Zebra ZD410
Brand | Zebra 2016 |
Model | ZD41023-D01000EZ |
Released Year | 2016 |
Type | Printers |
Series | Z |
Status | Active |
Quick view
Overview
The Zebra ZD410 is a compact direct thermal and thermal transfer label printer, engineered for precision and space-saving applications in office and retail environments. It features a high-resolution 203 dpi printhead for sharp barcode and text printing on labels up to 2.2 inches wide. The printer uses USB, Serial, and Bluetooth connectivity options, enabling versatile device integration. Its clamshell design simplifies media loading and reduces downtime. The ZD410 supports continuous, die-cut, and black mark media, making it flexible for a wide range of labeling needs. Additionally, it runs Zebra's Link-OS platform, which enhances device management and enables cloud connectivity.
Specifications
Printer Type | Direct Thermal / Thermal Transfer |
Print Resolution | 203 dpi (8 dots/mm) |
Max Print Width | 2.2 inches (56 mm) |
Max Print Speed | 4 inches per second |
Processor | 32-bit ARM Cortex-A9 |
RAM | 256 MB SDRAM |
ROM | 512 MB Flash |
Connectivity | USB 2.0 |
Media Types Supported | Continuous, die-cut, black mark, tag stock |
Media Width | 0.79 inch to 2.36 inches (20 mm to 60 mm) |
Media Thickness | 0.003 inches to 0.0075 inches (0.08 mm to 0.19 mm) |
Max Media Roll Diameter | 2.6 inches (66 mm) |
Ribbon | Thermal transfer ribbon (optional) |
Ribbon Max Length | 74 meters |
Dimensions | 4.7 in (W) x 7.6 in (H) x 7.0 in (D) |
Weight | 1.6 lbs (0.73 kg) |
Operating Temperature | 40°F to 105°F (5°C to 40°C) |
Software Platform | Zebra Link-OS |
Power Supply | External 100-240V, 50-60Hz |
Input Type | Monochrome |
Memory | 256 MB |
Output Type | Black & White |
MPN | ZD41023-D01000EZ |
Item Length | 8.6 in |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Item Height | 6 in |
Model | ZD410 |
Features | Portable |
Item Width | 4.5 in |
Product Line | Zebra Z |
Images
Key Advantages
The Zebra ZD410 offers ultra-compact size ideal for limited space environments. It boasts fast print speeds up to 4 inches per second for efficient label production. Compatibility with various connectivity options like USB, Bluetooth, and Serial allows flexible integration. The clamshell design makes media loading quick and error-free, reducing maintenance time. Its compatibility with both direct thermal and thermal transfer ribbons increases versatility for different printing requirements. Additionally, the robust Link-OS platform supports remote management and app development, improving operational workflows.
Limitations
The ZD410 has a relatively narrow maximum print width of 2.2 inches, limiting use for larger labels. Its thermal transfer ribbon capacity is limited compared to larger models, requiring frequent media replacement for high-volume demands. It is primarily designed for low to medium volume printing, making it less suitable for heavy industrial applications. The Bluetooth connectivity option does not support all mobile operating systems equivalently, potentially limiting wireless use. The print speed may be slower compared to some industrial label printers. Lastly, the price point may be higher than comparable compact desktop label printers without Link-OS features.
FAQ
What type of printing technology does the Zebra ZD410 use?
The Zebra ZD410 supports both direct thermal and thermal transfer printing technologies.
Which connectivity options are available on the ZD410 model ZD41023-D01000EZ?
This model includes USB, Serial, and Bluetooth connectivity options for flexible device integration.
What is the maximum print width supported by this printer?
The maximum print width is 2.2 inches (56 mm).
Is the Zebra ZD410 suitable for high volume industrial printing?
No, the ZD410 is designed primarily for low to medium volume label printing in office and retail environments.
Does the ZD410 support remote management?
Yes, the Zebra ZD410 runs on the Link-OS platform, which allows for remote device management and cloud connectivity.
What types of label media are compatible with the ZD410?
It supports continuous, die-cut, black mark, and tag stock label media.
Is the printer still available for purchase new?
Yes, the Zebra ZD410 is currently in production and not discontinued.
