Zebra 140XiIII Plus
Brand | Zebra 2011 |
Model | 140-741-00000 |
Released Year | 2011 |
Type | Printers |
Series | Xi |
Status | Discontinued |
Quick view
Overview
The Zebra 140XiIII Plus is an industrial-grade thermal barcode printer known for its robust design and high-performance capabilities. It operates with a direct thermal and thermal transfer printing method, supporting print resolutions of 203 dpi or 300 dpi for sharp barcode quality. The device is equipped with a 32-bit RISC processor for efficient data processing and rapid print speeds up to 6 inches per second (203 dpi). Connectivity options include serial, parallel, and USB interfaces with optional Ethernet, allowing versatile integration in industrial environments. The printer supports a wide variety of media types and sizes with an adjustable label width up to 4.09 inches, making it suitable for diverse labeling applications. Its durable metal frame and advanced firmware promote longevity and reliable operation in demanding conditions.
Specifications
Printer Type | Industrial Thermal Transfer and Direct Thermal Printer |
Print Resolution | 203 dpi (8 dots/mm), 300 dpi (12 dots/mm) |
Max Print Speed | Up to 6 inches per second (203 dpi), 4 inches per second (300 dpi) |
Max Print Width | 4.09 inches (104 mm) |
Processor | 32-bit RISC Processor |
Memory | 16 MB |
Media Type | Roll-fed, die-cut, continuous, fan-fold, tags |
Media Width | 0.79 inch to 4.52 inches (20 mm to 115 mm) |
Media Thickness | 0.0025 to 0.01 inch (0.063 to 0.254 mm) |
Interfaces | Serial RS-232, Parallel, USB 2.0; optional Ethernet |
Dimensions | 10.6 x 16.7 x 14.5 inches (269 x 423 x 368 mm) |
Weight | Approximately 21.6 lbs (9.8 kg) |
Firmware | ZPL II (Zebra Programming Language) |
Power Supply | 100-240 V AC, 50-60 Hz |
Operating Temperature | 40°F to 104°F (5°C to 40°C) |
Storage Temperature | -40°F to 140°F (-40°C to 60°C) |
Input Type | Monochrome |
Output Type | Black & White |
Custom Bundle | No |
MPN | 140-741-00000 |
Supported Paper Size | Max. Label Width: 5.51" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | 140XiIII Plus |
Connectivity | Ethernet (RJ-45), Serial (RS-232), USB 2.0 |
Features | Networkable |
Black Print Speed | 12 ips |
Product Line | Zebra Xi |
UPC | Does not apply |
Images
Key Advantages
The 140XiIII Plus excels in durable industrial applications due to its rugged metal housing. It offers fast printing speeds that improve productivity in high-volume environments. The printer supports multiple connectivity protocols, enhancing its compatibility with existing network infrastructures. Its high print resolution options ensure crisp barcode readability critical for logistics and manufacturing. The device's adjustable media handling accommodates a broad range of label sizes and types. Additionally, Zebra’s programming language and tools facilitate easy integration and customization for complex labeling needs.
Limitations
The 140XiIII Plus, being an older model, may lack support for some modern connectivity standards like wireless or Bluetooth out of the box. Its physical size is relatively large compared to newer compact printers, requiring more space. The firmware updates and technical support might be limited due to its age. It consumes more power compared to more recent energy-efficient models. Replacement parts can be harder to source since it's considered a legacy product. The operating noise level is higher, which might not be suitable for quieter office environments.
FAQ
What printing technologies does the Zebra 140XiIII Plus support?
It supports both thermal transfer and direct thermal printing technologies.
What is the maximum print width of the 140XiIII Plus?
The maximum print width is approximately 4.09 inches (104 mm).
Is the 140XiIII Plus still supported by Zebra?
The model has been discontinued and is considered legacy, so official support is limited.
Which connectivity options are available for this printer?
Standard interfaces include serial, parallel, USB, with optional Ethernet connectivity.
Can this printer handle high-volume industrial printing?
Yes, it is designed for industrial environments and high-volume label printing.
Are replacement parts readily available for the 140XiIII Plus?
Parts availability can be limited due to the model's discontinued status.
What resolutions are supported for printing?
Print resolutions of 203 dpi and 300 dpi are supported depending on the configuration.
