Zebra IMZ320
Brand | Zebra 2014 |
Model | iMZ320 |
Released Year | 2014 |
Type | Printers |
Series | Imz320 |
Status | Active |
Quick view
Overview
The Zebra iMZ320 is a compact, lightweight mobile printer designed specifically for on-the-go printing applications. It utilizes direct thermal printing technology, eliminating the need for ink or toner cartridges. The device supports 203 dpi resolution, ensuring clear, sharp text and barcodes. Connectivity options include Bluetooth and Wi-Fi for flexible wireless operation with mobile devices. It features an intuitive design with a user-friendly interface and fast print speeds of up to 4 inches per second. The device is compatible with a wide range of media widths up to 3 inches, suitable for receipts and labels.
Specifications
Model | iMZ320 |
Maximum Resolution | 203 dpi |
Black Print Speed | 4 in/s |
Product Line | Zebra iMZ320 |
Connectivity | Bluetooth 2.1 + EDR, Wi-Fi 802.11b/g/n |
Type | Label Printer |
Output Type | Black & White |
Memory | 8 MB SDRAM, 16 MB Flash |
Technology | Thermal |
MPN | M3I-0UB00010-02 |
UPC | Does not apply |
Print Technology | Direct Thermal |
Print Width | 72 mm (2.83 inches) |
Print Resolution | 203 dpi (8 dots/mm) |
Print Speed | Up to 102 mm/sec (4 inches/sec) |
Media Type | Receipt paper, labels |
Media Width | 50.8 mm to 76.2 mm (2 to 3 inches) |
Battery | Rechargeable Lithium-ion battery |
Dimensions | 132 mm x 74 mm x 44 mm (5.2" x 2.9" x 1.7") |
Weight | Approx. 320 g (11.3 oz) |
Operating System Compatibility | iOS, Android, Windows |
Interface | Serial, USB (via adapters), Wireless |
Durability | IP43 rated for dust and water resistance |
Power Supply | Rechargeable battery or AC adapter |
Images
Key Advantages
The Zebra iMZ320 excels in portability, allowing professionals to print anywhere efficiently. Its wireless connectivity options provide versatility in various mobile environments. The device’s compact design reduces user fatigue and integrates easily with existing mobile workflows. Direct thermal technology minimizes maintenance efforts and operating costs. Fast print speed enhances productivity in busy settings like retail or field services. Compatibility with popular mobile operating systems increases its adaptability across different platforms.
Limitations
The iMZ320's reliance on direct thermal printing means it is susceptible to fading over time, particularly when exposed to heat or sunlight. It has a limited print width, which can restrict the types of labels or receipts it produces. Battery life may require frequent recharging during extended use. The printer lacks support for higher resolution printing beyond 203 dpi, limiting finer detail output. Its initial cost may be higher compared to non-mobile printers. The compact size restricts media roll capacity, leading to more frequent media replacements.
FAQ
What printing technology does the Zebra iMZ320 use?
The Zebra iMZ320 uses direct thermal printing technology, which prints by heating specially coated thermal paper, eliminating the need for ink or toner.
What connectivity options are available on the iMZ320?
The iMZ320 supports both Bluetooth and Wi-Fi wireless connectivity options, allowing easy integration with mobile devices and networks.
What is the maximum print resolution of the iMZ320 printer?
The printer has a maximum print resolution of 203 dpi (dots per inch), suitable for clear text and barcode printing.
Can the iMZ320 print color labels?
No, the iMZ320 is a direct thermal printer and prints only in monochrome (black and white).
Is the iMZ320 suitable for printing wide labels?
The iMZ320 supports media widths up to 3 inches, which suits most receipt and label applications but is not ideal for wider formats.
What is the battery life of the Zebra iMZ320?
Battery life varies depending on usage but typically supports an entire work shift with moderate print volume before requiring a recharge.
Is the Zebra iMZ320 still available for purchase?
The iMZ320 series is generally still supported but may have limited availability as newer models have been released in recent years.
