Zebra GX430T
Brand | Zebra 2010 |
Model | GX43-100410-000, Ethernet Network, Tag, Barcode, Shipping |
Released Year | 2010 |
Type | Printers |
Series | Gx |
Status | Discontinued |
Quick view
Overview
The Zebra GX430T is a thermal transfer printer designed primarily for barcode, tag, and shipping label printing applications. It employs thermal transfer and direct thermal printing technologies to allow flexible media usage. The printer offers a high resolution of 300 dpi providing sharp and clear printing ideal for detailed barcodes and graphics. Equipped with an Ethernet network interface, the GX430T supports seamless integration into office networks allowing efficient and centralized label printing. The device supports multiple media widths and thicknesses, accommodating a wide range of label types and sizes. It features a print speed of up to 4 inches per second, balancing quality and performance for various business needs.
Specifications
Input Type | Monochrome |
Output Type | Black & White |
Memory | 8 MB SDRAM, 4 MB Flash |
MPN | GX43-100410-000, Ethernet Network, Tag, Barcode, Shipping |
Supported Paper Size | Max Label Width: 4.25" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 300 x 300 DPI |
Model | GX430T |
Connectivity | Ethernet 10/100 Mbps, USB 2.0, Serial RS-232C |
Features | Networkable, Portable |
Black Print Speed | 4 ips |
Product Line | Zebra GX |
Printer Type | Thermal Transfer and Direct Thermal |
Print Resolution | 300 dpi (12 dots/mm) |
Print Speed | Up to 4 inches per second (102 mm/sec) |
Print Width | 4.09 inches (104 mm) |
Media Type | Labels, Tags, Continuous, Black Mark |
Media Width | 1.00 to 4.5 inches (25.4 to 114 mm) |
Media Roll Diameter | Up to 5.00 inches (127 mm) |
Ribbon Type | Wax, Wax/Resin, Resin |
Ribbon Width | 1.6 to 4.33 inches (40 to 110 mm) |
Ribbon Roll Length | Up to 244 meters (800 feet) |
Power Supply | External, 100-240V AC, 50-60 Hz |
Operating Temperature | 40°F to 104°F (5°C to 40°C) |
Dimensions (W x D x H) | 7.9 x 8.0 x 6.9 inches (200 x 203 x 175 mm) |
Weight | 6.65 lbs (3.02 kg) |
Images
Key Advantages
The Zebra GX430T offers outstanding print resolution at 300 dpi enabling crisp text and clear barcodes. Its dual printing capability supports both thermal transfer and direct thermal printing, enhancing media flexibility. The inclusion of Ethernet connectivity ensures streamlined network integration and multi-user functionality. It supports a broad range of media sizes and types, catering to diverse labeling requirements. The printer is designed with ease of use in mind, featuring simple media loading and user-friendly controls. Its robust construction provides reliable performance suitable for office and industrial environments.
Limitations
The GX430T's print speed of 4 ips may be slower compared to some industrial printers designed for high-volume output. It does not support wireless connectivity options such as Wi-Fi or Bluetooth, limiting mobile use or flexible placement. The printer requires periodic replacement of thermal ribbons for thermal transfer printing, which may add ongoing maintenance costs. Its compatibility is optimized for Zebra's native ZPL programming language; integration with non-Zebra systems might require additional configuration. The device is relatively bulky compared to compact label printers, which could be a consideration for small workspaces. Its discontinued status means limited official support and firmware updates may no longer be available.
FAQ
What printing technologies does the Zebra GX430T support?
The Zebra GX430T supports both thermal transfer and direct thermal printing technologies.
What is the maximum print resolution of the GX430T printer?
The maximum print resolution of the GX430T is 300 dpi, suitable for high-quality barcode and graphic printing.
Does the GX430T support network connectivity?
Yes, the GX430T includes Ethernet network connectivity for integration into office networks.
Is the GX430T printer still supported by Zebra?
The GX430T is discontinued, meaning official support and firmware updates may no longer be provided.
What types of media can the GX430T print on?
The printer supports a variety of media including tags, labels, and shipping barcode media in different sizes and thicknesses.
What is the print speed of the Zebra GX430T printer?
The GX430T can print at speeds of up to 4 inches per second.
Does the GX430T have wireless connectivity options?
No, the GX430T does not support wireless connectivity like Wi-Fi or Bluetooth.
