Zebra ZD42043-T0G000EZ

Quick information
Brand Zebra 2018
Model ZD42043-T0G000EZ
Released Year 2018
Type Printers
Series ZD420
Printing Technology Direct Thermal
Item Weight 4.4 pounds
Product Dimensions 11.81 x 7.87 x 3.94 inches
Status Active
Quick view

Overview

The Zebra ZD42043-T0G000EZ is a thermal label printer designed for office and business environments, featuring direct thermal printing technology. It supports resolutions up to 203 dpi, delivering clear and sharp labels suitable for various applications. Connectivity options include USB, USB Host, and optional wireless capabilities for versatile integration. Its compact design occupies minimal desk space while enhancing workflow efficiency. The printer supports multiple media types and widths, enabling flexible label production. Advanced ribbon and media handling features simplify maintenance and reduce downtime.

Specifications

Release Year 2018
Printing Technology Direct Thermal
Print Resolution 203 dpi (8 dots/mm)
Maximum Print Width 4.09 inches (104 mm)
Maximum Print Speed 6 inches per second (152 mm/s)
Connectivity USB 2.0, USB Host, Optional 802.11ac Wi-Fi, Bluetooth
Media Types Supported Labels, Tags, Receipts
Media Width Supported 0.75 inches to 4.25 inches (19 mm to 108 mm)
Ribbon Type Thermal Transfer (optional)
Ribbon Capacity 74 m
User Interface LCD with 6 buttons and status LEDs
Dimensions 7.4 x 7.7 x 5.9 inches (188 x 196 x 150 mm)
Weight 3.5 lbs (1.6 kg)
Software Compatibility Zebra Print DNA, ZebraDesigner Software
Power Source AC adapter (external)
Operating Temperature 40°F to 105°F (4.4°C to 40.5°C)
Print media Labels
Max Input Sheet Capacity 100
Compatible Devices PC
Sheet Size 4.25 inches
Maximum Black and White Print Resolution 203 dpi
Warranty Type limited warranty
Dual-sided printing No
Max copy resolution black-white 203 dpi
Duplex Simplex
Hardware Interface Ethernet
Ink Color Black
Additional Printer functions Print Only
Control Method Remote
Output sheet capacity 100
Processor Count 1
Series Number 420
Number of USB 2 Ports 2
Total USB Ports 2
UPC 887988178002
Printer Ink Type Thermal Ribbon
Memory Storage Capacity 256 MB
Product Dimensions 11.81 x 7.87 x 3.94 inches
Item Weight 4.4 pounds
Item model number ZD42043-T0G000EZ
Is Discontinued By Manufacturer No
Date First Available June 8, 2018
Manufacturer ZEBRA

Key Advantages

The device offers fast printing speeds up to 6 inches per second, improving operational productivity. It features a user-friendly clamshell design for easy media loading, minimizing setup time. Zebra’s Print DNA software enhances printer management and remote configuration capabilities. The printer supports an optional cutter and peel-and-present functionality for convenience. High compatibility with various label formats and software platforms ensures versatile deployment. Robust build quality ensures reliability in demanding office environments.

Limitations

The ZD42043-T0G000EZ model is limited to 203 dpi resolution, which may not suffice for very fine or high-density labels. It lacks native Ethernet connectivity in standard configurations, requiring add-ons for network integration. Print width is restricted to 4.09 inches, limiting applications needing larger labels. The thermal transfer ribbon capacity is relatively small, necessitating frequent replacement in high-volume settings. Some advanced wireless features may require additional configuration or optional modules. Color printing is unavailable, restricting uses to monochrome label output.
