demands without frequent recharging. Infrared connectivity supports wireless printing, increasing flexibility and convenience on the field. The device features straightforward media loading and user-friendly operation to minimize user training requirements.
Limitations
The QL220 has a relatively narrow print width limited to 2 inches, restricting label size options. Its print resolution is 203 dpi, adequate for standard barcodes but less suitable for high-detail graphics. The infrared wireless connectivity can be less reliable compared to modern Bluetooth or Wi-Fi standards. Battery life may limit continuous printing duration during extended field operations. The device lacks advanced connectivity ports such as USB or Ethernet typical in newer models. Additionally, the printer's firmware and software compatibility are dated due to its release timeframe.
FAQ
What type of printing technology does the Zebra QL220 use?
The Zebra QL220 uses direct thermal printing technology, which does not require ink or toner and uses heat-sensitive labels.
What is the maximum print width of the Zebra QL220?
The maximum print width supported by the Zebra QL220 is 2 inches (approximately 54 mm).
Does the QL220 support wireless connectivity?
Yes, it supports infrared (IrDA) wireless connectivity for communication with compatible devices.
Is the Zebra QL220 still available for purchase?
No, the Zebra QL220 is a discontinued model and is no longer manufactured or sold new.
What is the print resolution of the QL220 printer?
The printer has a print resolution of 203 dots per inch (dpi), suitable for standard barcode and text printing.
What power source does the Zebra QL220 use?
It uses a rechargeable battery pack designed for mobile use.
Can I use the QL220 for high-detail graphic printing?
Due to its 203 dpi resolution, the QL220 is not ideal for printing high-detail graphics but works well for text and barcode labels.
