Zebra LP2824

Quick information
Brand Zebra 2004
Model 2824-21100-0001
Released Year 2004
Type Printers
Series Lp
Status Discontinued
Quick view
Full specs Images FAQ

Overview

The Zebra LP2824 is a compact thermal transfer and direct thermal printer designed for office and retail applications. It features a print resolution of 203 dpi, enabling clear and precise label printing. The printer uses a USB interface for seamless connectivity with various computer systems. Its maximum print width is 4.09 inches, supporting media widths between 1.5 and 4.33 inches. The LP2824 supports a print speed of up to 4 inches per second, optimizing productivity. Its built-in media sensor enhances accuracy when handling different label types.

Specifications

Input Type Monochrome
Output Type Black & White
Memory 2 MB DRAM, 4 MB Flash
MPN 2824-21100-0001
Supported Paper Size Maximum Label Width: 2.36"
Type Label Printer
Technology Thermal
Maximum Resolution 203 x 203 DPI
Model LP2824
Connectivity USB 1.1
Features Portable
Black Print Speed 4 ppm
Product Line Zebra LP
Printer Type Thermal transfer and direct thermal printer
Print Resolution 203 dpi
Max Print Width 4.09 inches (104 mm)
Print Speed Up to 4 inches per second (102 mm/s)
Media Width 1.5 inches to 4.33 inches (38 mm to 110 mm)
Dimensions 7.75 x 5.5 x 5.6 inches (197 x 140 x 143 mm)
Weight Approximately 3.4 lb (1.54 kg)
Media Type Continuous, die-cut, black mark, notch, and tag stock
Power Supply External power supply, 24 VDC
Operating System Compatibility Windows, Mac OS, Linux (via drivers)
Discontinued Yes

Key Advantages

The Zebra LP2824 offers a small footprint ideal for limited space environments. It supports both direct thermal and thermal transfer printing, allowing versatile media options. The printer is energy efficient with quick startup times to minimize waiting periods. Its easy-to-load media mechanism reduces staff intervention and downtime. The USB connectivity ensures compatibility with modern computing devices. Moreover, the robust design provides durability for consistent office usage.

Limitations

The LP2824's fixed 203 dpi resolution limits high-resolution print requirements such as fine graphics. It lacks built-in wireless connectivity, necessitating USB connection for operating. Print speed is moderate compared to some newer high-speed label printers. The maximum print width may constrain larger label printing needs. Limited memory capacity restricts complex label formats stored on-device. Additionally, spare parts and official support are harder to acquire due to its discontinued status.
