SATO Nato pw4nx image

SATO Nato pw4nx

Quick information
Brand SATO 1998
Model Nato pw4nx
Released Year 1998
Type Printers
Series Pw4nx
Status Discontinued
Quick view
Full specs Images FAQ

Overview

The SATO Nato PW4NX is a compact industrial printer primarily designed for office and industrial labeling applications.

It utilizes thermal transfer and direct thermal printing technologies to deliver high-quality barcode labels and tags.

Featuring a print resolution of 203 dpi, the PW4NX balances crisp print quality with fast throughput.

The printer supports multiple interface options such as serial and parallel ports, ensuring flexible connectivity with various host systems.

Its build includes durable components for reliable operation in medium-duty environments.

The device is equipped with a straightforward ribbon loading mechanism and a user-friendly control panel for ease of use and maintenance.

Specifications

Input Type Monochrome
Output Type Black & White
Memory Standard 256 KB RAM, 256 KB Flash ROM
MPN Sato Nato PW4NX
Type Label Printer
Technology Thermal
Maximum Resolution 203 x 203 DPI
Manufacturer Warranty 1 Month
Model Sato Nato PW4NX
Connectivity Bluetooth, Wireless
Features Networkable, Portable
Black Print Speed 60 ppm
Country/Region of Manufacture Vietnam
Product Line Sato PW4NX
UPC n/a
Printer type Thermal transfer and direct thermal
Print resolution 203 dpi (8 dots/mm)
Maximum print speed 4 inches per second (approx. 100 mm/s)
Print width 4.1 inches (104 mm)
Media types Labels, tags
Media width 1 to 4.4 inches (25 to 112 mm)
Interfaces RS-232 serial, Parallel port
Dimensions (W x D x H) 310 x 290 x 220 mm
Weight Approx. 6.5 kg
Power supply AC 100-240V, 50/60 Hz
Control panel LED indicators and control buttons
Ribbon type Wax, wax/resin ribbons
Operating temperature 5°C to 40°C
Storage temperature -20°C to 60°C

Key Advantages

The SATO PW4NX offers reliable printing performance suitable for diverse labeling needs.

Its compact design saves space in office and manufacturing settings.

Multiple connectivity options enhance device integration with legacy systems.

The printer supports standard label sizes and various media types, increasing versatility.

Ease of use through intuitive controls reduces operator training time.

Durable construction enables consistent operation in moderate industrial environments.

Limitations

Print resolution is limited to 203 dpi, which might not meet requirements for ultra-fine or graphical labels.

No built-in network connectivity, relying on serial and parallel ports, which are increasingly obsolete.

Limited memory capacity restricts the size and complexity of label formats stored.

Relatively slower print speed compared to modern counterparts affects high-volume operations.

Lack of advanced software compatibility may limit integration with current label design systems.

Discontinued support and scarcity of replacement parts can pose maintenance challenges.
