Panasonic TH-86SQE1WA
Brand | Panasonic 2023 |
Model | TH-86SQE1WA |
Released Year | 2023 |
Type | TV |
Screen Size | 86" |
Resolution | 3840 x 2160 (4K UHD) |
Refresh Rate | 60 Hz |
Display Technology | LED |
Status | Active |
Quick view
Overview
The Panasonic TH-86SQE1WA is a large-format professional display designed for high-quality 4K UHD video presentations. It features a direct LED backlight panel with a native resolution of 3840 x 2160 pixels, providing vivid and accurate color reproduction essential for professional environments. The display supports 10-bit color depth and HDR10+ for enhanced contrast and dynamic range.
Connectivity options include multiple HDMI 2.0 inputs, DisplayPort, USB ports for media playback, and LAN ports for network control and digital signage applications. The unit runs on a proprietary smart platform optimized for robust performance, with support for various content management systems through embedded software.
Built with a commercial-grade design, the screen supports 24/7 operation and has a wide viewing angle to ensure consistent image quality from different perspectives. It also incorporates advanced cooling technology to maintain performance stability during intensive use.
Specifications
Smart TV Features | Internet Browsing, Internet Streaming Interface |
Display Technology | LED |
Screen Size | 86" |
Maximum Resolution | 2160p (4K) |
Refresh Rate | 60 Hz |
Color | Black |
Model | TH-86SQE1WA |
MPN | TH-86SQE1WA |
Features | Built-in Speakers, Wall Mountable, Wi-Fi Ready |
Audio/Video Inputs | DisplayPort, Ethernet, HDMI, USB, VGA D-Sub |
UPC | 885170391475 |
Display Size | 86 inches |
Panel Type | IPS LCD with Direct LED backlight |
Resolution | 3840 x 2160 (4K UHD) |
Brightness | 500 cd/m² |
Contrast Ratio | 1200:1 |
Color Depth | 10-bit |
HDR Support | HDR10+ |
Viewing Angle | 178° horizontal / 178° vertical |
Response Time | 8 ms |
Operating System | Proprietary embedded platform |
Connectivity | 3x HDMI 2.0, 1x DisplayPort, 3x USB 2.0, 1x RJ45 Ethernet |
Audio Output | 2x 15W built-in speakers |
Power Consumption | Approx. 300W |
Dimensions (WxHxD) | 1926 x 1108 x 86 mm |
Weight | Approx. 45 kg |
Operating Temperature | 0°C to 40°C |
Compliance | CE, RoHS, Energy Star certified |
Usage | Commercial/Professional signage and presentations |
Images
Key Advantages
The TH-86SQE1WA offers an ultra-high-definition 86-inch screen that delivers stunning visual clarity and immersive detail ideal for professional environments.
Its 10-bit color processing and HDR compatibility ensure superior image quality with vibrant colors and deep blacks.
Extended connectivity options including multiple HDMI, DisplayPort, and USB ports allow flexible integration with diverse multimedia sources.
Designed for 24/7 commercial use, the display is built for durability and reliable long-term operation with advanced heat management.
The smart platform embedded in the device supports remote management and versatile content delivery, making it suitable for digital signage and corporate applications.
The wide viewing angle and anti-reflective screen coating enhance visibility and reduce glare in various lighting conditions.
Limitations
The Panasonic TH-86SQE1WA is primarily designed for professional use and may have limited availability in consumer retail markets.
While supporting many connectivity options, it lacks HDMI 2.1 ports, which means it may not fully support the latest high-bandwidth features for gaming or advanced video sources.
Due to its large size and commercial design, the unit is relatively heavy and requires professional installation support.
The built-in smart platform may have limited app availability compared to mainstream consumer smart TV operating systems.
Power consumption is higher than typical consumer TVs, which could increase operating costs in extended usage scenarios.
Replacement parts and accessories might be more expensive or harder to source outside authorized Panasonic service centers.
FAQ
What is the native resolution of the Panasonic TH-86SQE1WA?
The native resolution of the Panasonic TH-86SQE1WA is 3840 x 2160 pixels, which is standard 4K Ultra HD resolution.
Does the TH-86SQE1WA support HDR technology?
Yes, the TH-86SQE1WA supports HDR10+ to provide enhanced contrast and dynamic range for more lifelike images.
Is the Panasonic TH-86SQE1WA suitable for 24/7 operation?
Yes, it is designed as a commercial-grade display to support continuous 24/7 use with reliable performance.
What types of ports are available on the TH-86SQE1WA?
This model includes multiple HDMI 2.0 ports, DisplayPort, USB ports, and LAN Ethernet connectivity for versatile video and network integration.
Can the TH-86SQE1WA be used for digital signage?
Yes, the embedded smart platform and network capabilities make it well-suited for digital signage applications.
Is professional installation required for this Panasonic model?
Due to its large 86-inch size and heavy weight, professional installation is recommended to ensure safety and optimal setup.
Is the TH-86SQE1WA still in production?
As of now, the Panasonic TH-86SQE1WA is not discontinued and remains available for purchase.
