Zebra P4t
Brand | Zebra 2017 |
Model | P4D-0UG10000-00 |
Released Year | 2017 |
Type | Printers |
Series | Z |
Status | Active |
Quick view
Overview
The Zebra P4T is a rugged mobile thermal transfer printer designed specifically for field and industrial use. It supports both direct thermal and thermal transfer printing technologies, enabling durable label production in various environments. The device offers a print resolution of 203 dpi (8 dots/mm), suitable for clear barcode and label printing. It has a compact and ergonomic design optimized for mobile applications, with connectivity options including Bluetooth and USB. The printer supports multiple media types and sizes up to 4 inches wide, and includes optional accessories for enhanced mobility and functionality. Its durable construction meets IP54 standards for dust and water resistance, making it reliable in harsh conditions.
Equipped with a 32-bit processor and ample memory, the P4T ensures efficient printing performance even under demanding job loads. The printer uses a rechargeable battery pack, providing extended operation time during fieldwork. Additionally, Zebra's Link-OS environment and Print DNA capabilities provide device management, security, and firmware update features for seamless integration with enterprise workflows.
Specifications
Input Type | Monochrome |
Color Depth | 12 Bit |
Output Type | Black & White |
Memory | 256 MB Flash, 128 MB SDRAM |
MPN | P4D-0UG10000-00 |
Supported Paper Size | 4 inch |
California Prop 65 Warning | unknown |
Type | Mobile Printer |
Technology | Thermal |
Maximum Resolution | 203 x 203 DPI |
Manufacturer Warranty | None |
Model | p4t |
Connectivity | Bluetooth 2.1 + EDR, USB 2.0 |
Scanning Resolution | 200x300 DPI |
Features | Portable |
Black Print Speed | 1 ppm |
Country/Region of Manufacture | China |
Product Line | Zebra Z |
UPC | do not apply |
Printer Type | Mobile Thermal Transfer and Direct Thermal Printer |
Print Resolution | 203 dpi (8 dots/mm) |
Max Print Width | 4 inches (104 mm) |
Print Speed | Up to 4 inches per second |
Processor | 32-bit ARM Cortex |
Media Types Supported | Thermal transfer labels, direct thermal labels |
Media Width | 0.75 to 4.4 inches (19 to 112 mm) |
Media Thickness | 0.003 to 0.01 inches (0.08 to 0.25 mm) |
Battery | Removable rechargeable Li-ion battery pack |
Durability | IP54 rated for water and dust resistance |
Operating Temperature | -4°F to 122°F (-20°C to 50°C) |
Dimensions | 7.5 x 3.5 x 4.5 inches (190 x 90 x 115 mm) |
Weight | 2.35 lbs (1.07 kg) |
Operating System Compatibility | Windows, iOS, Android via Zebra mobile SDK |
Software Platform | Zebra Link-OS with Print DNA capabilities |
Images
Key Advantages
The Zebra P4T offers excellent print quality with its thermal transfer technology, producing long-lasting labels resilient to abrasion, heat, and chemicals. Its rugged design allows operation in extreme environments, including varying temperatures and weather conditions. The mobile form factor and wireless connectivity options enable users to print on-the-go, increasing operational efficiency. It supports a wide variety of label media, accommodating diverse labeling needs. The device's user-friendly interface and compatibility with Zebra's software platforms simplify deployment and maintenance. Also, its IP54-rated casing ensures reliable performance in dusty and wet conditions.
Limitations
The P4T printer, while robust, has a maximum print speed limited to 4 inches per second, which may be slower compared to some industrial stationary printers. The 203 dpi resolution, although sufficient for most applications, may not meet the needs for extremely fine print details. Battery life, while suitable for standard shifts, may require frequent recharging in heavy-use scenarios. The printer is optimized for field use and may lack some advanced features seen in larger office printers, such as very high capacity media rolls. Initial setup and integration may require technical expertise for full utilization of Zebra's Link-OS features. Also, the mobile nature means it may not be as cost-effective for high volume printing compared to fixed printers.
FAQ
What types of printing technology does the Zebra P4T support?
The Zebra P4T supports both direct thermal and thermal transfer printing technologies, allowing for versatile label production.
What is the maximum print resolution of the Zebra P4T?
The printer provides a maximum print resolution of 203 dpi (8 dots per millimeter).
Can the Zebra P4T printer be used outdoors?
Yes, the Zebra P4T is designed for outdoor and industrial environments with an IP54 rating for dust and water resistance.
What connectivity options are available with the Zebra P4T?
The P4T offers Bluetooth and USB connectivity to enable wireless and wired printing from various devices.
Is the Zebra P4T still supported by Zebra for firmware updates?
Yes, as of now, the Zebra P4T is not discontinued and receives support including firmware updates via Zebra's Link-OS platform.
What types of media can the Zebra P4T print on?
It supports a range of thermal transfer and direct thermal label materials including linered and linerless media up to 4 inches wide.
How long does the battery last during typical use?
Battery life varies with usage but generally supports a full typical work shift on a single charge under normal printing conditions.
