Zebra Zt410
Brand | Zebra 2015 |
Model | ZT41042-T01A000Z, ZT41042T010000Z |
Released Year | 2015 |
Type | Printers |
Series | Z |
Status | Active |
Quick view
Overview
The Zebra ZT410 is an industrial-grade thermal transfer and direct thermal printer built for reliable, high-volume label printing in demanding environments. It features a durable metal frame construction to withstand harsh conditions and continuous use. The printer supports printing widths up to 4.09 inches (104 mm) and resolutions of 203 dpi, 300 dpi, and 600 dpi for flexible label quality needs. Connectivity options include USB, Serial, Ethernet, and optional Wi-Fi, ensuring versatile integration with existing systems. The user interface provides a color LCD screen for easy operation, configuration, and status monitoring. Additionally, the printer supports a wide range of media types including continuous, die-cut, black mark, and notch media for broad applicability in industrial labeling tasks.
Specifications
Input Type | Monochrome |
Grayscale Depth | 8 Bit |
Color Depth | 8 Bit |
Output Type | Black & White |
Memory | 512 MB Flash, 256 MB SDRAM |
MPN | ZT41042-T01A000Z, ZT41042T010000Z |
Supported Paper Size | Maximum Label Width: 4.49", A6 (105 x 148 mm) |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Item Height | 12.75 |
Model | Zebra ZT410 |
Connectivity | USB 2.0, Serial RS-232, 10/100 Ethernet, optional Wi-Fi 802.11ac, Bluetooth 4.1 |
Features | Networkable |
Scanning Resolution | 200x200 DPI |
Black Print Speed | 14 ips |
Product Line | Zebra Z |
Printer type | Industrial thermal transfer and direct thermal printer |
Print width | Up to 4.09 inches (104 mm) |
Print resolution | 203 dpi, 300 dpi, 600 dpi (optional) |
Print speed | Up to 14 ips (inches per second) at 203 dpi |
Display | 4.3-inch color touch LCD screen |
Media types | Continuous, die-cut, black mark, notch, tag stock |
Media width | 0.75 inch to 4.65 inches (19 mm to 118 mm) |
Ribbon type | Thermal transfer ribbon, ink side in/out, max 450 meters length |
Dimensions | 10.77 x 17.75 x 12.2 inches (273.5 x 451 x 310 mm) |
Weight | Around 26 lbs (11.8 kg) |
Operating temperature | 40°F to 105°F (4°C to 41°C) |
Compliance | Energy Star certified, RoHS compliant |
Power supply | External power supply 100-240 VAC, 50-60 Hz |
Images
Key Advantages
The ZT410 offers robust metal housing, making it highly durable for industrial environments. It features easy media loading with its clamshell design, minimizing downtime. Multiple resolution options allow users to balance print quality and speed based on their application. The printer supports a variety of connectivity options, enabling flexible deployment across different network setups. Its intuitive LCD interface simplifies configuration and printer management, enhancing user experience. Furthermore, the ZT410 is Energy Star certified, providing energy efficiency benefits.
Limitations
The Zebra ZT410, while flexible, is limited to printing widths up to 4.09 inches, which might not suit applications requiring wider labels. The initial investment cost is higher than standard office printers, making it more suitable for industrial rather than occasional use. The maximum print speed is moderate, and for very high throughput environments, faster models may be preferred. The printer requires specific Zebra-approved media and ribbons to maintain print quality and avoid hardware issues. Replacement parts and maintenance should be handled carefully to avoid invalidating warranty. Its size and weight limit portability and make it best suited for fixed workstation setups.
FAQ
What types of media can the Zebra ZT410 use?
The ZT410 supports various media types including continuous roll, die-cut labels, black mark, and notch media for versatile labeling needs.
What are the connectivity options for the ZT410?
Connectivity options include USB, Serial, 10/100 Ethernet, and optional dual-band Wi-Fi and Bluetooth for network flexibility.
What is the maximum print resolution of the Zebra ZT410?
The printer offers print resolutions of 203 dpi, 300 dpi, and 600 dpi for varying levels of detail.
Is the ZT410 suitable for high-volume industrial printing?
Yes, the ZT410 is designed for industrial applications with durable construction and a duty cycle suitable for high volumes.
Can the Zebra ZT410 be integrated with existing ERP systems?
Yes, with its multiple connectivity options and support for various printer programming languages, it integrates well with ERP and labeling software.
Does the ZT410 have an easy media loading mechanism?
Yes, it features a clamshell design for quick and easy media and ribbon loading, minimizing downtime.
Is the Zebra ZT410 still supported and not discontinued?
The Zebra ZT410 is not discontinued and continues to be supported with firmware updates and service.
