Zebra Tlp2824 plus ethernet
Brand | Zebra 2013 |
Model | 282P-101510-000 |
Released Year | 2013 |
Type | Printers |
Series | Tlp |
Printing Technology | Direct Thermal |
Status | Discontinued |
Quick view
Overview
The Zebra TLP2824 Plus Ethernet is a compact thermal printer designed primarily for printing labels, barcodes, and receipts in office and retail environments. It supports direct thermal technology, utilizing heat-sensitive media eliminating the need for ink or toner cartridges. The device features an Ethernet interface for seamless network connectivity, enabling multiple users to print over a shared network easily. With a print resolution of 203 dpi (8 dots per mm), the printer provides clear and readable outputs suitable for supply chain and asset tracking applications. It supports various media types with a maximum width of 2.36 inches (60mm) and print speeds up to 4 inches per second. The printer's built-in programming languages include EPL and ZPL, allowing flexible integration with existing systems.
Its thermal printhead is user-replaceable, enhancing serviceability and reducing downtime. The device includes an LCD status indicator and customizable alerts to monitor printing conditions efficiently. The compact footprint and durable design enable deployment in tight spaces without compromising performance. Its firmware is upgradable via Ethernet, supporting ongoing improvements and feature expansions.
Specifications
Input Type | Monochrome |
Output Type | Black & White |
Memory | 8 MB SDRAM, 4 MB Flash |
MPN | 282P-101510-000 |
Supported Paper Size | 2 inch |
California Prop 65 Warning | non |
Type | Label Printer |
Technology | thermal |
Maximum Resolution | 203 x 203 DPI |
Model | tlp2824 plus ethernet |
Connectivity | Ethernet 10/100 Mbps, Serial RS-232 (optional) |
Features | Networkable |
Black Print Speed | 6 ppm |
Product Line | Zebra TLP |
UPC | Does not apply |
Device Type | Thermal Label Printer |
Printing Technology | Direct Thermal |
Print Resolution | 203 dpi (8 dots/mm) |
Maximum Print Width | 2.36 inches (60 mm) |
Maximum Print Speed | 4 inches per second |
Media Types Supported | Direct thermal labels, tags, wristbands |
Media Width Range | 0.75 inches to 2.36 inches (19 mm to 60 mm) |
Media Thickness | 0.0023 to 0.01 inches (0.06 to 0.25 mm) |
Media Sensing | Reflective and transmissive sensors |
Programming Languages | EPL, ZPL |
Dimensions (W x D x H) | 6.75 x 7.5 x 6.0 inches (171 x 190 x 152 mm) |
Weight | 3.4 lbs (1.54 kg) |
Power Supply | External 100-240 VAC, 50-60 Hz |
Operating Temperature | 40°F to 105°F (5°C to 40°C) |
Storage Temperature | -40°F to 140°F (-40°C to 60°C) |
User Interface | LED status indicators, LCD screen |
Printhead Life | Up to 50 km of printed labels |
Driver Support | Windows drivers (varies with OS version) |
Firmware Upgrade | Supported via Ethernet |
Images
Key Advantages
The Zebra TLP2824 Plus Ethernet offers reliable, high-quality thermal printing with excellent resolution and speed for its class. Its Ethernet connectivity ensures convenient network printing, ideal for shared office environments. The compact and lightweight design allows easy placement in small workspaces. User-friendly media loading and a replaceable printhead simplify maintenance. Compatibility with multiple programming languages (EPL and ZPL) supports diverse applications and easy integration. The device's robust build ensures consistent performance in various operational conditions.
Limitations
While efficient for small-scale printing, the TLP2824 Plus has a limited print width of 2.36 inches, restricting its use for larger labels or documents. The print speed, though adequate, is slower compared to higher-end models, potentially affecting high-volume print jobs. Direct thermal printing requires heat-sensitive media, which may fade over time and is unsuitable for long-term label durability. The device lacks wireless connectivity options, relying solely on Ethernet or serial connections. Advanced color printing is not supported, limiting output to monochrome labels. Compatibility issues may arise with some modern operating systems due to limited driver updates.
FAQ
What type of printing technology does the Zebra TLP2824 Plus Ethernet use?
It uses direct thermal printing technology, which relies on heat-sensitive media to produce images without ink or toner.
What connectivity options are available on this model?
The printer primarily offers Ethernet connectivity, allowing it to be connected to a network for shared use.
What is the maximum print width supported by the printer?
The maximum print width is 2.36 inches (60 millimeters).
Can the Zebra TLP2824 Plus print color labels?
No, this model supports only monochrome (black and white) thermal printing.
Is the printhead user-replaceable on this device?
Yes, the printhead is designed to be user-replaceable, facilitating easier maintenance.
What programming languages does the printer support?
It supports Zebra's EPL and ZPL printer command languages for flexible label formatting.
Is the Zebra TLP2824 Plus still supported or discontinued?
The Zebra TLP2824 Plus Ethernet model has been discontinued and may no longer receive official support and updates.
