Zebra ZD420 image

Zebra ZD420

Quick information
Brand Zebra 2016
Model ZD420t, Wi-Fi, ZD42043-C01W018N, AC Adapter, Wireless, Barcode, ZD420c, Direct Thermal, Thermal Transfer
Released Year 2016
Type Printers
Series Zd
Status Active
Quick view
Full specs Images

Overview

The Zebra ZD420 printer series is an advanced office electronic device designed primarily for barcode and label printing applications. It features direct thermal and thermal transfer printing technologies, allowing flexibility in media usage. The printer supports various connectivity options including USB, Ethernet, and optional Wi-Fi, ensuring seamless integration within different office environments. It utilizes a high-resolution printhead capable of delivering crisp labels at speeds up to 6 inches per second. The ZD420 includes a user-friendly LCD interface and compatibility with multiple programming languages for ease of deployment. Its compact design optimizes workspace efficiency without compromising on performance.

Specifications

Input Type Monochrome
Output Type Black & White
Memory 256 MB SDRAM, 512 MB Flash
MPN ZD420t, Wi-Fi, ZD42043-C01W018N, AC Adapter, Wireless, Barcode, ZD420c, Direct Thermal, Thermal Transfer
Supported Paper Size Max Label Width: 4.65"
California Prop 65 Warning This item does NOT contain any chemicals or materials specified in the California Prop 65 list.
Type Label Printer
Technology Thermal
Maximum Resolution 300 x 300 DPI
Model ZD420
Connectivity USB 2.0, Serial, Ethernet (10/100 Mbps), optional Wi-Fi 802.11ac
Features Portable
Black Print Speed 4 ips
Product Line Zebra ZD
Printer type Desktop thermal transfer and direct thermal printer
Print resolution 203 dpi (8 dots/mm) and 300 dpi (12 dots/mm) options
Maximum print width 4.09 inches (104 mm)
Print speed Up to 6 inches per second (ips)
Media types supported Gap, black mark, continuous, fanfold, notch, and die-cut labels; tag stock
Media width 0.585 inches to 4.65 inches (15 mm to 118 mm)
Media thickness 0.003 inches to 0.01 inches (0.08 mm to 0.25 mm)
Media sensing Moveable reflective and transmissive sensors
Label roll maximum diameter 5.00 inches (127 mm) on a 1-inch core
Power supply Auto-ranging (100-240 VAC) external power supply
Dimensions (W x H x D) 7.4 x 7.5 x 10 inches (188 x 191 x 254 mm)
Weight Approximately 3.6 lbs (1.63 kg)
Operating temperature 40°F to 105°F (5°C to 40°C)
Operating humidity 10% to 90% non-condensing
Programming languages ZPL, EPL, XML-enabled
User interface Full-color LCD with easy-to-use menu system

Key Advantages

The Zebra ZD420 offers high-resolution printing with 203 dpi to 300 dpi options, enhancing label clarity and readability. Its versatile connectivity options include USB, serial, Ethernet, and optional Wi-Fi, facilitating flexible network integration. The printer supports both direct thermal and thermal transfer printing, expanding media compatibility to meet various labeling needs. The easy-to-use LCD interface simplifies setup, configuration, and maintenance for end-users. Its fast print speed up to 6 ips improves workplace productivity in high-volume scenarios. Additionally, the ZD420 series is designed with energy efficiency and reliability, minimizing downtime and operational costs.

Limitations

Despite its versatility, the ZD420 has limitations in maximum label width capped at 4.09 inches, which may not suit all labeling applications. The print speed, while efficient for most office tasks, might be insufficient for extremely high-volume industrial environments. Wi-Fi connectivity is optional and not built into all models, requiring additional hardware for wireless functionality. Media capacity is limited compared to larger industrial printers, necessitating frequent media changes in heavy usage scenarios. The printer does not natively support some advanced RFID encoding features present in other Zebra models. Finally, its higher price point relative to basic label printers could be a constraint for small businesses with limited budgets.

FAQ

The Zebra ZD420 supports both direct thermal and thermal transfer printing technologies.

No, Wi-Fi connectivity is optional and available on specific models of the ZD420 series.

The maximum print width supported by the Zebra ZD420 is 4.09 inches (104 mm).

Yes, the ZD420 is designed for barcode printing among other label printing applications.

The printer provides USB, serial, Ethernet, and optional Wi-Fi connectivity options.

Yes, it features an LCD interface for easier setup and operation.

Yes, as of now, the Zebra ZD420 printer series is not discontinued.
