Zebra ZD410 image

Zebra ZD410

Quick information
Brand Zebra 2017
Model ZD41022D01E00EZ
Released Year 2017
Type Printers
Series Z
Status Active
Quick view
Full specs Images

Overview

The Zebra ZD410 is a compact, direct thermal label printer designed for efficient on-demand printing in office and light industrial environments. It supports print widths up to 2.2 inches and resolutions of 203 dpi or 300 dpi, delivering high-quality, sharp labels and barcodes. The device operates with fast print speeds up to 6 inches per second, ideal for applications requiring quick label output. Connectivity options include USB, Bluetooth, and optional Wi-Fi, allowing flexible integration with various systems. Its media handling supports multiple types of labels and tags, including continuous, die-cut, and black mark sensors for accurate media detection. The ZD410 is engineered for ease of use with a user-friendly interface, tool-less media loading, and reliable performance for streamlined printing workflows.

Specifications

MPN ZD41022D01E00EZ
Model ZD410
Memory 256 MB Flash, 128 MB SDRAM
Technology Thermal
Image Sensor Thermal
Connectivity USB 2.0, Bluetooth 4.1, Optional 802.11ac Wi-Fi
Output Type Black & White
Features Portable, Networkable
Input Type Monochrome
Type Label Printer
Maximum Resolution 203 x 203 DPI
Black Print Speed 6 ppm
Product Line Zebra Z
Print Method Direct Thermal
Print Resolution 203 dpi or 300 dpi
Maximum Print Width 2.2 inches (56 mm)
Print Speed Up to 6 inches per second (152 mm/s)
Media Types Continuous, Die-cut, Black Mark labels and tags
Media Width 0.79 in to 2.36 in (20 mm to 60 mm)
Dimensions 5.9 in (W) x 7.4 in (D) x 5.9 in (H) (150 mm x 188 mm x 150 mm)
Weight 1.4 kg (3 lbs)
Sensors Transmissive and Reflective
Power Supply External 100-240 VAC, 50-60 Hz
Operating Temperature 40°F to 105°F (5°C to 40°C)
Storage Temperature -40°F to 140°F (-40°C to 60°C)
Compatibility Supports EPL, ZPL programming languages

Key Advantages

The ZD410's compact size makes it an ideal choice for environments with limited space. It offers excellent print quality with its 300 dpi option, producing crisp barcodes and graphics. Rapid print speeds reduce wait times and increase productivity. Multiple connectivity options (USB, Bluetooth, optional Wi-Fi) provide versatility in deployment and integration. The printer supports various label media types and widths, enhancing application flexibility. Its easy-to-use design simplifies maintenance and media replacement, minimizing downtime.

Limitations

The ZD410 is a direct thermal printer, which means labels may fade over time when exposed to heat or sunlight, limiting lifespan. It has a maximum print width of 2.2 inches, which may not suit wide-format label needs. The device's small size limits ribbon and media roll capacities, requiring more frequent replacements. Unlike thermal transfer printers, it does not support ribbon-based printing out-of-the-box, reducing durability of printed labels. Wi-Fi connectivity is optional and may require additional configuration. The printer's ruggedness is less suited for harsh industrial environments compared to larger models.

FAQ

The Zebra ZD410 uses direct thermal printing technology, which does not require ink or ribbon, relying on heat-sensitive media.

The ZD410 offers a maximum print resolution of 300 dots per inch (dpi) for high-quality label and barcode printing.

The printer includes USB and Bluetooth connectivity by default, with optional Wi-Fi available as an add-on for wireless networking.

It supports label widths up to 2.2 inches (56 mm), suitable for small to medium-sized labels and tags.

While designed for office and light industrial use, it is best suited for environments where space is limited and harsh conditions are minimal.

The standard ZD410 model is a direct thermal printer; however, Zebra offers a thermal transfer variant that supports ribbon printing if needed.

The printer features a tool-less media loading system that allows quick and straightforward replacement of labels and ribbons, reducing downtime.
