BIXOLON XD5 Series image

BIXOLON XD5 Series

Quick information
Brand BIXOLON 2016
Model XD5 Series
Released Year 2016
Type Printers
Series Xd5 series
Status Active
Quick view
Full specs Images

Overview

The BIXOLON XD5 Series is a line of office-focused high-performance label printers engineered for dependable and efficient printing tasks. It supports thermal transfer and direct thermal printing technologies, allowing for versatile application in label printing. The printer series features a 203 dpi resolution, balancing sharpness and speed suitable for various business needs. Connectivity options include USB and optional Ethernet interfaces, providing flexible integration with office networks. The XD5 Series accommodates media widths from 25.4mm to 108mm, compatible with multiple label sizes and types. Its design incorporates user-friendly operation with a compact footprint ideal for desktop placement in office environments.

Specifications

Supported Paper Size Label 4"x6", Labels any size
Model XD5 Series
Maximum Resolution 203 x 203 DPI
Country/Region of Manufacture Korea, Republic of
Black Print Speed 7 IPS
Product Line Bixolon XD5 Series
Input Type Monochrome
Connectivity USB 2.0 (Standard), Ethernet (Optional)
Type Label Printer
Output Type Black & White
Technology Direct Thermal Transfer
MPN XD5-40dK
Manufacturer Warranty 2 years
UPC Does not apply
Print Technology Thermal Transfer / Direct Thermal
Print Resolution 203 dpi (8 dots/mm)
Max Print Speed 152 mm/s (6 inches per second)
Max Print Width 108 mm (4.25 inches)
Media Width 25.4 mm to 108 mm (1 inch to 4.25 inches)
Media Types Labels, Tags, Continuous, Black Mark, Gap
Memory 8 MB SDRAM, 4 MB Flash
Processor 32-bit RISC microprocessor
Display LCD with 6 buttons
Dimensions (W x D x H) 230 mm x 204 mm x 151 mm
Weight Approx. 2.5 kg
Operating Systems Windows, Linux, Mac OS (via drivers)
Emulations BIXOLON SLCS, ZPL-II, EPL2
Power External power supply, 100-240V AC
Fonts Standard scalable and bitmap fonts

Key Advantages

The XD5 Series offers high print speeds up to 6 inches per second, improving office productivity. Its dual printing methods (thermal transfer and direct thermal) enhance versatility for different labeling requirements. The printer provides user-friendly operation with intuitive LCD display and button controls. Robust media compatibility supports a wide range of labels, tags, and ribbons for diverse applications. Compact design with energy-efficient operation suits modern office spaces. Reliable build quality ensures long-term use in frequent printing scenarios.

Limitations

The print resolution of 203 dpi may limit the detail for very small or fine barcode printing. Absence of built-in wireless connectivity requires external adapters for Wi-Fi support. Limited native font selection might require additional font download for custom text. The maximum media width constraint restricts very large label printing needs. It may lack some advanced security features expected in higher-end commercial printers. The printer's interface options are basic compared to more modern smart printers with touchscreen controls.

FAQ

The XD5 Series supports both thermal transfer and direct thermal printing methods for flexibility in label applications.

Standard connectivity includes USB 2.0, with optional Ethernet available for network integration.

The maximum print speed is 6 inches per second, enabling efficient label production.

It supports media widths ranging from 25.4mm (1 inch) to 108mm (4.25 inches), accommodating various label sizes.

Yes, the printer is suited for barcode label printing with 203 dpi resolution suitable for most standard barcode applications.

Wireless connectivity is not built-in but can be added using external wireless adapters.

As of now, the XD5 Series is not discontinued and remains available for purchase.
