Zebra Zt410 image

Zebra Zt410

Quick information
Brand Zebra 2015
Model ZT41042-T01A000Z, ZT41042T010000Z
Released Year 2015
Type Printers
Series Z
Status Active
Quick view

Overview

The Zebra ZT410 is an industrial-grade thermal transfer and direct thermal printer built for reliable, high-volume label printing in demanding environments. It features a durable metal frame construction to withstand harsh conditions and continuous use. The printer supports printing widths up to 4.09 inches (104 mm) and resolutions of 203 dpi, 300 dpi, and 600 dpi for flexible label quality needs. Connectivity options include USB, Serial, Ethernet, and optional Wi-Fi, ensuring versatile integration with existing systems. The user interface provides a color LCD screen for easy operation, configuration, and status monitoring. Additionally, the printer supports a wide range of media types including continuous, die-cut, black mark, and notch media for broad applicability in industrial labeling tasks.

Specifications

Input Type Monochrome
Grayscale Depth 8 Bit
Color Depth 8 Bit
Output Type Black & White
Memory 512 MB Flash, 256 MB SDRAM
MPN ZT41042-T01A000Z, ZT41042T010000Z
Supported Paper Size Maximum Label Width: 4.49", A6 (105 x 148 mm)
Type Label Printer
Technology Thermal
Maximum Resolution 203 x 203 DPI
Item Height 12.75
Model Zebra ZT410
Connectivity USB 2.0, Serial RS-232, 10/100 Ethernet, optional Wi-Fi 802.11ac, Bluetooth 4.1
Features Networkable
Scanning Resolution 200x200 DPI
Black Print Speed 14 ips
Product Line Zebra Z
Printer type Industrial thermal transfer and direct thermal printer
Print width Up to 4.09 inches (104 mm)
Print resolution 203 dpi, 300 dpi, 600 dpi (optional)
Print speed Up to 14 ips (inches per second) at 203 dpi
Display 4.3-inch color touch LCD screen
Media types Continuous, die-cut, black mark, notch, tag stock
Media width 0.75 inch to 4.65 inches (19 mm to 118 mm)
Ribbon type Thermal transfer ribbon, ink side in/out, max 450 meters length
Dimensions 10.77 x 17.75 x 12.2 inches (273.5 x 451 x 310 mm)
Weight Around 26 lbs (11.8 kg)
Operating temperature 40°F to 105°F (4°C to 41°C)
Compliance Energy Star certified, RoHS compliant
Power supply External power supply 100-240 VAC, 50-60 Hz

Key Advantages

The ZT410 offers robust metal housing, making it highly durable for industrial environments. It features easy media loading with its clamshell design, minimizing downtime. Multiple resolution options allow users to balance print quality and speed based on their application. The printer supports a variety of connectivity options, enabling flexible deployment across different network setups. Its intuitive LCD interface simplifies configuration and printer management, enhancing user experience. Furthermore, the ZT410 is Energy Star certified, providing energy efficiency benefits.

Limitations

The Zebra ZT410, while flexible, is limited to printing widths up to 4.09 inches, which might not suit applications requiring wider labels. The initial investment cost is higher than standard office printers, making it more suitable for industrial rather than occasional use. The maximum print speed is moderate, and for very high throughput environments, faster models may be preferred. The printer requires specific Zebra-approved media and ribbons to maintain print quality and avoid hardware issues. Replacement parts and maintenance should be handled carefully to avoid invalidating warranty. Its size and weight limit portability and make it best suited for fixed workstation setups.
