Zebra TLP 2824 Plus (282P-101110-000)
Brand | Zebra 2010 |
Model | 282P101110000, 282P-101110-000 |
Released Year | 2010 |
Type | Printers |
Series | Lp |
Status | Discontinued |
Quick view
Overview
The Zebra TLP 2824 Plus is a compact thermal transfer and direct thermal label printer designed for low to medium volume printing tasks. It integrates a 32-bit processor to efficiently process printing commands and supports print resolution of 203 dpi (8 dots/mm), which allows for high-quality barcode and text printing. The device supports a maximum print width of 2.2 inches, suitable for small labels, tags, wristbands, or receipts. Connectivity options include USB and serial interfaces, enhancing its compatibility with various systems and devices. It uses Zebra's Link-OS for simplified printer management and configuration. The printer supports a wide range of label materials and sizes, enhancing flexibility across different applications.
Specifications
MPN | 282P101110000, 282P-101110-000 |
GTIN | 0807027540638, 0807027562289, 0807027540614 |
UPC | 0807027540638, 0807027562289, 0778889974209, 0807027540614 |
Model | TLP 2824 Plus (282P-101110-000) |
Memory | 8 MB Flash, 8 MB SDRAM |
Technology | Thermal |
Connectivity | USB 2.0, RS-232 Serial |
Output Type | Black & White |
Features | Networkable |
Type | Label Printer |
Black Print Speed | 4in/Sec |
Product Line | Zebra LP |
Depth | 9.5in |
Height | 7in |
Width | 5.3in |
Extend Printer Technology | Thermal Transfer |
Data Link Protocol | Ethernet, Parallel |
Color | Black |
Form Factor | Desktop |
Networking Type | Network Adapter |
Media Type | Die-Cut |
Max Resolution (Bw) | 203DPI |
Max Media Size | Roll (6cm) |
Printer Type | Thermal Transfer and Direct Thermal |
Print Resolution | 203 dpi (8 dots/mm) |
Maximum Print Width | 2.2 inches (56 mm) |
Print Speed | Up to 4 inches (102 mm) per second |
Processor | 32-bit RISC CPU |
Media Types | Labels, Tags, Receipts |
Media Width | 0.5 to 2.36 inches (12.7 to 60 mm) |
Media Thickness | 0.0025 to 0.01 inches (0.0635 to 0.254 mm) |
Media Roll Size | Up to 5 inches (127 mm) outer diameter |
Power Supply | External, 100-240 V AC |
Software Compatibility | Zebra Link-OS, ZPL, EPL |
Dimensions (WxHxD) | 6.8 x 6.7 x 8.3 inches (172 x 170 x 210 mm) |
Weight | Approx. 3.5 lbs (1.6 kg) |
Images
Key Advantages
The Zebra TLP 2824 Plus offers compact design ideal for restricted spaces in office environments. It features reliable thermal transfer and direct thermal printing technology that reduces the need for ink or toner cartridges. The printer's ease of use is enhanced with quick media loading and intuitive controls. It supports multiple connectivity options, including USB and serial port, ensuring versatile compatibility. Its rugged construction ensures durability and reliability for continuous operation. The device is energy efficient and supports various label types, making it adaptable to different labeling needs.
Limitations
The print width is limited to 2.2 inches, which may not be suitable for wider labels needed in some applications. The print speed is moderate, limiting high-volume production efficiency. The 203 dpi resolution, while sufficient for many tasks, may not meet the requirements for ultra-fine graphic printing. Connectivity options do not include Ethernet or wireless interfaces in the base model, limiting network integration without add-ons. It lacks advanced display interfaces, which could improve status monitoring and configuration. Additionally, the device is primarily designed for smaller scale operations, which can restrict its use in larger industrial environments.
FAQ
What type of printing technology does the Zebra TLP 2824 Plus use?
It uses both thermal transfer and direct thermal printing technologies.
What is the maximum print width supported by the TLP 2824 Plus?
The maximum print width is 2.2 inches (approximately 56 mm).
Does the Zebra TLP 2824 Plus support wireless connectivity?
No, the standard model does not include wireless connectivity; it supports USB and serial interfaces.
What is the print resolution of the Zebra TLP 2824 Plus?
It has a print resolution of 203 dpi (dots per inch).
Can I use the Zebra TLP 2824 Plus for barcode printing?
Yes, it is suitable for printing barcodes, labels, tags, and receipts.
Is the Zebra TLP 2824 Plus still being manufactured?
No, this model has been discontinued.
What type of media can the TLP 2824 Plus handle?
It supports various label materials including continuous, die-cut labels, receipt paper, and tags.
