Zebra ZD410-HC
Brand | Zebra 2018 |
Model | ZD41H22-D01E00EZ, ZD410-HC, Pharmacy |
Released Year | 2018 |
Type | Printers |
Series | Zd |
Status | Active |
Quick view
Overview
The Zebra ZD410-HC is a high-resolution thermal label printer designed specifically for healthcare environments. It supports direct thermal printing technology ensuring no ink, toner, or ribbon is required for its operation. The device operates with a print speed of up to 6 inches per second, rendering high quality 300 dpi images and text for crisp labeling. Connectivity options include USB, Bluetooth, and optional Ethernet or Wi-Fi for flexible integration into various network environments. The printer supports multiple barcode symbologies and can be managed remotely for efficient device management. Its design includes a healthcare-compliant casing that is easy to clean and resistant to disinfectants.
Equipped with Zebra's Link-OS operating system, the ZD410-HC allows seamless device management and integration with enterprise systems. It accommodates media up to 2.2 inches wide and supports different media types such as labels, tags, and receipts. The printer features easy media loading mechanisms and a compact design optimized for space-constrained work areas.
Specifications
Print Method | Direct Thermal |
Print Resolution | 300 dpi (12 dots/mm) |
Print Speed | Up to 6 ips (152 mm/s) |
Max Print Width | 2.2 inches (56 mm) |
Media Types Supported | Labels, Tags, Receipts |
Connectivity | Bluetooth, Ethernet (RJ-45), USB 2.0 |
Memory | 256 MB |
Dimensions | 5.9" W x 7.1" D x 5.8" H (150 mm x 180 mm x 147 mm) |
Weight | 2.2 lbs (1.0 kg) |
Operating Temperatures | 40°F to 105°F (5°C to 40°C) |
Compatible Barcodes | 1D, 2D including QR Code, DataMatrix, PDF417 |
Operating System Compatibility | Windows, Android, iOS |
Management Software | Zebra Link-OS |
Healthcare Compliance | Disinfectant-ready plastics and sealed button design |
Input Type | Monochrome |
Output Type | Black & White |
MPN | ZD41H22-D01E00EZ, ZD410-HC, Pharmacy |
Supported Paper Size | Maximum Label Width: 2.36" |
California Prop 65 Warning | This item does NOT contain any chemicals or materials specified in the California Prop 65 list. |
Type | Label Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Model | ZD410-HC |
Features | Portable |
Black Print Speed | 6 ips |
Product Line | Zebra ZD |
Images
Key Advantages
The ZD410-HC offers superior print resolution at 300 dpi, ideal for detailed healthcare labeling. Its compact size enables placement in tight spaces without sacrificing functionality. The inclusion of multiple connectivity options allows versatile deployment across different healthcare IT infrastructures. Its durable housing is built to healthcare industry standards, resisting frequent cleaning with harsh chemicals. The printer supports a broad range of media types and sizes, ensuring compatibility with various label requirements. It also benefits from Zebra's Link-OS platform for enhanced printer management and diagnostics.
Limitations
The ZD410-HC is a direct thermal printer, which means labels can fade over time when exposed to heat or sunlight. It has a relatively narrow media width limit of 2.2 inches, restricting label size options. The print speed, while adequate for many tasks, may be slower compared to larger industrial printers. Its memory capacity is limited, which could constrain complex label designs or large print jobs. The device may lack some advanced features found in larger desktop or industrial printers such as peel and present or cutter options. Additionally, initial setup and driver installation might pose challenges in some healthcare IT environments.
FAQ
What type of printing technology does the Zebra ZD410-HC use?
The Zebra ZD410-HC utilizes direct thermal printing technology, which prints images directly onto heat-sensitive media without the need for ink or toner.
What print resolution does the ZD410-HC support?
It supports a print resolution of 300 dpi, delivering high-quality, sharp text and barcodes suitable for healthcare labels.
Are there connectivity options available for the ZD410-HC?
Yes, the printer includes USB and Bluetooth as standard interfaces, with optional Ethernet and Wi-Fi available for network connectivity.
Can this printer handle various media types?
Yes, it supports different media types including labels, tags, and receipts up to 2.2 inches wide.
Is the ZD410-HC designed for healthcare environments?
Yes, it features a healthcare-compliant design that resists cleaning chemicals and is easy to sanitize.
What software platform does the printer use for device management?
The printer runs on Zebra's Link-OS platform, allowing remote management and seamless integration.
Is the Zebra ZD410-HC still supported and available?
As of now, the ZD410-HC is not discontinued and remains supported by Zebra for healthcare labeling solutions.
