Zebra Zxp seies 7
Brand | Zebra 2014 |
Model | Z72-000C0000US00 |
Released Year | 2014 |
Type | Printers |
Series | Z |
Printing Technology | Retransfer Dye-Sublimation |
Status | Active |
Quick view
Overview
The Zebra ZXP Series 7 is an advanced card printer designed for high-volume, on-demand card printing needs. It supports high-speed printing up to 190 cards per hour in monochrome mode and 140 cards per hour for full-color print. This model utilizes retransfer printing technology, ensuring superior image quality and durability with edge-to-edge printing capabilities. It integrates seamless smart card encoding options including contact and contactless encoding modules for enhanced security applications. The printer features a robust built-in print head with a resolution of 300 dpi, supporting various card thicknesses from 0.25 mm to 1.0 mm. Its modular design allows customization and easy maintenance, making it a versatile solution for enterprises requiring reliable card issuance.
Specifications
Printing Technology | Retransfer Dye-Sublimation |
Print Speed | Up to 190 cards/hour monochrome, 140 cards/hour full color |
Print Resolution | 300 dpi |
Card Thickness Supported | 0.25 mm to 1.0 mm |
Encoding Options | Contact, contactless, magnetic stripe encoding (optional modules) |
Connectivity | Ethernet (RJ-45), USB 2.0 |
Card Size | CR-80 (3.375" L x 2.125" W) |
Input Hopper Capacity | 100 cards |
Output Hopper Capacity | Up to 100 cards |
Supported Card Materials | PVC, Composite, PET |
Dimensions | 10.4 in. H x 18.5 in. W x 15.5 in. D (264 mm x 470 mm x 393 mm) |
Weight | Approx. 24 kg (53 lbs) |
Display | LCD control panel with menu navigation |
Software Compatibility | Zebra CardStudio, internal drivers for Windows |
Operating System Support | Windows 7, 8, 10 (32-bit and 64-bit) |
Power Supply | 100-240V AC, 50-60 Hz |
Warranty | Limited warranty with extended options available |
MPN | Z72-000C0000US00 |
Country/Region of Manufacture | China |
Product Line | Zebra Z |
Technology | Thermal |
Output Type | Color |
Input Type | Color |
Features | Networkable |
Model | Zebra ZXP Seies 7 |
Type | ID Card Printer |
Supported Paper Size | 7 |
Size Type | Regular |
Images
Key Advantages
The ZXP Series 7 delivers exceptional print speed, making it ideal for large-scale card production. Its retransfer technology offers top-notch image quality with a smooth finish and vibrant colors. The printer supports multiple card encoding options, enabling secure data storage and easy integration with existing card management systems. Its user-friendly interface and LCD control panel facilitate simple operation and maintenance. The modular construction ensures adaptability to future print and encoding requirements. Additionally, compatibility with Zebra's extensive card printer ecosystem and consumables enhances operational flexibility.
Limitations
Although fast, the printer's size and weight may limit portability and require dedicated workspace. The upfront cost for the ZXP Series 7 and its consumables can be higher compared to direct-to-card printers. Certain advanced encoding options may require additional modules, increasing overall system cost. The device may require regular maintenance for print head cleaning and calibration to maintain optimal performance. It is primarily designed for PVC and composite cards, limiting use with other card materials. Some users may find software integration complex depending on existing IT infrastructure.
FAQ
What type of printing technology does the Zebra ZXP Series 7 use?
It uses retransfer printing technology which allows for high-quality edge-to-edge prints with vibrant colors.
What card thicknesses can the ZXP Series 7 handle?
It can print on cards ranging in thickness from 0.25 mm to 1.0 mm.
Does the ZXP Series 7 support smart card encoding?
Yes, it supports contact and contactless smart card encoding options.
What is the printing speed of the ZXP Series 7?
It can print up to 190 monochrome cards per hour and approximately 140 full-color cards per hour.
Is the Zebra ZXP Series 7 still being produced?
No, the model has not been officially discontinued but newer models are available; it is considered currently supported.
What kind of interface does the ZXP Series 7 provide?
It features USB and optional Ethernet connections for flexible integration.
What is the print resolution of the ZXP Series 7?
The printer offers a resolution of 300 dpi for crisp image and text quality.
