Zebra Zd410 image

Zebra Zd410

Quick information
Brand Zebra 2017
Model ZD41H22-D01W01EZ, ZD410
Released Year 2017
Type Printers
Series Zd
Status Active
Quick view
Full specs Images FAQ

Overview

The Zebra ZD410 is a high-resolution thermal label printer designed for office environments requiring precise and compact printing solutions.

It supports direct thermal printing technology, offering print speeds up to 6 inches per second and a 203 dpi or optional 300 dpi print resolution for detailed barcode and text clarity.

The printer accommodates media widths from 0.75 inches to 4.25 inches, making it versatile for a variety of label sizes.

Connectivity options include USB, Ethernet, serial, and optional wireless interfaces, enabling flexible integration into diverse network setups.

The device features an intuitive LCD interface for easy setup and configuration.

Its compact design supports space-constrained office environments without sacrificing print quality or reliability.

Specifications

Input Type Monochrome
Output Type Black & White
Memory 512 MB Flash, 256 MB SDRAM
MPN ZD41H22-D01W01EZ, ZD410
California Prop 65 Warning :
Type Printer
Technology Thermal
Maximum Resolution 203DPI
Model Zebra ZD410
Connectivity USB 2.0, Ethernet, Serial, Optional Wi-Fi (802.11ac), Bluetooth
Features Networkable
Country/Region of Manufacture Vietnam
Product Line Zebra ZD
Print Technology Direct Thermal
Print Resolution 203 dpi (8 dots/mm) standard; 300 dpi (12 dots/mm) optional
Max Print Speed 6 inches per second
Max Print Width 4.25 inches (108 mm)
Media Width Supported 0.75 inches to 4.25 inches
Display Single button with LED status indicators, optional LCD screen
Dimensions 7.4 in (W) x 7.6 in (D) x 5.9 in (H)
Weight Approx. 2.1 lbs (0.95 kg)
Power Supply External universal power supply (AC adaptor)
Supported Label Types Roll or fanfold labels, tags, tickets
Operating Temperature 40°F to 105°F (5°C to 40°C)
Reliability 12 million linear inches
Software Support Zebra Print DNA tools, printer drivers for Windows, support for various label design software

Key Advantages

The ZD410 printer offers a compact footprint suitable for limited office space.

High print resolution options (203 dpi and 300 dpi) provide crisp, detailed labels and barcodes.

Fast print speeds up to 6 ips help enhance operational efficiency.

Multiple connectivity choices, including wired and wireless, allow seamless integration with existing systems.

Easy media loading and adjustable media handling reduce downtime and improve workflow.

Robust build quality ensures reliable daily operation in various office settings.

Limitations

The ZD410 uses direct thermal technology, which limits label longevity as prints can fade when exposed to heat or light.

It may not be suitable for high-volume industrial environments requiring continuous heavy-duty printing.

Its compact size limits maximum media roll diameter, necessitating frequent media replacements in heavy use.

Print width is limited to a maximum of 4.25 inches, restricting larger label applications.

Options for advanced third-party software or accessories are more limited compared to larger enterprise printers.

Wireless connectivity is optional and may add to the initial cost and setup complexity.
