BIXOLON SRP-770III
Brand | BIXOLON 2012 |
Model | SRP-770iii-303-UPS |
Released Year | 2012 |
Type | Printers |
Series | Srp |
Status | Active |
Quick view
Overview
The BIXOLON SRP-770III is a high-performance POS thermal printer designed primarily for retail and hospitality applications. It supports 203 dpi resolution thermal line printing which ensures clear and sharp printouts suitable for receipts, tickets, and labels. Printing speed reaches up to 300 mm per second, significantly reducing wait times during transactions. The printer supports various interfaces including USB, Serial, and Ethernet, providing connectivity flexibility for diverse system environments. Paper width supports standard 80mm rolls and easy drop-in loading technology is implemented for fast media replacement. The printer firmware supports ESC/POS command system ensuring compatibility with many POS software solutions.
The device incorporates a durable print head with a life expectancy of approximately 150 km of printed paper, ideal for high-volume usage scenarios. It also supports various barcode types as well as 1D and 2D symbologies for versatile business needs. Additionally, it features a compact design with configurable cutter options (full or partial cut) to enhance efficiency in daily operations.
Specifications
Black Print Speed | 5 IPS |
Connectivity | Parallel (IEEE 1284) |
Features | Desktop |
Input Type | Monochrome |
MPN | SRP-770iii-303-UPS |
Maximum Resolution | 203 x 203 DPI |
Memory | 64 KB Flash ROM, 16 KB SDRAM |
Model | SRP-770III |
Output Type | Black & White |
Product Line | Bixolon SRP |
Scanning Resolution | 200x200 DPI |
Supported Paper Size | Up to 4 in. Wide |
Technology | Thermal |
Type | Label Printer |
Platform | NA |
UPC | Do Not Apply |
Printing Method | Thermal Line Printing |
Print Speed | Up to 300 mm/sec |
Resolution | 203 dpi |
Print Width | 72 mm |
Paper Width | 80 mm |
Interface Options | USB, Serial (RS-232), Ethernet |
Command System | ESC/POS Compatible |
Print Head Life | Approx. 150 km |
Cutter | Full and Partial Cutter |
Power Supply | AC Adapter 24V |
Dimensions | 145 x 195 x 148 mm (W x D x H) |
Weight | Approx. 1.5 kg |
Barcode Support | 1D and 2D Barcodes (QR Code, PDF417, MaxiCode, etc.) |
Operating Temperature | 0°C to 45°C |
Certifications | FCC, CE, UL, CCC |
Images
Key Advantages
The BIXOLON SRP-770III offers exceptional print speed of up to 300 mm/s, improving transaction throughput effectively. It has a high-resolution 203 dpi thermal print head that produces crisp and professional outputs. The printer supports multiple interface options such as USB, Serial, and Ethernet, making it adaptable to various POS systems. Its easy paper loading mechanism reduces downtime and simplifies maintenance. The durability of the print head extends device longevity under intensive usage conditions. The inclusion of various barcode printing capabilities increases its versatility for different business requirements.
Limitations
While the SRP-770III excels in speed and reliability, it supports only monochrome thermal printing and does not provide color output, limiting its usage to typical receipt formats. Some advanced connectivity options like Bluetooth or Wi-Fi are not natively supported and would require additional modules. The printer supports 80mm paper width predominantly, limiting flexibility for other media sizes. It also lacks an LCD display which could provide easier local configuration and troubleshooting. Noise levels during printing are standard but could be higher in certain environments. Firmware updates require connection to a PC and are not performed wirelessly.
FAQ
What printing speed does the BIXOLON SRP-770III support?
The SRP-770III supports a maximum printing speed of up to 300 mm per second.
Which interfaces are available on the SRP-770III printer?
It offers USB, Serial, and Ethernet interface options for connectivity.
What type of printing technology does the SRP-770III use?
It utilizes thermal line printing technology with a resolution of 203 dpi.
Can the SRP-770III print barcodes and 2D codes?
Yes, it supports 1D and 2D barcode printing including popular symbologies.
Is the SRP-770III suitable for high-volume printing environments?
Yes, with a print head lifespan of around 150 km of paper, it is ideal for high-volume usage.
Does the SRP-770III support wireless connectivity?
No, wireless options such as Wi-Fi or Bluetooth are not built-in and require additional modules.
What paper sizes does the BIXOLON SRP-770III support?
It mainly supports 80mm wide thermal paper rolls, standard for POS receipt printing.
