Panasonic TH-86SQE1WA

Quick information
Brand Panasonic 2023
Model TH-86SQE1WA
Released Year 2023
Type TV
Screen Size 86"
Resolution 3840 x 2160 (4K UHD)
Refresh Rate 60 Hz
Display Technology LED
Status Active
Quick view

Overview

The Panasonic TH-86SQE1WA is a large-format professional display designed for high-quality 4K UHD video presentations. It features a direct LED backlight panel with a native resolution of 3840 x 2160 pixels, providing vivid and accurate color reproduction essential for professional environments. The display supports 10-bit color depth and HDR10+ for enhanced contrast and dynamic range.

Connectivity options include multiple HDMI 2.0 inputs, DisplayPort, USB ports for media playback, and LAN ports for network control and digital signage applications. The unit runs on a proprietary smart platform optimized for robust performance, with support for various content management systems through embedded software.

Built with a commercial-grade design, the screen supports 24/7 operation and has a wide viewing angle to ensure consistent image quality from different perspectives. It also incorporates advanced cooling technology to maintain performance stability during intensive use.

Specifications

Smart TV Features Internet Browsing, Internet Streaming Interface
Display Technology LED
Screen Size 86"
Maximum Resolution 2160p (4K)
Refresh Rate 60 Hz
Color Black
Model TH-86SQE1WA
MPN TH-86SQE1WA
Features Built-in Speakers, Wall Mountable, Wi-Fi Ready
Audio/Video Inputs DisplayPort, Ethernet, HDMI, USB, VGA D-Sub
UPC 885170391475
Display Size 86 inches
Panel Type IPS LCD with Direct LED backlight
Resolution 3840 x 2160 (4K UHD)
Brightness 500 cd/m²
Contrast Ratio 1200:1
Color Depth 10-bit
HDR Support HDR10+
Viewing Angle 178° horizontal / 178° vertical
Response Time 8 ms
Operating System Proprietary embedded platform
Connectivity 3x HDMI 2.0, 1x DisplayPort, 3x USB 2.0, 1x RJ45 Ethernet
Audio Output 2x 15W built-in speakers
Power Consumption Approx. 300W
Dimensions (WxHxD) 1926 x 1108 x 86 mm
Weight Approx. 45 kg
Operating Temperature 0°C to 40°C
Compliance CE, RoHS, Energy Star certified
Usage Commercial/Professional signage and presentations

Key Advantages

The TH-86SQE1WA offers an ultra-high-definition 86-inch screen that delivers stunning visual clarity and immersive detail ideal for professional environments.

Its 10-bit color processing and HDR compatibility ensure superior image quality with vibrant colors and deep blacks.

Extended connectivity options including multiple HDMI, DisplayPort, and USB ports allow flexible integration with diverse multimedia sources.

Designed for 24/7 commercial use, the display is built for durability and reliable long-term operation with advanced heat management.

The smart platform embedded in the device supports remote management and versatile content delivery, making it suitable for digital signage and corporate applications.

The wide viewing angle and anti-reflective screen coating enhance visibility and reduce glare in various lighting conditions.

Limitations

The Panasonic TH-86SQE1WA is primarily designed for professional use and may have limited availability in consumer retail markets.

While supporting many connectivity options, it lacks HDMI 2.1 ports, which means it may not fully support the latest high-bandwidth features for gaming or advanced video sources.

Due to its large size and commercial design, the unit is relatively heavy and requires professional installation support.

The built-in smart platform may have limited app availability compared to mainstream consumer smart TV operating systems.

Power consumption is higher than typical consumer TVs, which could increase operating costs in extended usage scenarios.

Replacement parts and accessories might be more expensive or harder to source outside authorized Panasonic service centers.
