Zebra GX430D
Brand | Zebra 2014 |
Model | GX43-202510-00AK |
Released Year | 2014 |
Type | Printers |
Series | Label maker |
Status | Active |
Quick view
Overview
The Zebra GX430D is a direct thermal desktop label printer, engineered for high-resolution printing at 300 dpi, delivering sharp and clear labels ideal for barcode applications.
Equipped with a print speed up to 4 inches per second, it balances efficiency and precision for office electronics and retail environments.
This model supports a variety of media types including labels, tags, and receipt stock with widths up to 4.25 inches, enhancing versatility across labeling needs.
Connectivity options include USB and serial ports, with optional Ethernet and wireless modules available, ensuring seamless integration with existing systems.
The printer features a durable metal frame construction that supports long-term reliability and minimal downtime.
Zebra’s printer language options such as ZPL and EPL support ease in label design and compatibility with various software solutions.
Specifications
Print Technology | Direct Thermal |
Print Resolution | 300 dpi (12 dots/mm) |
Maximum Print Speed | 4 inches per second (102 mm/s) |
Maximum Print Width | 4.16 inches (106 mm) |
Media Types | Labels and Tags |
Media Width Range | 0.75 inches to 4.25 inches (19 mm to 108 mm) |
Connectivity Interfaces | USB 2.0, Serial (RS-232), Optional Ethernet, Optional Wireless |
Dimensions (W x D x H) | 7.7 x 8.5 x 6.5 inches (196 x 216 x 165 mm) |
Weight | 5.9 lbs (2.7 kg) |
Printer Languages | ZPL, EPL |
Power Supply | External power supply, 100–240 VAC |
Operating Temperature | 41°F to 104°F (5°C to 40°C) |
Memory | 8 MB SDRAM; 4 MB Flash |
Status Indicators | LED indicators for error, pause, and power |
Frame Material | Metal |
Input Type | Monochrome |
Output Type | Black & White |
MPN | GX43-202510-00AK |
Max. Resolution | 300 DPI |
Supported Paper Size | Up to 4 inches wide |
Type | Label Printer |
Printer Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 300 x 300 DPI |
Supported Printing Sizes | Up to 4 Inches Wide |
Model | GX430D |
Connectivity | Parallel (IEEE 1284), Serial (RS-232), USB 2.0 |
Features | Compact - 300 DPI |
Black Print Speed | 6 IPS |
Product Line | Zebra Label Maker |
Images
Key Advantages
High-resolution 300 dpi printing for crisp barcode and text clarity enhances label readability.
Compact desktop footprint suitable for limited office space without sacrificing performance.
Fast print speed of up to 4 inches per second boosts productivity for moderate label volumes.
Wide media compatibility allows use of diverse label types catering to different application requirements.
Robust metal frame ensures durability and stable operation over extended periods.
Flexible connectivity options improve integration possibilities in various network environments.
Limitations
As a direct thermal printer, labels may fade over time when exposed to heat or light, limiting longevity.
No built-in cutter, potentially requiring manual label separation depending on media used.
Limited advanced connectivity options on base models, with some requiring optional accessories to enable wireless networking.
Print width capped at 4.25 inches may not suit wider label requirements.
High print resolution comes at a slight trade-off in maximum print speed compared to lower dpi models.
The device is not designed for heavy industrial use, possibly limiting application in extremely high-volume environments.
FAQ
What type of printing technology does the Zebra GX430D use?
The Zebra GX430D uses direct thermal printing technology, which uses heat-sensitive media and no ink or ribbons.
What is the maximum print resolution of the GX430D?
The printer delivers a sharp print resolution of 300 dpi, suitable for detailed barcode and text printing.
Can the GX430D connect to wireless networks?
By default, it includes USB and serial interfaces, but wireless connectivity is available as an optional add-on.
What media widths are supported by the GX430D printer?
It supports media widths up to 4.25 inches, making it compatible with a wide range of label sizes.
Is the Zebra GX430D suitable for industrial labeling environments?
While robust and reliable, the GX430D is primarily designed for office and light industrial use, not for high-volume heavy industrial applications.
Does the GX430D come with a cutter for labels?
The standard model does not include a built-in cutter; users may need to separate labels manually or use external cutting devices.
What printer languages does the GX430D support?
It supports Zebra's ZPL and EPL programming languages, compatible with various label design software.
