Zebra LP2824Z
Brand | Zebra 2005 |
Model | 282Z-21100-0001 |
Released Year | 2005 |
Type | Printers |
Status | Discontinued |
Quick view
Overview
The Zebra LP2824Z is a compact, desktop thermal label printer designed for office and retail environments. It utilizes direct thermal printing technology, allowing for quick and quiet label production without the need for ink or toner. The device supports a maximum print width of approximately 2.3 inches and printing speeds up to 4 inches per second. Connectivity is typically provided via serial or parallel ports, with some models supporting USB interfaces. The printer accommodates label rolls with a maximum outer diameter of 5 inches, making it suitable for moderate volume printing tasks. Its robust metal frame ensures durability for consistent, long-term use in environments requiring reliable label printing solutions.
The printer's resolution is 203 dpi, providing clear and readable barcode labels and text. It supports multiple barcode symbologies and has built-in memory to store label formats. The LP2824Z is compatible with various Zebra printer languages and software applications, enabling ease of integration into existing workflows. Firmware updates are occasionally released by Zebra to enhance performance and compatibility. Overall, the LP2824Z is designed to efficiently meet needs in shipping, inventory management, and product labeling scenarios.
Specifications
MPN | 282Z-21100-0001 |
UPC | 5052178188818 |
Model | LP2824Z |
Technology | Thermal |
Connectivity | Serial (RS-232), Parallel (IEEE 1284), USB 1.0/1.1 |
Output Type | Black & White |
Type | Label Printer |
Weight | 3.5 lbs (1.59 kg) |
Depth | 8in |
Height | 7in |
Width | 4in |
Platform | PC Products |
Extend Printer Technology | Direct Thermal |
Installed RAM | 8MB |
Computer Operating System | Microsoft Windows XP Home, Microsoft Windows 2000, Microsoft Windows NT, Microsoft Windows 98, Microsoft Windows 95 |
Form Factor | Point of Sale |
Networking Type | Print Server (Optional) |
Media Type | Roll-fed thermal labels and tags |
Max Resolution (Bw) | 203DPI |
Max Media Size | Roll (5.8cm) |
Black Print Speed | 4 Ips |
Media Capacity | 1 Roll(s) |
Printer Type | Direct Thermal Desktop Printer |
Print Resolution | 203 dpi (8 dots/mm) |
Maximum Print Width | 2.2 inches (56 mm) |
Maximum Print Speed | 4 inches per second (102 mm/s) |
Media Width | 0.75 to 2.36 inches (19 to 60 mm) |
Max Media Roll Diameter | 5 inches (127 mm) |
Memory | 1 MB Flash, 2 MB SDRAM |
Communication Interface | Serial and parallel port; USB optional |
Dimensions (WxHxD) | 6.5 x 5 x 8 inches (165 x 127 x 203 mm) |
Power | External AC adapter (110-240 V) |
Supported Barcodes | Code 39, Code 128, EAN-13, UPC-A, UPC-E, Interleaved 2 of 5, and others |
Operating Systems | Windows, Mac OS, and Linux via drivers |
Accessories | Label peelers, cutters, external rewinders (optional) |
Images
Key Advantages
The Zebra LP2824Z offers highly reliable direct thermal printing technology that requires no ink or toner, minimizing operational costs. Its compact design makes it ideal for office and retail spaces with limited space. The printer supports a fast print speed, enabling efficient label production and reducing wait times. It offers robust build quality with a metal frame that provides durability over extended periods of frequent use. The device supports multiple connectivity options, allowing versatile integration into existing systems. Additionally, its compatibility with common label formats and barcode symbologies simplifies deployment in various labeling applications.
Limitations
One limitation of the Zebra LP2824Z is its relatively low print resolution at 203 dpi, which may not suffice for highly detailed graphics or fine text. The printer uses direct thermal technology, which generally produces labels that can fade over time when exposed to heat or sunlight, limiting longevity. Limited connectivity options in some models may restrict modern interface flexibility, as USB was not standard in all variants. The maximum label width restricts the printer to smaller label sizes, potentially unsuitable for larger format labeling needs. Its discontinued status means official support and firmware updates may be limited or unavailable. Also, the device may lack advanced networking capabilities found in newer label printers.
FAQ
What printing technology does the Zebra LP2824Z use?
The Zebra LP2824Z utilizes direct thermal printing technology, which prints by applying heat to chemically treated paper, eliminating the need for ink or toner.
What is the maximum print width of the LP2824Z?
The maximum print width supported by the Zebra LP2824Z is approximately 2.3 inches (58 mm).
Which connectivity options are available for the LP2824Z?
The printer commonly supports serial and parallel interfaces; some models may include USB connectivity.
Is the Zebra LP2824Z still supported by the manufacturer?
No, the LP2824Z is a discontinued model, and Zebra no longer provides official support or firmware updates.
What label sizes can the LP2824Z handle?
It accommodates label rolls with a maximum outer diameter of 5 inches and supports widths up to about 2.3 inches.
Does the LP2824Z support color printing?
No, the LP2824Z is a monochrome direct thermal printer and does not support color printing.
What industries commonly use the Zebra LP2824Z printer?
It is widely used in retail, healthcare, manufacturing, and shipping industries for barcode and shipping label printing.
