Zebra Z6M Plus image

Zebra Z6M Plus

Quick information
Brand Zebra 2017
Model Z6M00-3001-0000, Barcode
Released Year 2017
Type Printers
Series Z
Status Active
Quick view
Full specs Images

Overview

The Zebra Z6M Plus is a high-performance industrial barcode printer designed primarily for heavy-duty office and warehouse applications. It features direct thermal and thermal transfer printing methods, supporting a wide range of label materials. The printer is equipped with a robust metal frame that ensures durability and longevity in demanding environments. It supports a maximum print resolution of 203 dpi or optionally 300 dpi, allowing clear and precise barcode and text output. Connectivity options include USB, serial, and Ethernet interfaces for versatile integration into existing office networks. Additionally, the device supports an easy-to-use LCD interface for convenient configuration and management.

Specifications

Input Type Monochrome
Output Type Black & White
Memory Standard 512 MB Flash, 256 MB SDRAM
MPN Z6M00-3001-0000, Barcode
Supported Paper Size Max Label Width: 6.75"
California Prop 65 Warning This item does NOT contain any chemicals or materials specified in the California Prop 65 list.
Type Label Printer
Technology Thermal
Maximum Resolution 300 x 300 DPI
Model Z6M Plus
Connectivity USB 2.0, Serial RS-232, 10/100 Ethernet
Black Print Speed 10”/254 mm per second
Product Line Zebra Z
UPC Does not apply
Print Method Direct Thermal and Thermal Transfer
Print Resolution 203 dpi (8 dots/mm) standard, optional 300 dpi
Max Print Width 6.6 inches (168 mm)
Print Speed Up to 8 inches (203 mm) per second
Media Types Supported Roll-fed, fan-fold, continuous, die-cut labels, tags, receipt paper
Media Width 1.00 inches (25.4 mm) to 6.88 inches (174.6 mm)
Dimensions (W x D x H) 13.0 x 22.8 x 16.8 in (330 x 580 x 427 mm)
Weight Approximately 56 lbs (25.4 kg)
Operating System Compatibility Windows, Mac OS via appropriate drivers
Control Panel 4.3-inch color LCD with touch interface
Power Supply External, 100-240V AC, 2.5A, 50-60Hz
Optional Features Cutter module, label peeler, internal rewinder
Software Zebra Designer, Link-OS environment for remote management

Key Advantages

The Z6M Plus offers exceptional print speed, enhancing operational efficiency in busy office settings. Its versatile media handling supports rolls, fan-fold, and continuous media with a maximum width of up to 6 inches. The printer's modular design permits the addition of optional cutters, peelers, and rewinds, catering to diverse office needs. Zebra’s Link-OS environment integration simplifies remote device management and diagnostics. The rugged steel construction ensures reliable operation under continuous workload conditions. Enhanced connectivity options facilitate seamless integration into various office electronic systems and workflows.

Limitations

The Zebra Z6M Plus is relatively large and heavy compared to desktop printers, which may limit its placement in constrained office spaces. Its initial purchase cost and maintenance might be higher than compact printers designed for lower volume printing. The maximum print width of 6 inches might be insufficient for very large label requirements. Some advanced configuration settings require specialized knowledge or IT support. Firmware updates and driver compatibility need careful management to ensure smooth operation across multiple operating systems. The printer does not offer wireless connectivity as a standard feature, potentially limiting flexible placement without cabling.

FAQ

The Z6M Plus supports both direct thermal and thermal transfer printing methods.

The printer offers a maximum print resolution of up to 300 dpi, with 203 dpi as standard.

Connectivity options include USB, serial, and Ethernet interfaces.

Yes, it supports various media types including rolls, fan-fold, and continuous media.

While ideal for industrial and heavy-duty office use, its size and weight may be restrictive for very small office spaces.

Wireless connectivity is not included as a standard feature but may be available through optional accessories.

Optional accessories include cutters, peelers, and label rewinders for enhanced functionality.
