Zebra LP2844PSAT
Brand | Zebra 2004 |
Model | 120598-001, LP 2844PSAT, AC Adapter, Dispenser, LP2844PSAT |
Released Year | 2004 |
Type | Printers |
Series | Lp |
Status | Discontinued |
Quick view
Overview
The Zebra LP2844PSAT is a compact thermal label printer designed primarily for office and industrial applications requiring fast, reliable label printing. It supports direct thermal printing technology eliminating the need for ink, ribbon, or toner cartridges. The printer offers a maximum print resolution of 203 dpi, suitable for producing barcodes and text with crisp clarity. Connectivity is provided through serial, parallel, and USB interfaces, allowing flexible integration with different computer systems. The device includes a built-in auto-calibration feature to optimize label size detection. Its design supports 4-inch wide label media roll, making it versatile for various labeling needs.
Specifications
Printer type | Direct Thermal |
Resolution | 203 dpi (8 dots/mm) |
Maximum print width | 4.09 inches (104 mm) |
Maximum print speed | 4 inches per second (102 mm/s) |
Media type | Roll-fed, die-cut or continuous labels, tags, or receipt paper |
Media width | Up to 4.25 inches (108 mm) |
Connectivity | Parallel (IEEE 1284), Serial (RS-232), USB 2.0 |
Dimensions | 7.65 x 5.94 x 7.2 inches (194 x 151 x 183 mm) |
Weight | 6.1 pounds (2.76 kg) |
Memory | 1 MB |
Operating temperature | 40° to 105°F (5° to 40°C) |
Power supply | External AC Adapter (LP2844PSAT) |
Barcode symbologies supported | Code 39, Code 128, UPC, EAN, Interleaved 2 of 5, PDF417, DataMatrix |
Input Type | Monochrome |
Output Type | Black & White |
MPN | 120598-001, LP 2844PSAT, AC Adapter, Dispenser, LP2844PSAT |
Supported Paper Size | Max Label Width: 4.25" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | LP2844PSAT |
Features | Peeler, Portable |
Black Print Speed | 4 ips |
Country/Region of Manufacture | United States |
Product Line | Zebra LP |
Images
Key Advantages
The LP2844PSAT excels due to its fast print speed of up to 4 inches per second, boosting productivity in demanding office environments. Its compact and lightweight design facilitates easy desktop placement without occupying much space. It offers broad compatibility with popular barcode symbologies such as Code 39, UPC, EAN, and others, suitable for inventory and shipping labels. The printer’s direct thermal technology reduces maintenance and operational costs by removing the need for ink or toner. Enhanced connectivity options, including USB, parallel, and serial ports, ensure integration flexibility. Additionally, Zebra's reliable build quality provides durability and long service life.
Limitations
One limitation of the LP2844PSAT is its relatively low 203 dpi resolution, which may not suffice for extremely high-definition printing needs. It relies exclusively on direct thermal printing, so printed labels may fade over time when exposed to heat or sunlight. The maximum print width of 4.09 inches restricts usage for larger format labels. The printer does not support wireless connectivity options such as Wi-Fi or Bluetooth natively. Its older interface standards like serial and parallel ports might pose compatibility issues with newer systems. Also, it lacks advanced graphical user interface features found in modern printers, limiting ease of configuration.
FAQ
What type of printing technology does the Zebra LP2844PSAT use?
The Zebra LP2844PSAT uses direct thermal printing technology, which prints by applying heat directly onto specially coated thermal paper.
What is the maximum print resolution of the LP2844PSAT?
The maximum print resolution of the LP2844PSAT is 203 dots per inch (dpi).
Which interface options are available on the LP2844PSAT?
The printer supports USB, serial, and parallel port connections for flexible integration.
Can the LP2844PSAT print in color?
No, the LP2844PSAT is a monochrome thermal printer and prints only in black and white.
What media size does the LP2844PSAT support?
It supports label rolls up to 4.09 inches wide.
Is the Zebra LP2844PSAT still in production?
No, the LP2844PSAT has been discontinued and is no longer in production.
Does the LP2844PSAT require ink or toner to print?
No, because it uses direct thermal printing technology, it does not require ink, toner, or ribbons.
