Zebra ZT62062-T010100Z
Brand | Zebra 2019 |
Model | ZT62062-T010100Z |
Released Year | 2019 |
Type | Printers |
Series | ZT620 |
Item Weight | 60 pounds |
Status | Active |
Quick view
Overview
The Zebra ZT62062-T010100Z is an industrial thermal transfer and direct thermal printer designed for high-volume labeling applications. It features a rugged metal frame for enhanced durability in harsh environments, supporting print widths up to 6 inches for versatile label sizes. This model utilizes a high-resolution 600 dpi printhead, ensuring crisp and detailed barcode and text output. It includes advanced connectivity options such as USB, serial, Ethernet, and optional wireless modules to integrate seamlessly into enterprise networks. The printer's architecture supports easy media loading and includes a programmable display for operator convenience. Its firmware supports multiple printer languages, facilitating compatibility with various labeling software.
The ZT620 series is tailored for industrial workplaces requiring reliable performance and uptime. The printer supports a large ribbon capacity and adjustable media handling settings to accommodate a wide range of label types and sizes. Additionally, the device features RFID encoding options for enhanced supply chain tracking capabilities. It conforms to various industry standards, ensuring compatibility and security within critical production environments.
Specifications
Print media | Labels |
Max Input Sheet Capacity | 15 |
Sheet Size | 6 inches |
Maximum Black and White Print Resolution | 203 dpi |
Warranty Type | full warranty |
Dual-sided printing | No |
Max copy resolution black-white | 203 dpi |
Duplex | simplex |
Hardware Interface | Bluetooth |
Ink Color | black |
Additional Printer functions | Print Only |
Control Method | Remote |
Series Number | 620 |
Total USB Ports | 1 |
Specific Uses For Product | Point of Sale (POS) Systems, Commercial Use, Manufacturing, Transportation & Logistics, Retail |
Package Dimensions | 23.8 x 20.2 x 18.9 inches |
Item Weight | 60 pounds |
Item model number | ZT62062-T010100Z |
Date First Available | March 28, 2019 |
Manufacturer | Zebra |
Printer Type | Industrial Thermal Transfer / Direct Thermal |
Print Resolution | 600 dpi (23.6 dots/mm) |
Print Width | Up to 6 inches (152 mm) |
Print Speed | Up to 10 inches per second (at 300 dpi model; slower at 600 dpi) |
Processor | Dual-core 1 GHz ARM Cortex-A9 |
Memory | 512 MB SDRAM, 512 MB Flash |
Display | Color 4.3-inch LCD with ZBI 2.0 (Zebra BASIC Interpreter) |
Connectivity | USB 2.0, Serial, Ethernet (10/100), Optional Wi-Fi and Bluetooth |
Media Handling | Adjustable sensors, large roll capacity up to 8 inches OD |
Ribbon Capacity | 450 meters |
Dimensions (W x H x D) | 270 mm x 432 mm x 408 mm |
Weight | Approx. 11.5 kg |
Operating Temperature | 5°C to 40°C |
Compliance | FCC, CE, UL, RoHS |
Optional Features | RFID encoding, Cutter, Peeler, Rewinder |
Images
Key Advantages
The Zebra ZT62062-T010100Z offers high-resolution 600 dpi printing that delivers excellent label quality for small fonts and detailed graphics. Its robust metal construction provides exceptional durability, suitable for industrial environments. The device supports multiple connectivity interfaces which improve integration flexibility across different systems. User-friendly media loading and an intuitive LCD interface streamline operation and reduce downtime. The large media capacity and adjustable sensors enable compatibility with diverse label formats. Additionally, flexible printer language support enhances usability in multilingual and multi-application environments.
Limitations
The high resolution 600 dpi model may print slower compared to lower dpi models, potentially limiting throughput. Being an industrial grade printer, the unit has a larger physical footprint, which may not suit small office spaces. The cost of this high specification printer tends to be higher than desktop alternatives, affecting budget constraints. Some advanced connectivity options may require additional module purchases, impacting total investment. Maintenance may require trained personnel due to the printer's complex mechanism and industrial focus. Firmware updates and software integration can be complex for users unfamiliar with industrial printing systems.
FAQ
What printing technology does the Zebra ZT62062-T010100Z use?
The Zebra ZT62062-T010100Z uses thermal transfer and direct thermal printing technologies.
What is the maximum print resolution of the ZT62062-T010100Z?
This model offers a maximum print resolution of 600 dpi for high-quality output.
Can the ZT62062-T010100Z connect to a network?
Yes, it supports various connectivity options including USB, serial, Ethernet, and optional wireless modules.
Is the Zebra ZT62062-T010100Z suitable for harsh environments?
Yes, it features a rugged metal frame designed for durability in industrial and harsh environments.
What label widths does this printer support?
The printer supports label widths up to 6 inches, accommodating diverse labeling needs.
Does the printer support RFID encoding?
Yes, the ZT620 series offers optional RFID encoding capabilities for enhanced supply chain tracking.
Is the Zebra ZT62062-T010100Z still available in production?
As of now, the ZT620 series continues to be supported and has not been discontinued.
