Zebra Zd220t image

Zebra Zd220t

Quick information
Brand Zebra 2019
Model ZD22042-T0GG00EZ
Released Year 2019
Type Printers
Series Z
Status Active
Quick view
Full specs Images FAQ

Overview

The Zebra ZD220t is a thermal transfer desktop printer designed for small to medium-volume label printing applications. It features a direct thermal or thermal transfer print method with a maximum print width of 4.09 inches (104 mm). The printer uses a 203 dpi (dots per inch) print resolution to ensure clean, crisp barcode and text labelling. Equipped with USB 2.0 connectivity, it provides reliable communication to desktop and mobile computers. The device supports easy media loading and features an intuitive LCD interface for operation. With its compact footprint and energy-efficient design, the ZD220t integrates seamlessly into office and retail environments requiring durable, high-quality label printing.

Specifications

MPN ZD22042-T0GG00EZ
Country/Region of Manufacture China
Type Mobile Printer
Technology Thermal
Product Line Zebra Z
Output Type Black & White
Connectivity USB 2.0
Input Type Monochrome
Features Networkable
Model Zebra ZD220T
Supported Paper Size Does not apply
Maximum Resolution 203 x 203 DPI
Black Print Speed 6 ppm
Memory 512 MB Flash, 256 MB SDRAM
Manufacturer Warranty 3 Months
UPC Does not apply
Print Method Thermal Transfer
Print Resolution 203 dpi (8 dots/mm)
Maximum Print Width 4.09 inches (104 mm)
Print Speed Up to 4 inches per second
Media Types Roll-fed or fanfold labels and tags, continuous, die-cut, black mark
Media Width 0.75 inches to 4.25 inches (19 mm to 108 mm)
Media Sensors Moveable gap sensor, black mark sensor, and ribbon sensor
Ribbon Compatibility Ink-coated side out, width 1.57 in to 4.33 in (40 mm to 110 mm)
Dimensions 7.2 x 5.9 x 7.4 inches (182 x 150 x 188 mm)
Weight 3.6 lbs (1.63 kg)
Power 100-240 VAC, 50-60 Hz
Operating Temperature 40°F to 105°F (5°C to 40°C)
Certifications ENERGY STAR qualified, FCC, CE

Key Advantages

The ZD220t's compact design makes it suitable for environments with limited space. Its thermal transfer technology produces durable, long-lasting labels resistant to smudging and fading. Easy media loading reduces downtime for operators and increases productivity. The printer is ENERGY STAR qualified, promoting energy savings in daily use. USB connectivity ensures compatibility with a variety of systems and devices. The device supports multiple label formats and barcode symbologies enhancing flexibility in label creation.

Limitations

The ZD220t offers a maximum print resolution of 203 dpi, which may not suffice for ultra-high detail printing needs. It lacks wireless connectivity options such as Wi-Fi or Bluetooth, limiting mobility and remote operation. The printer's print speed is moderate, potentially unsuitable for high-volume industrial environments. Limited memory storage restricts handling of very large or complex label formats. Absence of advanced networking ports like Ethernet might impede integration into networked office setups. The basic control interface may not provide advanced diagnostics available in higher-end models.
