Zebra ZT230
| Brand | Zebra 2015 |
| Model | 305 dpi, Barcode, ZT23043-T01200FZ |
| Released Year | 2015 |
| Type | Printers |
| Status | Discontinued |
Quick view
Overview
The Zebra ZT230 is an industrial-grade barcode printer designed for reliable and efficient label printing in office and industrial environments. It features a thermal transfer and direct thermal printing technology that supports a 305 dpi resolution, ensuring high-quality, crisp barcode and label prints. The device supports a variety of media types and widths, accommodating diverse labeling needs. It integrates USB and Ethernet connectivity for versatile communication and easy integration into existing systems. The printer is equipped with a durable metal frame and a user-friendly LCD interface for easy operation and status monitoring. Advanced printhead technology and optimized thermal elements extend printhead life and improve print consistency.
Specifications
| Print Technology | Thermal Transfer and Direct Thermal |
| Print Resolution | 305 dpi (12 dots/mm) |
| Print Speed | Up to 6 inches per second (152 mm/s) |
| Max Print Width | 4.09 inches (104 mm) |
| Max Print Length | 98 inches (2,487 mm) |
| Media Types Supported | Continuous, die-cut, tag, receipt |
| Media Width Range | 1.0 to 4.5 inches (25.4 to 114 mm) |
| Connectivity | Ethernet (RJ-45), Serial (RS-232), USB |
| Memory | 128 MB |
| Display | Full graphic LCD with 6-button user interface |
| Dimensions | 12.1 in (W) x 19.1 in (D) x 13.7 in (H) |
| Weight | Approximately 16.3 lbs (7.4 kg) |
| Operating Temperature | 40°F to 105°F (4.4°C to 40.6°C) |
| Power Supply | External 100-240 VAC, 50-60 Hz auto-ranging |
| Certifications | FCC Class A, UL, CE |
| Discontinued | Yes |
| Input Type | Monochrome |
| Output Type | Black & White |
| MPN | 305 dpi, Barcode, ZT23043-T01200FZ |
| Supported Paper Size | Maximum Label Width: 4.50" |
| California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
| Type | Label Printer |
| Technology | Thermal |
| Maximum Resolution | 300 x 300 DPI |
| Model | ZT230 |
| Features | Networkable, Industrial |
| Black Print Speed | 6 ips |
| Product Line | Zebra |
| UPC | 791836551148 |
Images
Key Advantages
The Zebra ZT230's 305 dpi resolution delivers superior print clarity, ideal for detailed barcode and text printing. Its robust build quality withstands demanding industrial environments, ensuring long-term reliability. The device offers versatile media handling, supporting labels of different sizes and materials, which enhances its adaptability. Easy-to-use controls and an intuitive interface reduce training time and user error. Multiple connectivity options like USB and Ethernet facilitate seamless integration into various network setups. Additionally, energy-efficient design and quick print speeds minimize operational costs and improve productivity.
Limitations
The Zebra ZT230 is limited to monochrome printing, restricting it to black-and-white labels only. Maximum print width and length constraints may not support very large format labels. The printer requires specific compatible media types for optimal performance, which might limit flexibility in media sourcing. Some users may find the device's initial setup and calibration process moderately complex without technical assistance. The printer's firmware updates depend on Zebra's support, which could cause delays in addressing emerging compatibility issues. Lastly, the device's size and weight might pose challenges in compact workspaces.
FAQ
What types of printing technology does the Zebra ZT230 support?
The Zebra ZT230 supports both thermal transfer and direct thermal printing technologies, allowing for versatile label printing options.
What is the maximum print resolution of the Zebra ZT230?
The Zebra ZT230 features a print resolution of 305 dots per inch (dpi), providing high-quality and detailed print output.
Which connectivity options are available for the ZT230?
The printer offers USB and Ethernet interfaces for easy integration with various computers and network setups.
Is the Zebra ZT230 still in production?
No, the Zebra ZT230 has been discontinued and is no longer manufactured or sold as a new unit.
What media types can the ZT230 handle?
It supports a wide range of label media including continuous, die-cut, tag, and receipt papers in various sizes.
Does the printer support color printing?
No, the Zebra ZT230 only supports monochrome (black and white) printing, typical for barcode label printers.
Where can I find the user manual and technical documentation for the Zebra ZT230?
User manuals, technical specifications, and PDF documentation are typically available for download on Zebra's official website or trusted equipment documentation portals.
