ZTECH ZD620
| Brand | ZTECH 2021 |
| Model | ZD620 |
| Released Year | 2021 |
| Type | Printers |
| Series | ZD620 |
| Item Weight |
|
| Product Dimensions | 6 x 6 x 6 inches |
| Status | Active |
Quick view
Overview
The ZTECH ZD620 is a high-performance desktop barcode label printer designed for office electronics environments. It utilizes thermal transfer and direct thermal printing technologies to deliver high-resolution output at speeds up to 8 inches per second. The device supports multiple connectivity options including USB, Ethernet, and optional Wi-Fi, enabling easy integration into varied IT infrastructures. An advanced processor combined with 512 MB RAM allows efficient printing and quick processing of complex label layouts. It offers a print width of up to 4.09 inches and supports a wide range of media types and sizes, facilitating versatile office and industrial applications. The printer includes an intuitive color touchscreen display for enhanced user control and diagnostics.
Specifications
| Printer type | Thermal transfer and direct thermal |
| Print resolution | 203 dpi standard, optional 300 dpi |
| Print speed | Up to 8 inches per second |
| Max print width | 4.09 inches (104 mm) |
| Memory | 512 MB SDRAM, 256 MB flash |
| Display | 4.3-inch color touchscreen LCD |
| Connectivity | USB 2.0, Ethernet, optional Wi-Fi and Bluetooth |
| Dimensions | 8.7 in W x 8.0 in H x 11.7 in D (221 mm x 203 mm x 297 mm) |
| Weight | Approximately 6.6 lbs (3.0 kg) |
| Media types | Labels, tags, continuous media |
| Ribbon types | Wax, wax/resin, resin (thermal transfer) |
| Operating systems supported | Windows, Mac OS, Linux |
| Power requirements | AC input 100-240V, 50/60 Hz |
| Standards and certifications | FCC Class A, cTUVus, CE, RoHS compliant |
| Compatible Devices | PC |
| Sheet Size |
|
| Maximum Black and White Print Resolution | 203 dpi |
| Warranty Type |
|
| Dual-sided printing | No |
| Max copy resolution black-white | 203 dpi |
| Duplex | Simplex |
| Hardware Interface | Bluetooth |
| Additional Printer functions | Print Only |
| Control Method |
|
| Total USB Ports | 1 |
| UPC |
|
| Printer Ink Type | No Ink |
| Product Dimensions | 6 x 6 x 6 inches |
| Item Weight |
|
| Item model number | ZD620 |
| Date First Available | May 17, 2021 |
| Manufacturer | Ztech |
| Max Input Sheet Capacity | 100 |
| Color Depth | 1 bpp |
| Ink Color | Black |
| Processor Count | 1 |
| Total Ethernet Ports | 1 |
| Package Dimensions | 12.25 x 8.5 x 8.25 inches |
Images
Key Advantages
The ZD620 provides fast print speeds ideal for high-volume office environments. It supports versatile media types with adjustable sensors for different label stocks. Its advanced connectivity options, such as Ethernet and Wi-Fi, promote flexible deployment. The printer’s high resolution of 203 to 300 dpi ensures crisp and professional label outputs. It is designed for user-friendly operation with an intuitive display and simple media loading. Robust build quality and reliability reduce downtime and maintenance efforts.
Limitations
The ZD620 may have higher initial purchase costs compared to basic label printers. Thermal transfer ribbon replacement may add ongoing operational expenses. Some advanced features and connectivity options require optional modules, increasing total cost. The printer requires compatible labels and ribbons, which may limit the choice from third-party vendors. It is predominantly designed for office and light industrial use, less suited for harsh environments. Firmware updates and troubleshooting typically require access to specific technical resources or support.
FAQ
What printing technologies does the ZTECH ZD620 support?
The ZD620 supports both direct thermal and thermal transfer printing methods for versatile label production.
What are the connectivity options available on the ZD620?
Standard connectivity includes USB and Ethernet, with optional support for Wi-Fi and Bluetooth modules.
What is the maximum print resolution of the ZD620 printer?
The printer offers print resolutions of 203 dpi and optional 300 dpi for high-quality label printing.
What is the maximum print width the ZD620 can handle?
The maximum print width supported by the ZD620 is 4.09 inches (104 mm).
Does the ZD620 support a touchscreen interface?
Yes, it features a full-color LCD touchscreen display for easy operation and configuration.
Can the ZD620 be integrated into existing office networks?
Yes, with Ethernet and optional wireless modules, it can be easily integrated into networked environments.
Is the ZTECH ZD620 still available for purchase?
The ZD620 is an active product and not discontinued, available through authorized resellers.
