Zebra LP 2824 Plus
Brand | Zebra 2006 |
Model | 282P-201112-000 |
Released Year | 2006 |
Type | Printers |
Series | Lp |
Status | Discontinued |
Quick view
Overview
The Zebra LP 2824 Plus is a compact direct thermal label printer designed primarily for low- to medium-volume printing environments. It features a print resolution of 203 dpi (8 dots/mm) and a print speed up to 4 inches per second, making it suitable for small label printing tasks such as shipping, barcoding, and identification. The device supports a maximum label width of 2.2 inches (56 mm) and uses a thermal transfer or direct thermal printing technology. Connectivity options include serial, parallel, and USB interfaces, ensuring compatibility with various host devices. The printer operates with Zebra Programming Language (ZPL) II support, facilitating integration and customization for different labeling applications.
Its compact footprint is designed for tight workspaces, allowing easy placement in kiosks, retail points of sale, or back-office environments. The LP 2824 Plus uses standard media roll sizes and features easy-loading media mechanisms for improved usability. It can accommodate labels, tags, and receipt media types, adding to its versatility. The rugged design and reliable printhead provide consistent print quality over extended usage periods, suitable for environments where durability and uptime are valued.
Specifications
MPN | 282P-201112-000 |
Ean | 0132017738529 |
GTIN | 0132017738529 |
Model | LP 2824 Plus |
Memory | 2 MB SDRAM, 4 MB Flash |
Technology | Thermal |
Connectivity | Cable, Serial (RS-232), Parallel (IEEE 1284), USB 1.0/1.1, Ethernet (RJ-45), USB 2.0 |
Output Type | Black & White |
Features | Scanner, Portable, Networkable |
Input Type | Monochrome |
Supported Paper Size | A8 (52 x 74 mm), A0 (841 x 1189 mm), A9 (37 x 52 mm) |
Type | Label Printer |
Maximum Resolution | 203 x 203 DPI |
Black Print Speed | 4 ppm |
Product Line | Zebra LP |
Printer Type | Direct Thermal / Thermal Transfer |
Print Resolution | 203 dpi (8 dots/mm) |
Maximum Print Width | 2.2 inches (56 mm) |
Print Speed | Up to 4 inches per second (102 mm/s) |
Interface | USB 1.1, Serial RS-232, Parallel IEEE 1284 |
Supported Languages | Zebra Programming Language (ZPL) II |
Media Types | Labels, Tags, Receipts |
Maximum Media Roll Diameter | 5.9 inches (150 mm) |
Media Width | 0.75 inches to 2.36 inches (19 mm to 60 mm) |
Power Source | External power supply 100-240V AC |
Dimensions (W x D x H) | 7.5 x 7.75 x 5.25 inches (191 x 197 x 133 mm) |
Weight | 3.75 lbs (1.7 kg) |
Operating Temperature | 40°F to 105°F (5°C to 40°C) |
Storage Temperature | -40°F to 140°F (-40°C to 60°C) |
Operating Humidity | 10% to 90% non-condensing |
Discontinued | Yes |
Images
Key Advantages
The Zebra LP 2824 Plus offers a compact and space-efficient design that fits well into small office and retail environments. It features versatile connectivity options including USB, serial, and parallel ports, enhancing its compatibility with older and modern systems. The printer provides crisp 203 dpi print resolution suitable for barcode labels and shipping tags. Its easy media loading system reduces downtime and simplifies label replacement. The LP 2824 Plus supports a range of media types, providing flexibility for various labeling solutions. It also benefits from the proven reliability of Zebra's print engines, ensuring long-term durability and consistent performance.
Limitations
The LP 2824 Plus is limited to a maximum print width of 2.2 inches, which may not be suitable for wider label applications. Its print speed of up to 4 inches per second is slower compared to some newer models, potentially limiting high-volume printing tasks. The device uses thermal transfer or direct thermal methods, but does not support color printing, restricting it to monochrome labels. As it is primarily designed for low- to medium-volume usage, it may not perform optimally in heavy duty industrial environments. The media capacity is relatively small, requiring frequent media changes in high usage scenarios. Additionally, the printer is now discontinued, which may restrict availability of replacement parts or technical support.
FAQ
What type of printing technology does the Zebra LP 2824 Plus use?
The Zebra LP 2824 Plus uses direct thermal and thermal transfer printing technologies.
What is the maximum print width supported by this printer?
The maximum print width supported by the LP 2824 Plus is 2.2 inches (56 mm).
Does the printer support color printing?
No, the Zebra LP 2824 Plus supports monochrome printing only, suitable for black and white labels.
What connectivity options are available for the LP 2824 Plus?
It offers USB, serial, and parallel interface connectivity options.
Is the Zebra LP 2824 Plus still available for purchase?
No, the LP 2824 Plus has been discontinued, but refurbished units and replacement parts may still be available through some vendors.
What resolution can I expect from this printer?
The printer produces labels at a resolution of 203 dpi (8 dots per mm).
Can the LP 2824 Plus be used for high-volume printing?
It is designed for low- to medium-volume printing; for high-volume needs, a more robust industrial printer is recommended.
