Zebra ZD620

Quick information
Brand Zebra 2017
Model ZD62042-D21F00EZ, AC Adapter, ZD620d, Bluetooth
Released Year 2017
Type Printers
Series Zd
Status Active
Quick view

Overview

The Zebra ZD620 is a high-performance desktop label printer designed for office and industrial environments. It offers fast, reliable thermal printing with resolutions up to 300 dpi, enabling crisp, sharp barcode and text output. The printer supports both direct thermal and thermal transfer printing methods, providing versatility for different labeling needs. It integrates a powerful processor and ample memory for quick data processing and print job handling. Connectivity options include USB, Serial, Ethernet, Wi-Fi, and Bluetooth, allowing seamless integration with various systems. The ZD620 features a user-friendly interface with a full-color LCD for easy setup and monitoring.

The printer runs on Link-OS, Zebra’s intelligent printer operating system, which supports cloud connectivity and remote management. The compact design saves space without sacrificing performance or durability. The media handling system supports multiple media widths and types, enhancing flexibility for various applications.

Specifications

Input Type Monochrome
Output Type Black & White
Memory 512 MB Flash, 256 MB SDRAM
MPN ZD62042-D21F00EZ, AC Adapter, ZD620d, Bluetooth
Supported Paper Size Max Label Width: 4.65"
California Prop 65 Warning This item does NOT contain any chemicals or materials specified in the California Prop 65 list.
Type Label Printer
Technology Thermal
Maximum Resolution 203 x 203 DPI
Model ZD620
Connectivity USB 2.0, Serial, Ethernet (optional), Wi-Fi (optional), Bluetooth (optional)
Features Networkable, Portable
Black Print Speed 8 ips
Product Line Zebra ZD
Print Technology Direct Thermal and Thermal Transfer
Print Resolution 203 dpi (8 dots/mm) or 300 dpi (12 dots/mm)
Print Width Up to 4.09 inches (104 mm)
Print Speed Up to 8 inches per second (203 mm/sec) at 203 dpi
Processor Dual-core ARM A7 800 MHz
Display Color LCD with touch interface
Power Supply AC Adapter, auto-ranging 100-240 VAC
Dimensions (WxDxH) 8.3 x 7.6 x 6 inches (211 x 193 x 152 mm)
Weight About 4.6 lbs (2.1 kg)
Operating Temperature 41°F to 104°F (5°C to 40°C)
Media Types Supported Die-cut labels, continuous labels, tags, wristbands
Operating System Support Windows, Android, iOS, Mac OS X
Printer Language ZPL, EPL
Link-OS Support Yes

Key Advantages

The ZD620 provides outstanding print speed and high resolution for professional label quality. Its broad range of connectivity options, including Bluetooth and Wi-Fi, enables easy wireless printing. The Link-OS environment enhances device management, diagnostics, and updates, reducing downtime. The printer’s modular design supports field-installable connectivity options to adapt to changing business needs. It also has a user-friendly interface with intuitive controls and a bright color display. The rugged construction ensures reliability in demanding office and industrial environments.

Limitations

The ZD620 may be relatively expensive compared to entry-level desktop printers. Its full functionality and advanced features might require technical knowledge for setup and maintenance. The printer size and weight could be a constraint in very limited space environments. Some specialized media types may need specific accessories or supplies not included by default. Compatibility with non-Zebra software and applications occasionally requires additional driver installation or configuration. While the Link-OS platform offers extended capabilities, it depends on network reliability for some remote functions.
